Summary of Contents for Vision Technology InSight 1808
- Page 1 ® ™ InSight 1808 ™ Desktop Video Magnifi er Made in U.S.A. Owner’s Manual www.visiontechnology.com Copyright © Vision Technology, Inc. 07/04/08...
- Page 2 ® ™ Thank you for choosing a Vision Technology desktop video magnifi cation system. You have selected a precision-engineered product designed to give years of performance and reading enjoyment. You have selected the fi nest video magnifi er available in the marketplace.
- Page 3 ® ™ Overview InSight™ 1808 provides independence with the freedom to view phtographs, write, enjoy reading and hobbies. InSight™ 1808 includes the following features: > S Video, RCA Composite video and VGA video output allows the choice of CRT television, fl atscreen television or computer monitor.
- Page 4 ® ™...
-
Page 5: Table Of Contents
® ™ Table Of Contents Table of Contents Table of Contents Important Information Unpacking and Set Up Storage Compartment Optional Monitor Bracket Assembly Control Panel Customization of Settings Effects Package Option Trouble Shooting Specifi cations Warranty and Product Registration Warranty Service Information... -
Page 6: Important Information
® ™ Important Information Vision Technology is not responsible for damage incurred during shipment. In the event of damage to the shipping carton or its contents, immediately notify Vision Technology. Keep the original shipping carton and all packing materials in the event the unit needs to be returned for service or repairs. -
Page 7: Unpacking And Set Up
® ™ Unpacking and Set Up Place the Video Magnifi er on a sturdy work surface, such as a desk or table. Use a chair that allows you to view and work with the Video Magnifi er comfortably. What’s in the Box? Power Supply and Electrical Cord. - Page 8 ® ™ Unpacking and Set Up VGA video in port RCA video in port S- video in port Main Power in Port...
-
Page 9: Storage Compartment
® ™ Storage Compartment... -
Page 10: Optional Monitor Bracket Assembly
™ Optional Monitor Bracket Assembly 1. Remove the two screws located in the center top portion of the InSight 1808 unit. These same screws will be used in mounting the bracket to the top of the unit. 2. Place the short portion of the bracket on top of the Insight 1808. - Page 11 ® ™ Optional Monitor Bracket Assembly 3. Power supply cord and a VGA cable are inclusive with the purchase of new monitors. Connect the power supply cord and VGA cable to the monitor. 4. Align the four screw holes located on the back of the monitor with the slotted holes on the bracket.
-
Page 12: Control Panel
® ™ Control Panel Tap the power switch to power the Video Magnifi er on or off. An audible beep occurs when tapping the power switch and the reading lights illuminate. When powered on, the lock button locks and unlocks the reading table. Powering off the Video Magnifi... -
Page 13: Customization Of Settings
® ™ Customization of Settings Hold both sides of brightness button- this allows the choice in setting VGA or S-Video/ RCA-Video. There are two audible beeps indicating the selection has been made. Hold down the mode button when powering up the machine to turn the auditory beep on or off. -
Page 14: Effects Package Option
® ™ Effects Package Option Accessing Color Combinations There are eight color combinations to choose from. In order to access color combinations hold the MODE button in mode two “high contrast” or mode three “reverse high contrast” viewing mode. When you have determined your selection of a color combination release the mode button. -
Page 15: Trouble Shooting
® ™ Trouble Shooting SOLUTION SYMPTOM CAUSE Video Magnifi er A. No power to system Restore power at outlet. does not power on B. Defective power supply Replace power supply C. Membrane wire harness Service Required not connected or com- pletely connected A. -
Page 16: Specifi Cations
® ™ Specifi cations Features Reading Table Autofocus Unrestricted workspace Ball bearing table movement Internal Storage compartment Audible Feedback Magnifi cation Video Output 2x - 65x RCA Composite S-Video Illumination Optional Effects Package LED Lighting Color Combinations Line Markers Window Shading Power Supply Input Voltage 100-240 V AC Frequency 50-60 hz... -
Page 17: Warranty And Product Registration
Product repair because of failure to follow instructions and warnings in the owner’s manual, accident, misuse, abuse, lightning damage, unauthorized repair, failure to provide reasonable and necessary maintenance, improper packaging or transit by someone other than Vision Technology, acts of God, or other cause not within the control of Vision Technology, Inc. -
Page 18: Warranty Service Information
Warranty Service Information Warranty Service: Warranty service will be provided by Vision Technology. If you believe you need service for your product, contact Vision Technology at 800-560-7226. A representative will go through a diagnostic checklist with you. If it is determined that the product needs to be returned for service, you will receive a return authorization number. - Page 19 ® ™...
- Page 20 ® ™ Made in U.S.A. 8501 Delport Drive Saint Louis MO 63114 800-560-7226 Discover more innovative Vision Technology® low vision products www.visiontechnology.com Copyright © Vision Technology, Inc.
