USE AND MAINTENANCE MANUAL
INTRODUCTION ......................................................................................................................................................... 2
PURPOSE ................................................................................................................................................................... 2
RESERVATIONS OF MANUFACTURER .................................................................................................................. 2
TECHNICAL DATA ..................................................................................................................................................... 2
STRUCTURE ADN FUNCTION ................................................................................................................................. 3
ASSEMBLY AND STARTUP ..................................................................................................................................... 4
OPERATIONAL USE .................................................................................................................................................. 6
TROUBLESHOOTING GUIDE .................................................................................................................................... 7
MAINTENANCE AND REPAIR .................................................................................................................................. 7
OCCUPATIONAL HEALTH AND SAFETY ................................................................................................................ 7
TRANSPORT AND STORAGE ................................................................................................................................. 8
TERMS OF WARRANTY ........................................................................................................................................... 8
DECLARATION OF CONFORMITY .......................................................................................................................... 8
Producer: KLIMAWENT S.A.
81-571 Gdynia, ul. Chwaszczyńska 194
tel. 58 629 64 80, 58 771 43 40
fax 58 629 64 19
email:
klimawent@klimawent.com.pl
www.klimawent.com.pl
Filtering unit HARD-2000-S
Contents:
October 2019
issue:
Advertisement
Table of Contents
Related Manuals for Klimawent HARD-2000-S
Summary of Contents for Klimawent HARD-2000-S
- Page 1 USE AND MAINTENANCE MANUAL Filtering unit HARD-2000-S Contents: INTRODUCTION ................................. 2 PURPOSE ................................... 2 RESERVATIONS OF MANUFACTURER ........................2 TECHNICAL DATA ..............................2 STRUCTURE ADN FUNCTION ..........................3 ASSEMBLY AND STARTUP ............................. 4 OPERATIONAL USE ..............................6 TROUBLESHOOTING GUIDE ............................ 7 MAINTENANCE AND REPAIR ..........................
- Page 2 Construction of HARD-2000-S meets the requirements of the current state of technology as well as the safety and health assurances included in: the safety and health assurances included in: 2006/42/EC Directive of the European Parliament and of the Council of the 17 May, 2006 on machinery, amending the 95/16/EC Directive (recast) / Official Journal EC L157 of the 09.06.2006, page 24);...
- Page 3 Klimawent – the warranty of highest quality at attractive price Fig. No.1 – HARD-2000-S – Flow chart STRUCTURE ADN FUNCTION HARD-2000-S consists of: ● steel housing ● radial fan – housing of cast aluminium pre-filter “paint-stop” – class G3 (hardly flammable) ●...
- Page 4 Fig. No.3 – HARD-2000-S – Dimensions, layout of connections ASSEMBLY AND STARTUP Before the use, install the ERGO LUX extraction arm or a hose on the HARD-2000-S filtering unit. For the extraction arm apply a suitable bracket DB-ERGO, whereas for the hose use simply an appropriate DC coupling.
- Page 5 Klimawent – the warranty of highest quality at attractive price Subsequent activities before the startup: remove two cover from the device top; slide out the HEPA high-efficiency filter and the FK pocket filter; screw out (inside the filtering unit) the blocking bolts of the activated carbon cassette;...
- Page 6 In order to replace the high-efficiency filter, first pull out the pocket filter, then (gripping the front handle and rear handle of the high-efficiency filter) lift and remove it from the HARD-2000-S filtering unit. Do not slide the high-efficiency filter directly on the guide profiles (while pulling out), as this could damage the sealing and cause filter malfunction as a result afterwards.
- Page 7 Klimawent – the warranty of highest quality at attractive price REPLACEABLE FILTERS Table No.2 – Pre-filter paint stop Weight Dimensions Efficiency Type Class [kg] [mm] PS-HARD-2000-S 700x740x50 90-95 Table No.3 – Pocket filter Weight Dimensions Efficiency Type Class [kg] AxBxHxT [mm]...
- Page 8 Klimawent – the warranty of highest quality at attractive price TRANSPORT AND STORAGE HARD-2000-S is transported on a pallet, protected with foil against weather conditions. During the transport, the appliance must be kept in vertical position and protected from overturn, knocking down and uncontrolled displacement / slide.
