  • Page 1 Installation and User Manual Pellet and Wood Central Heating Stoves Model TPW-23 Tested according to DIN EN 14785 For efficiency and emission, see enclosed declaration of conformity!
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION ................................3 2. FEATURES ..................................3 3. WARNING ..................................3 4. INSTALLATION AND CONNECTION ........................... 4 4.1 GENERAL INFORMATION ................................. 4 4.2 SAFETY ........................................4 4.3 INSTALLATION ..................................... 5 4.3.1 Electricity ......................................5 4.3.2 Sanitary ......................................5 4.3.3 Flue pipe connection ..................................
  • Page 3: Introduction

    We recommend you to keep this guide in order to reach the information about the correct use of the stove at the beginning of every winter. 2. FEATURES Technical Features TPW-23 Power 25KW Boiler connections out-in 1"- 3/4"...
  • Page 4: Installation And Connection

    ● CLEAN THE FIRE POT EVERYDAY. ● THE FLAME TRANSMISSION PIPES MUST BE CLEANED IN 3-4 DAY PERIODS WITH THE BRUSH SUPPLIED WITH YOUR STOVE OR BOILER. ● AT THE END OF THE WINTER, GENERAL MAINTENANCE AND CLEANING (WITH THE BRUSH) MUST BE CARIED OUT AND THE FUEL STORAGE MUST BE EMPTIED. ●...
  • Page 5: Installation

    * The pellet stove can operate in conjunction with the existing multiple chimneys. In addition, the stove should not be connected at places such as the aspirator chimney and ventilator. * Product needs to be connected to the chimney with a shortest distance. * Always check the water level in the stoves and radiators with the manometer before the first installation (1 - 1.5 bar range).
  • Page 6: Flue Pipe Connection

    installation, radiators and valves should be checked and the air in the installation should be emptied. This all needs to be done by the authorized person. *According to the weather conditions of the region, it is recommended to use 1/3 portion antifreeze against corrosion and freezing.
  • Page 7: Minimum Safety Distances

    4.3.4 Minimum Safety Distances While installing the stove, the fire regulations and chimney’s instructions must be complied. For any related questions please ask the chimney installer. Minimum distances to be observed in flammable or heat-sensitive materials (eg furniture, wallpaper, wood panels) (see diagram below) are: 25cm from rear wall Sayfa...
  • Page 8: Control Panel

    15cm from lateral wall and 80cm from the radiation area (front side of the product) Flammable materials and furniture should not be placed at a distance of 80 cm in the radiation area (C) of the flame monitoring cover. This distance can be reduced to 40 cm when the protection panel is placed between the stove and the materials that are likely to burn.
  • Page 9 The screen will be accessed when swiped to the left The active ones are displayed in green, inactive in black. The main screen will be accessed when scrolled down This screen is displayed in the Summer-Winter Menu, combustion management and the level of the Pellet or wood mode is shown.
  • Page 10: Main Display And Buttons

    5.2 MAIN DISPLAY AND BUTTONS Pressing this symbol in the lower left corner of the screen will display “Swipe to Open”, the system will start when you ON/OFF - RESET swipe. If there is an error in the system, touch this symbol again to remove the error, then ”Swipe to unblock”...
  • Page 11: Menus And Symbols

    SAMPLE VISUALS ; When you touch the info button one time following messages will be shown on the screen; The sample is visual, ignore the numbers. 5.3 MENUS AND SYMBOLS Save and exit menu. Return to main menu Exit menu without saving. Return to the previous menu 5.4 ERROR CODES AND EXPLANATIONS NOTE: If you recieve an Error Code please check the related parts and the values.
  • Page 12 Error Code Explanation Solution Check the valves and the circulation Safety limit thermostat error/boiler pump. Push the black tip of the safety Er01 temperature exceeds 90°C. limit thermostat inside, which is on the back side of the boiler. Check chimney connections and Er02 Chimney emission safety switch error emission.
  • Page 13: Menu Functions

    5.5 MENU FUNCTIONS Press the symbols on the touch screen to enter the menus. To save the changes press button. Press button to exit from the menu. 5.5.1 Settings menu Press button to enter the settings menu. In the settings menu, you can set the heating power, heating management, timer and manual loading.
  • Page 14: Combustion Management

    5.5.3 Combustion management Press the boiler thermostat to enter the sub-menu. You can move Boiler Thermostat the display to the right / left to change the boiler thermostat value (max 75 - min 50). To save the changes touch button. Touch button to exit menu.
  • Page 15: Display Menu

    5.5.7 Display menu This menu is used to set functions such as screen brightness, minimum brightness, and sound. 5.5.8 Chrono menu To enter this menu, press the on the lower right corner of the main menu. In order to be able to set the time, first check that your time and date are correct. When you enter the menu you will see the following screen.
  • Page 16 After selecting the time mode, this screen will appear (the text will change according to the selected mode). We can select the working day we want by scrolling the screen. When we touch the opening and closing hours, the screen will be displayed. Set the desired hours from the Start and ”Stop“...
  • Page 17: Cleaning And Maintnance

    6. CLEANING AND MAINTNANCE Cleaning sections Cleaning Frequency Flame Pipes cleaning Once a week Ash drawer cleaning Daily Combustion pot cleaning Daily Oven bottom and top cleaning Twice a year Oven cleaning Once a year 6.1 FLAME PIPES CLEANING Remove the metal plate on the product's upper table and brush the exchanger pipes with the brush provided with the stove or boiler.
  • Page 18: Ash Drawer Cleaning

    6.2 ASH DRAWER CLEANING Ash drawer under the fire pot must be emptied daily. Open the oven door and empty the ash drawer located on the upper side of the oven. 6.3 COMBUSTION POT CLEANING Carefully open the lid of the product so that the ashes are not spilled out, clean them with a vacuum cleaner (see picture 2).
  • Page 19: Oven Cleaning And Oven Section Cleaning

    It is advised to clean the grate daily. 6.4 OVEN CLEANING AND OVEN SECTION CLEANING The oven section needs to be cleaned once a year. First the oven door and then the oven section must be removed. In order to remove the cover, the hinges must be removed by hand or by a metal part and then the cover must be closed and removed.
  • Page 20 In order to remove the oven section after the cover, the screws and the oven section must be removed. After the dismantling, these sections should be cleaned with a wire brush. Sayfa...
  • Page 21 After cleaning, the oven section and then the oven door must be reinserted. Heat- resistant silicone should be used in the oven frame when installing the compartment screws. To clean the oven top, the cleaning cap (metal part) in the products’ upper table be removed and cleaned with the help of a brush twice a year.
  • Page 22: General Warranty Policy

    7. GENERAL WARRANTY POLICY ARAL MAKİNA MADENİ EŞYA SAN. VE TİC.LTD. ŞTİ provides warranty to the buyer within the framework of legal provisions. 2 (two) year warranty period against production defects starts from the actual delivery date. An invoice must be presented for inclusion in the warranty.
