- Page 1 PROFESSIONAL ROOM STERILISERS USER’S MODELS: VS-100/450, VS-160/600, VS-300/900, MANUAL VS-400/1200, VS-600/1500, VS-900/1800...
-
Page 2: Table Of Contents
Table of Contents 1. Notes for service technicians ....................................... 3 2. Notes for users..........................................4 3. Important safety instructions ...................................... 5 4. Product features ........................................... 12 4.1 Purpose ..........................................12 4.2 Product description ......................................12 4.3 Operating principle ......................................14 5. -
Page 3: Notes For Service Technicians
Notes for service technicians The following service instructions are intended exclusively for qualified service personnel. To reduce the risk of danger (electric shock, UV-C exposure, exposure to high ozone concentrations), persons without appropriate qualifications or without appropriate training should not perform any servicing other than as described below. When servicing this appliance, the service technician is exposed to dangerous UV-C radiation, high concentration of the hazardous substance –... -
Page 4: Notes For Users
Notes for users The STERYLIS room steriliser can emit health hazardous UV-C radiation and generate high ozone concentrations. For this reason, please read these operating instructions very carefully, especially the chapter on safety! Keep this manual and store it in a safe place. Do the same for the safety data sheet (ozone) and the UV-C radiation safety data sheet. -
Page 5: Important Safety Instructions
Important safety instructions There are several warning stickers on the housing of the device, the contents of which are also presented below. It is imperative that you comply with them! Failure to comply with the information contained therein may lead to a risk to the health or life of the user or other persons, animals and living organisms, and may lead to the failure of the device. - Page 6 cataracts. The most common, acute symptom of eye exposure to UV-C radiation is inflammation of the cornea and conjunctiva. Corneal inflammation manifests itself in photophobia, increased tearing, a feeling of a foreign body in the eye, eyelid spasm, and sometimes visual impairment. The symptoms of inflammation appear after a period of concealment lasting even less than 30 minutes, and the symptoms of inflammation disappear about 14 hours after exposure.
- Page 7 The device is designed to sterilise rooms by generating ozone in a concentration that may pose a threat to the health and life of humans and other living organisms. Despite the safety principles during the operation of the product as described in the following chapters, it is essential to read the information below on possible effects of ozone and on first aid in case of exposure to a hazardous concentration of the substance.
- Page 8 The graph on the left shows very clearly what effects ozone poisoning can have on humans depending on their concentration and exposure time. The graph shows: asymptomatic area such concentrations and such exposure times there should be no symptoms of ozone poisoning), non-toxic area (possible light, life-threatening symptoms), transiently toxic area (strong symptoms of poisoning...
- Page 9 Personal protective equipment (ozone) Hygiene measures Water and soap Respiratory protection Full protective respiratory and eye mask with NO P3 filter (according to EN 14387) Eye protection Full protective mask for the airways and eyes Hand protection Chemical-resistant protective gloves Skin protection Protective clothing and footwear Ozone sensor located on the inside the steriliser allows the current concentration of ozone in the room to be tested, so...
- Page 10 The safe operation of the product is also related to the principles listed below: The device may only be operated in sterilisation mode in a tightly closed room (no ozone may penetrate outside the sterilised room). Therefore, make sure that all windows, doors and any other escape routes for ozone from the room are tightly closed.
- Page 11 harm electronics, flowers and other sensitive or poor quality materials. Ozone as such is a powerful oxidant and in addition to destroying microorganisms it can also destroy other objects. No animals or plants should be left in the disinfected room, as living organisms can suffer, so it is recommended to take them out. If there are valuable objects in the room, including electronics, it is also advisable to move them during disinfection.
-
Page 12: Product Features
Product features 4.1 Purpose The product is designed for air cleaning and disinfection and surface disinfection. Depending on the mode of operation, it can work as a standard air purifier, an air purifier extended by sterilisation lamps with UV-C light source and as an ozoniser. - Page 13 STERYLIS VS is available in 6 versions, whose technical parameters are shown in the table: Name STERYLIS STERYLIS STERYLIS Model VS – 100/450 VS – 150/600 VS – 300/900 Rated voltage 230 V 230 V 230 V Frequency 50 Hz 50 Hz 50 Hz Rated power*...
-
Page 14: Operating Principle
4.3 Operating principle Ozoning: The steriliser has ozone generators, the number of which varies depending on the version. The ozoning process consists in starting all the ozone generators in the device and achieving a concentration of O particles in the room of 7 ppm. - Page 15 their reproduction. Subjected to high levels of UV-C radiation, microorganisms and viruses are permanently destroyed. In addition to the disinfecting effect of the UV-C radiation used, we also obtain a high quality deodorising effect (removing odours from the air). Due to the special design of the UV-C chamber, the device operating in disinfection mode can be used in rooms where people are present.
-
Page 16: Packing Contents
Packing contents A user who has purchased any model of STERYLIS room steriliser receives a set of: Complete room steriliser ready for use Additional pre-filter Detachable 3-meter long power cord Additional 10-meter long power cord* Operating manual Safety data sheet (ozone) UV-C safety data sheet Safety data sheet Declarations of conformity in Polish and English... -
Page 17: Operation
Operation The device should be operated in rooms whose parameters are consistent with the technical characteristics of the device. In addition, they must be operated in accordance with the information contained in the chapters on safety and maintenance. 6.1 Operation of the device To operate the room steriliser, use the user panel on the front of the device. -
Page 18: User Panel
6.2 User panel The signal LED signals a user safe ozone concentration in the air after the ozone cycle. STERILIZATION O section: segmented display indicating operating mode and error codes, +, -, PROG. buttons. SET and START and warning lights O and ! CONCENTRATION section: segment display indicating the ozone concentration and the +, - and SET buttons Alarm icons for failure of a system of ozone generators, ozone sensor or UV-C fluorescent lamps... -
Page 19: Starting The Device And Selecting The Operating Mode
6.3 Starting the device and selecting the operating mode The device can operate in four operating modes, the activation of which is forced by means of appropriate buttons on the user panel. The following modes are available: Filtration, UV-C air disinfection – standard mode, UV-C air disinfection – silent mode and O sterilisation To start the device, insert the power cord plug into an electrical outlet. -
Page 20: Uv-C Air Disinfection - Silent Mode" Operating Mode
During the standard disinfection mode, the device indicates: - Characters - - - - on the display in the O STERILIZATION section or the LOCH message (when the device is in locked mode) and error and message codes (if any) - On the display in the O CONCENTRATION section: Value of the current ozone concentration when the concentration exceeds 0.1 ppm / Characters - -.- - during the ozone sensor warm-up phase / In other cases, the display is inactive... -
Page 21: Sterilisation" Mode
6.3.4 “O sterilisation” mode CAUTION! Ozone is a substance hazardous to human and animal health and life. Before starting to operate the device in sterilization mode, it is essential to read these operating instructions, especially the safety sections! NOTE! Before starting the sterilization mode, replace the activated carbon filter with a standard filter. Such a filter is included with the device. -
Page 22: Sterilisation - Manual" Mode
instructions in 6.4) and a flashing signal generated by the warning beacon (regardless of the measured ozone concentration). When the safe ozone concentration (0.1 ppm) is exceeded, the safe ozone concentration indicator will stop illuminating. The sterilisation process or the countdown to the start of sterilisation can be interrupted at any time by pressing any button on the user panel. -
Page 23: Other Functions In Sterilisation Mode
counting down the time remaining until the start of sterilization and O and ! will start blinking. After the 120-second countdown, the unit will check the proper functioning of the relevant actuators (PRE-TEST) and then the ozone generators will start and the unit will operate in the selected mode of operation. If any errors are detected during the test, the device will display a tESt message, go into standby mode and then display the corresponding error codes on the display in the O STERILIZATION section. -
Page 24: Emergency Situations During The Sterilization Process
If the room exceeds the 10 ppm ozone concentration threshold, the unit will display an error and proceed to ozone destruction until the safe concentration is reached and the safe ozone concentration light is lit. 6.3.4.5 Emergency situations during the sterilization process The following emergencies may occur during operation in sterilization mode: Emergency situation Behavior of the device after an emergency... -
Page 25: Changing The Configuration Parameters
To activate the front panel locking mode: During active standby, silent disinfection, standard disinfection or filtration, press and hold the + and - buttons in the O STERILIZATION section for at least 3 seconds. To deactivate the front panel locking mode: While the front panel lock mode is active, press and hold the + and - buttons in the O STERILIZATION section for at least 3 seconds. -
Page 26: Electricity Consumption Counting
pressing the yellow START button longer. If the code is incorrectly entered, the code XXXX or HHHH will be displayed and a short beep will occur. In this case, the code must be re-entered. You can interfere with the following counters: Parameter code Description d102... -
Page 27: Auto-Test Function
The individual parameters are changed using the + and - buttons in the O STERILIZATION section. The code of the selected parameter is displayed in the O STERILIZATION section. To move to a given function, select it and press and hold the PROG.SET button. -
Page 28: Set-Factory-Settings Function (Resetting To Factory Settings)
The display in the O CONCENTRATION section shows: The value of the current ozone concentration when the concentration exceeds 0.1 ppm / characters - -.- - during the heating phase of the ozone sensor when the concentration exceeds 0.1 ppm and when the selected sterilization mode / In other cases the display is inactive The display under OZONING TIME indicates the characters - -.- - ... -
Page 29: Maintenance
Maintenance 7.1 Recommendations for maintenance Note! All maintenance work should only be carried out when the unit is disconnected from the power supply (with the exception of alarm removal activities)! Note! Maintenance work related to the replacement of the ozone sensor, UV-C fluorescent lamps and ozone generators may only be carried out by authorized personnel and the manufacturer's factory service. - Page 30 Insert your index finger into the hole in the air filter cartridge and pull it towards you with a slight movement. Pull the cassette out with a downward motion Turn the front air filter cartridge towards the floor Remove the air filter from the cartridge Insert a new air filter into the cartridge, making sure that the direction of the arrow on the cartridge and on the filter are aligned.
- Page 31 A pre-filter that is pulled out of the destination causes a violation of the limiting switch. If a limiting switch is violated during the sterilisation process, the process will be stopped and completed and the device will go into standby mode. In case of violation of the limiting switch in filtration or disinfection mode, the process will be stopped at the current moment and the unit will go into pause mode.
-
Page 32: Replacing The Uv-C Lamps
The active carbon filter that is pulled out of the destination causes a violation of the limiting switch. If a limiting switch is violated during the sterilisation process, the process will be stopped and completed and the device will go into standby mode. -
Page 33: Procedure For Carrying Out The Ozoning Process
Procedure for carrying out the ozoning process The room ozonisation process must be carried out according to the following instructions. Before starting to ozone, read the rest of this manual and meet all the safety requirements described at the beginning of this document. Prepare the room according to the instructions below: (a) Clean the room - vacuum, ventilate, clean from any spills. -
Page 34: Possible Errors And Messages
Possible errors and messages All possible errors and messages are indicated by 4-digit codes on the display in the O STERILIZATION section. If more than 1 error occurs simultaneously, the codes are displayed one after the other, the presentation time of each code is 2 seconds. - Page 35 The device can communicate with the user through the following indications: Indication Meaning Green filtration mode light is on The device works in filtration mode Green silent mode light is on The device works in silent disinfection mode Green standard mode light is on The device works in standard disinfection mode The device, after a timeout, will go into sterilization mode The device will stop working in the sterilization mode after...
-
Page 36: Declaration Of Conformity
Declaration of conformity This device complies with the relevant directives and standards in force in the European Union, provided that the device is operated as intended and in accordance with this manual. The product complies with the following directives: Directive 2014/35/EU, on the harmonisation of the laws of Member States relating to the making available on ... -
Page 37: Warranty And Service
Serial number Date of manufacture The information in this document may be changed by „MILOO-ELECTRONICS” without notice. Reproduction of this manual without the consent of the manufacturer is prohibited. Photos and figures are for illustration only and may differ from the purchased unit.
