ASSEMBLY

Carefully remove the test frame/data acquisition assembly from the packaging and set it
on a sturdy bench top. Check the physical dimensions listed previously for the space
required for the instrument. As with any precision piece of laboratory equipment, it is
preferable to locate the COF-1000 in an area where temperature and humidity are
controlled to standard conditions of 72 ± 2 degrees Fahrenheit and 50 ± 5% relative
humidity.
WARNING: Make sure the power source matches the requirements of the
Coefficient of Friction Tester. Damage will occur if this unit is plugged
into the incorrect power supply.
Level the COF-1000 tester by adjusting the four leveling feet located at each corner of
the unit.
Place the Test Sled on the Test Platform and connect the cable to the hook on the Load
Cell.
Connect the power cord to its receptacle on the backside of the control cabinet.
Complete the connection by inserting the male end of the power cord into an
appropriate AC outlet. Notice that the on/off power switch is located directly beside the
power cord receptacle on the backside of the test frame.
WARNING: Before proceeding with using the COF-1000, it is advisable
to become familiar with the Key Components. These Key Components
and a brief description of their function follow in the next section.
