AtGames Legends Core Instruction Manual

INSTRUCTION Manual
Sign Up For ArcadeNet ® !
More Games to Play
Discounts and Special Offers for Members
Online Multiplayer and Voice Chat
Global Leaderboards and Leagues Events
Legends Core FEATURES
1
2
3
5 6
4
How to Set Up
1. Connect the Legends Core to a TV or monitor via the included HDMI cable*.
2. Use the included Micro USB AC adapter* to power the Legends Core.
3. Switch to pairing mode on your controller (control device).
4. Press the pairing button on Legends Core and the pairing window will display on the
screen.
5. Press the pairing button and select your control device. Long press the pairing button
to confirm the pairing.
1
HDMI
The control device:
•
You may use the AtGames Legends Gamer series or third party controllers to connect
with the Legends Core.
•
While a variety of control devices may be able to connect, AtGames cannot recommend
any particular device.
•
The third party controller may not operate properly due to a variety of conditions, please
follow the instructions on the third party device.
*Note: HDMI Cable (1ft); Micro USB AC Adapter Cable (5ft) are included.
QUICK START GUIDE
All screenshots shown are for illustration purposes only. Actual screens may vary.
1. Power on the Legends Core and connect
to your control device.
2.
Use your controller to select from
[GAMES] to enjoy 100 pre-loaded games.
(Note: Internet connection is not required.
The games can be played offline.)
3.
To access the internet, connect an
Ethernet Cable (not included) or go to
[SETTINGS] to connect through Wi-Fi.
4.
To connect through Wi-Fi:
Sign Up at www.arcadenet.net
4-1. Select [Wi-Fi] under the [SETTINGS]
page.
4-2. Select the Wi-Fi SSID you would like
to connect to, and select [Connect]. If
prompted, enter the Wi-Fi password using
the on-screen keyboard and select
1. PAIRING BUTTON [Submit] when done.
2. RESET BUTTON
3. MICRO USB PORT
4. USB PORT
5. HDMI PORT
6. ETHERNET PORT
HOW TO UPDATE FIRMWARE
1. Power on the Legends Core and connect to your control device.
2. Connect internet via Ethernet (Ethernet cable is not included) or Wi-Fi.
3. Go to [SETTINGS] and select [Version].
4.
If there is a newer version, follow the instructions to download the latest firmware.
Make sure the internet connection is stable during this process.
5.
Once the firmware is downloaded successfully, select [Upgrade] and the device will
reboot automatically to activate the new firmware version.
Note: If you encounter any issues on firmware update, please contact support@atgames.net
2 4,5
PAIRING BUTTON
Power
TV
Micro USB
How to Sign in with your ArcadeNet® account
1. Go to [SETTINGS] and select [SIGN IN].
2. Sign up for a new account if you don't have one yet.
3. Once you have an ArcadeNet® account, you can choose either to sign in with your
email or with the QR Code. To sign in with your email, enter the email address and
password.
4. To sign in with the QR Code, a smartphone is required.
5.
Use a smartphone to scan the QR Code on the screen to launch the ArcadeNet®
website. You will be directed to the login page, where you can choose either to sign
in with your existing Google/Facebook account or your e-mail.
6. You will see the authorization notification
once complete. Now you can close the
window and return to your Legends Core.
A "Success!" message will show on the
screen once signed in.
WHEN TO SAFELY POWER OFF LEGENDS CORE
Do not power off the Legends Core during the following:
•
Firmware update
•
Factory reset
•
Data cleanup
•
Read/write USB drive
This could prevent irreversible data loss and/or damage to your device or USB drives.
