- Page 1 ASSEMBLY INSTRUCTIONS 48" High 3 Shelf Bookcase Lot Code # NEED HELP? Call 1−800−950−4782 www.bushbusinessfurniture.com Part Number A178122D Keep manual for future reference.
-
Page 2: Important Safety Information
A178122D IMPORTANT SAFETY INFORMATION WARNING Serious or fatal crushing injuries can occur from furniture tip−over. To help prevent tip−over: -Install tip-over restraint provided. -Place heaviest items in the lower drawers or shelves. -Unless specifically designed to accommodate, do not set TVs or other heavy objects on top of this product. - Page 3 A178122D IMPORTANT SAFETY INFORMATION WARNING Do not move unit when loaded. Doing so could cause instability, product collapse, tip over, and/or serious injury. No mueva la unidad cuando esté cargada. Hacerlo puede causar inestabilidad, que el producto se derrumbe, que se la caiga encima y/o heridas (golpes) serias.
-
Page 4: Exploded View
A178122D EXPLODED VIEW... -
Page 5: Parts List
A178122D PARTS LIST BK4836CS BK4836MR [ 1 ] W178086 A [ 1 ] W178092 [ 2 ] W178123 [ 2 ] W178126 [ 1 ] W178089 D [ 1 ] W178095 [ 1 ] W178125 [ 1 ] W178128 [ 2 ]... -
Page 6: Fasteners / Hardware
FASTENERS / HARDWARE A178122D Fasteners are shown in actual size. los fijadores son demonstrados en su tamaño actual. les attaches sont montrées dans l'échelle grandeur. [ 40 ] H34174 [ 8 ] H72988 Nail 19mm KD Bolt [ 1 ] [ 8 ] H107572 H71659... - Page 7 A178122D MODEL SPECIFIC BK4836CS BK4836MR [ 8 ] [ 8 ] H73621 H107306 Cover Cap Cover Cap BK4836AC BK4836MC [ 8 ] H163153 [ 8 ] H107305 Cover Cap Cover Cap BK4836HC BK4836NC [ 8 ] H95137 [ 8 ]...
- Page 8 A178122D STEP [ 8 ] H72988 KD Bolt...
- Page 9 A178122D STEP H184321 H73621 [ 4 ] [ 4 ] H71659 H107305 H163153 H95137 Cover Cap KD Cam H73620 Flush Nivelado Abondant...
- Page 10 A178122D STEP H184321 H73621 [ 4 ] H71659 [ 4 ] H107305 H163153 H95137 KD Cam Cover Cap H73620 Flush Nivelado Abondant...
- Page 11 A178122D STEP [ 40 ] H34174 Nail 19mm Safety glasses 1/16" gafas de seguridad Lunettes de protection WARNING Failure to install every indicated Si no se instalan todos los clavos Le fait de ne pas installer chaque nail and/or screw could lead to y / o tornillos indicados, se podría clou et / ou vis indiqué...
- Page 12 A178122D STEP Secure unit to the wall with a tip-over restraint. Unidad de seguro a la pared con un sistema de retención de un vuelco. Fixer l'unité au mur avec un dispositif de retenue renversement. 1. Place unit in desired location. 2.
- Page 13 A178122D STEP WALL STUD ATTACHMENT Drill 1/8" hole 2" deep at mark on wall. Taladro 1/8 "agujero 2" de profundidad en la marca en la pared. Percer 1/8 "trou de 2" de profondeur à la marque sur le mur. [ 1 ] H181412 [ 1 ] H181434...
- Page 14 A178122D STEP [ 1 ] H107572 [ 1 ] H181412 #8 x 1-1/2" Connecting Plate Drill 1/8" hole 1" deep at mark on unit. Taladro 1/8 "agujero de 1" de profundidad en la marca de la unidad. Percer 1/8 "trou 1" de profondeur à la marque sur l'unité. Correct Correcto [ 1 ]...
- Page 15 A178122D STEP [ 8 ] H126396 Shelf Pin Sleeve [ 8 ] H23604 Shelf Pin Maximum Weight: 0 Lbs. Peso Máximo: 0 Libras Poids Maximum: 0 kilogramme Maximum Weight: 90 Lbs. Peso Máximo:940 Libras Poids Maximum: 40.8 kilogramme Maximum Weight: 140 Lbs. Peso Máximo: 140 Libras Poids Maximum: 63.5 kilogramme...
- Page 16 THIS PAGE INTENTIONALLY LEFT BLANK...
- Page 17 WARRANTY INFORMATION/INFORMATIONS POUR LA GARANTIE/INFORMACIÓN DE GARANTÍA BUSH BUSINESS FURNITURE’S VOTRE GARANTIE BUSH BUSINESS GARANTIA ESCRITA DE BUSH WRITTEN WARRANTY TO YOU FURNITURE BUSINESS FURNITURE PARA USTED In order to provide you with timely assistance, please Afin de vous assister rapidement, veuillez inspecter Para brindarle asistencia oportuna, por favor, veri- thoroughly inspect your furniture for missing or votre mobilier en détail immédiatement après...
-
Page 18: Consumer Service
1,2,3 IT’S AS EASY AS Assembly tips: 1. Read the instructions and become familiar with the parts. 2. Ensure this carton contains all parts, fasteners and hardware. 3. To protect floors, assemble the furniture on the carton. Thank you for purchasing this Bush Business 4.
