Larson Electronics LED-ILS Instruction Manual

10-amp inline switch on/off toggle switch for led lights - ac or dc - for larson electronics led
Hide thumbs
1
2

Advertisement

Table of Contents

On/Off Toggle Switch for LED Lights - AC or DC - For Larson Electronics LED
Thank you for your purchase of the Larson Electronics LED-ILS.
WARNING:
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CRITICAL SAFETY INSTRUCTIONS:
•
INSTALLATION SHOULD ONLY BE CONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY
RELEVANT LOCAL BUILDING CODES.
•
RISK OF FIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL
SYSTEMS. IF NOT QUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.
•
BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•
MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.
•
TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP
OBJECTS. SUITABLE FOR DAMP LOCATIONS.
WARNING:
USER SHOULD BE TRAINED IN THE PROPER USE AND MAINTENANCE OF THIS DEVICE.
CORD IS INTENDED TO ALLOW OPERATORS TO EXTEND POWER TO EQUIPMENT WHEN STATIONARY OUTLETS ARE NOT
READILY AVAILABLE.
IMPROPER USE OF THIS CORD, PLUG, AND RECEPTACLE CAN LEAD TO SERIOUS INJURIES OR DEATH TO
PERSONNEL.
PERIODIC INSPECTION OF THE CORD IS NECESSARY.
THE CORD MUST BE ROUTINELY CHECKED FOR CUTS, BREAKS, OR ANY SEVERE ABRASIONS, AND IF ANY ARE FOUND,
THE CORD MUST BE REPLACED BEFORE RESUMING USE.
Inline On/Off Toggle Switch for LED Lights - AC or DC - For Larson Electronics LED Lights.

WIRING

The output wiring whip is terminated in a male water tight two pin Deustch connector. The input wiring whip is offer with a
female twp pin Deutsch connector, battery clamps, or ring terminals termination.

Low Voltage DC

Connect power to power supply outputting low voltage between 12-24 Volts DC.
This variable voltage allows greater versatility without affecting light output. Ensure
deutsch connectors are properly connected (If applicable)

DETACHABLE CORDS

•
Cord is attached via a weatherproof 2-pin Deutsch connector.
•
The cord is detachable by depressing the tab on the top of the connectors. This enables the
operator to remove and store the light while leaving the cord connected to the power source.
•
Additional or replacement cords can be ordered from our website. Contact us or visit LarsonElectronics.com for more
information.

MOUNTING

Two predrilled holes on each side of the switch allow for permanent flat surface mounting.
Larson Electronics, LLC
10-Amp Inline Switch
Instruction Manual
Phone: (800) 369-6671
Lights
Fax: (903) 498-3364
www.larsonelectronics.com
LED-ILS
THIS LINE
1 of 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LED-ILS and is the answer not in the manual?

Questions and answers

Related Manuals for Larson Electronics LED-ILS

Summary of Contents for Larson Electronics LED-ILS

  • Page 1 THE CORD MUST BE ROUTINELY CHECKED FOR CUTS, BREAKS, OR ANY SEVERE ABRASIONS, AND IF ANY ARE FOUND, THE CORD MUST BE REPLACED BEFORE RESUMING USE. Inline On/Off Toggle Switch for LED Lights - AC or DC - For Larson Electronics LED Lights. WIRING The output wiring whip is terminated in a male water tight two pin Deustch connector.
  • Page 2 Inspect for good working condition prior to storage and before re-use. REPLACEMENT PARTS The LED-ILS is designed to provide years of reliable performance. Should the need for replacement parts arise, please contact Larson Electronics. THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
