- Page 1 GENFINE Purifier HT User manual V2.1...
-
Page 2: Table Of Contents
Contents Chapter 1 Product Introduction1 ....................... 3 1.1 Product Name........................3 1.2 Model ..........................3 1.3 Intended use ........................3 Chapter 2 Function Introducion ......................4 2.1 Main Components ....................... 4 2.1.1 Front View ......................4 2.1.2 RearView ....................... 4 2.2 Working Principle ....................... - Page 3 7.8 Safety and User Guide ..................... 21 Chater 8 Manufacturer and Medical Device Information ............... 22 Chater 9 Order Information ......................22 9.1 Purifier HT confiuration....................23 9.2 List of Accessories and Consumabes ................23 9.3 List of Kits ........................23 Appendix A Certificate of Decontamination ...................
-
Page 4: Chapter 1 Product Introduction1
The instrument can be applied for the extraction and purification of nucleic acid from different clinic samples. Purifier HT is especially used on research and tests by the personnel who have been trained professionally. It is used for automatic transfer and processing of magnetic beads in deep well plates. -
Page 5: Chapter 2 Function Introducion
Chapter 2 Function Introduction 2.1 Main Components 2.1.1 Front View Figure 2-1.Purifier HT Front view 2.1.2 Rear View Figure 2-2. Purifier HT Rear View... -
Page 6: Working Principle
Purifier HT (Figure 2-1), The magnetic tip combs matches the deep-well Plate. The magnetic head consists of two vertically moving platforms. One is used for the magnetic tip rods (24 or 96) and the other is used for grasping the magnetic tip comb. During running, the magnetic tip comb and the magnetic rods move vertically to complete the mixing of reagents and the adsorption and release of magnetic beads. -
Page 7: Chapter 3 Installation
• Humidity is low and condensation does not occur (relative humidity is between 10% and 80%); • Install the Purifier HT in a protected place where no one can step on or trip over the power cord, and where it is easy to access the power cord when the plug needs to be removed;... -
Page 8: Installtion Settings
Warning Do not put the Purifier HT magnetic head near the computer monitor, as this may damage the monitor. The product has a strong permanent magnet. This product should not be used by people wearing pacemakers or metal prostheses. Prosthetic devices such as pacemakers or prostheses may be affected or damaged by close contact with strong magnetic fields. -
Page 9: Chapter 4 Instructions For Use
Chapter 4 Instructions for Use 4.1 Starting Before turning on Purifier HT, make sure that the voltage on the label which is on the left bottom of the back panel (Figure 2-2) matches the local voltage. Warning Never operate the instrument on an ungrounded electrical outlet. -
Page 10: New Pogram Creation
During the program running, the interface displays the total time and remaining time of the program. Click "Pause" to pause the program. Click “Continue” to resume running. Click "Cancel", a dialog box will indicate whether to exit the current running program or not. Click "Cancel"... - Page 11 Click "Add" to add steps after, click "Insert" to add steps before the selected step, and click "Delete" to delete steps. Click "Edit" to set step parameters. Click "Back" to return to the main screen. Steps, parameters edition should be according to the actual situation to set the plate position, solution volume and step options.
- Page 12 The heating temperature and time are selected according to the requirements of the experiment. The temperature setting range is 0-99°C, and the temperature can be switched. The entry position of the deep-well plate is the position where the magnetic tip comb enter the deep-well plates for mixing;...
-
Page 13: User Settings
4.2.4 User Settings The user can select "User Setting" on the main screen to set the parameters of Purifier HT. After entering the user setting interface, the user can set the language, fan switch, light switch and prompt tone switch. There are two modes of language: Chinese and English. "Factory Setting" is not accessible to the users. -
Page 14: Emergencies
4.4 Emergencies If an abnormal situation occurs during operation, such as liquid spilling into the instrument, please follow the steps below: (1) Turn off the instrument immediately (Figure 2-3). (2) Unplug the power plug. (3) Implement appropriate corrective measures. But do not disassemble the instrument. (4) If the corrective measures taken do not help, please contact authorized technical service or your local agent. -
Page 15: Chapter 5 Care And Maintenance
Although Purifier HT is made of high-quality materials, you must remove the spilled salt solution, chemical solvent, acid or alkaline solution from the surface immediately to prevent damage to the instrument. -
Page 16: Decontamination Procedure
5.9 Disposal of the instrument If Purifier HT must be discarded, please follow the specific regulations of the laboratory and the country for the treatment of biological waste. The disposal of the instrument is carried... - Page 17 electronic equipment and waste. Disposal procedures vary from country to country. For the original packaging and packaging materials recycle, please cooperate with a recycler you are familiar with. Warning Disinfect the instrument before disposing of it. Please refer to decontamination procedures.
-
Page 18: Chapter 6 Technical Parameters
Chapter 6 Technical Parameters 6.1 General Parameters As part of our continuous product development plan, the manufacturer reserves the right to change any parameters without prior notice. General parameter Overall size Device 840 mm(width)x685 mm(length) x420 mm(height) Transport package 850 mm(width)x760 mm(length) x610mm(height) Weight Device about 41kg[±0.5g]... -
Page 19: Performance Parameters
6.2 Performance parameter Performance parameter Processing volume 20-1000ul (96 deep-well plate), 96 channel magnetic rods Capacity (sample per run) Maximum 96 Collection efficiency of magnetic 96 deep well plate, containing detergent beads neutral cleaning solution, 2.8μm magnetic beads, collect three times, at room temperature, recovery rate ≥95% Magnetic bead size Average diameter＞1um... -
Page 20: Compliance
6.4 Compliance Purifier HT meets the following compliance: YY 0505-2005/IEC 60601-1-2:2001 GB 4793.1-2007/IEC 61010-2:2001 6.5 Error code P96 error code P96 error type Solution X axis photoelectric switch error If the error is reported repeatedly after restarting, contact the engineer. -
Page 21: Chapter 7 Other Information
Chapter 7 Other information 7.1 Production Date See the label for details. 7.2 Service life The recommended service life should not exceed 5 years. 7.3 Components List Purifier HT Packing List Number Item Name Quantity Unit Purifier HT 96 magnetic rod... -
Page 22: Interpretation Of Graphics
This instruction is for end-users, such as scientific researchers and laboratory technicians; it provides basic information about the 96-channel automatic nucleic acid extraction and purification instrument (referred to as Purifier HT), including the installation and operation of the instrument. 7.7 More information For the latest information on products and services, please visit our website: http://www.genfine.com/. -
Page 23: Chater 8 Manufacturer And Medical Device Information
Chapter 8 Manufacturer and Medical Device Information GENFINE BIOTECH (CHANGZHOU) CO., LTD 4th Floor, Building E4, No.9, Changyang Road, West Taihu Technology Indus trial Park, Changzhou City, Jiangsu Province PEOPLE’S REPUBLIC OF CHINA Tel: +86 051983761557 marke ting@genfi ne.com E-mail: Web: en. -
Page 24: Purifier Ht Confiuration
P961001 Purifier HT（DEMO） P961002 Purifier HT（Mass production） P961003 Purifier HT（Test） 9.2 List of accessories and consumables Table 9-2 List of accessories and consumables used with Purifier HT Item No. Content Quantity Purifier 96 magnetic tip comb PR04 96-well square-well U-shaped PL05 plate 1.6ml plate... -
Page 25: Appendix A Certificate Of Decontamination
Appendix A: Certificate of Decontamination Name： Address： Telephone / Fax： Device： Record Number： (A) I confirm that the returned items are not contaminated with liquid, toxic, carcinogenic or radioactive substances or any other harmful substances. (B) I confirm that the returned items have been decontaminated and can be processed without affecting the health of the personnel. -
Page 26: Appendix B System Log
Appendix B: System Log Device name and number User Date Remarks... - Page 27 济凡生物科技（常州）有限公司 Genfine Biotech (Changzhou) Co., Ltd www.genfine.com marketing@genfine.com...
