Summary of Contents for HIMO C26
- Page 1 Please read the instruction manual carefully before using your bike Do not use the bike until you know its performance. Please keep the instruction manual properly E-Bike...
-
Page 2: Notes For Using
Notes for using Preparation before riding Obey traffic rules strictly Whether the power circuit and lighting are good. According to the regulations on the implementation of the road traffic safety law of the People's Republic of China, e-bike rider must be at least 16 years old. Whether the front and rear brake lever are good. -
Page 3: Electrical Schematic
Electrical schematic Main technical parameters of the bike Dimensions (L*W*H) Front and rear wheel center distance Motor Booster sensor Max weight Power signal Maximum design speed The cathode Controller Assisting rang Head light signal Electric range The cathode Consumes electricity（100KM） Loading weight The cathode Overspeed warning signal... - Page 4 Get to know C26 quickly Battery mounting and locking 1.Insert the key to rotate to the open state,put the battery into the predetermined position of the body,push it upward until the machine makes a clear sound and the battery is energized.
-
Page 5: Display Introduction
Display and riding mode Display introduction Mode button Switch button Speed Mileage accumulated (switching) Subtotal mileage Headlight indication (switching) Power indicator Gear position indication (power/medium speed/high speed) -
Page 6: Normal Riding
Normal riding Electric assist riding Long press the button for 3 seconds to start the Long press the key for 3 seconds to electric bike; close the electric bike; The first default gear is "ECO" assisted cycling mode; Pedal riding Pedal riding speed reaches 5KM/H;... - Page 7 Switch for the headlight Long press button for 3 second to open the headlight Long press button for 3 second to close the headlight Mileage pattern In the startup state; Press button to switched between (TRIP) → accumulated mileage (ODO)
-
Page 8: Battery Charging
Battery charging Daily charge Charger First plug the power supply pin of the charger into the charging port ofthe battery, and then plug the power supply pin into the power supply. Indicator light Under charging state, the indicator light of charger is red,and when fully charged, it is green. -
Page 9: Check Battery Capacity
Check battery capacity When your battery is in the state of charging or not charging, press the power display button to display the current remaining power. Power indicato Battery capacity button Change battery Taillight opening and maintenance Prepare 1 suitable phillips screwdriver, 2 no. 7 batteries. Tail light Remove the rear lamp, unscrew the front panel screw, open the rear housing, and replace the battery. -
Page 10: Transmission Diagram
Transmission using Transmission diagram Gear Power Speed Gear pointer Rlax Slow Moderate Moderate Hard Fast To speed up, start with a lower gear and shift to a higher gear as you speed up When going uphill, the speed will decrease,the gear will be lowered to maintain a certain pedal strength Shift down Downwind will speed up, increase gear to maintain a certain degree of pedal strength... -
Page 11: Damping Adjustment
Damping adjustment Shock absorber indicato on 1.Shock absorber opening is suitable for abnormal uneven road surface. The front fork is stretched up and down under the force, which can alleviate the impact of the protrusion on the vehicle and the rider, better protect the bicycle parts, and make riding more comfortable and easy to control. - Page 12 Description of component Display Knob Saddle Gear shifer Hnadlebar Charging port License plate intergral tail light Battery Seat post Head light Suspension fork Wheel light Wheel light Rear disc brake Front disc brake Motor Pedal Gear system Kickstand...
-
Page 13: About Batteries
About batteries Note before use of lithium battery Before use, confirm that the battery model is the original battery of the whole bike, do not use any other brand of battery. Check the appearance of lithium battery intact, no damage, leakage, heat and water, smoke and other obvious phenomena. In order to ensure the safety of transportation, the battery's output power is about 30%. -
Page 14: Storage Environment
Charger port of the battery Use the original charger to charge the battery. Do not use other brand or model charger to charge the battery. Please charge the battery at the ambient temperature of 10℃ ~ 40℃ to ensure that there are no flammable substances around and good ventilation. -
Page 15: Maintenance And Repair
Maintenance and repair Regular bike inspection Whether the fastener is locked or not, whether the joints of all parts are normal: Whether the tread pattern of the tire is worn and cracked, whether the front and rear tire pressure is appropriate, Whether the drive system is smooth;... -
Page 16: Maintenance And Cleaning Instructions
According to <Product quality of the People's Republic of China>&<Law of the People's Repulic of China on the protection of user's right and interests>and the regulation of after sales service,the after sales service for HIMO electric scooter is as below: Free reason in return within 7 days If the goods are rejected or intercepted due to non-quality reasons after shipment, the user shall bear the round-trip freight. - Page 17 The warranty policy During the warranty period, HIMO official customer service center will provide you with free after-sales service.If the service period and scope of "three guarantees" are exceeded, HIMO official customer service center will provide you with paid after-sales service according to the local market situation and maintenance price.
- Page 18 The following circumstances are not within the scope of warranty service, we will provide you with paid after-sales service. Three guarantees of validity have been issued;Missing or changed invoice;Damage caused by force majeure. Repair, misuse, collision, negligence, abuse, accident, modification, incorrect use of this product without HIMO's approval, frame serial number destroyed.
- Page 19 The HIMO guarantee service standard for electric vehicle parts exceeds the specified service period and scope. Failure or damage of the HIMO electric vehicle product caused by the user's failure to properly use, drive, maintain and adjust the HIMO electric vehicle product according to the instructions.
- Page 20 Responsibilities and obligations Three guarantee policy Item Allowance for depreciation The warranty period From the date of receipt and signature, the HIMO authorized Battery after-sales service center will provide after-sales service for 24 month you within the warranty period Natural open welding, off welding, fracture, deformation, paint off...
- Page 21 Solutions of trouble Problems Reasons for the problem Solution way When the power is turned on , Bike is not powered 1.Check whether the battery plug is properly inserted the bike can not be powered on 2. Battery undervoltage, charge the battery Turn on the power and turn on 1.Whether the brake lever is on the brake 1.The bike is in the brake status 2.The speed did not reach 5km/h...
- Page 22 Model name Electric mountain power bike The name and content of harmful substances in the product Hazardous substance Parts name Display Headlight Taillight Battery Control ler Charger 1.This form is prepared in accordance with the provisions of SJ/T 1136 O:Indicates that the content of the hazardous substance in all homogeneous materials of the part is below the limit set by GB/T 26572.
- Page 24 HIMO official public number The principal:Shang hai HIMO Electric Technology Co. LTD Manufacturers:Tianjin Fuji-ta Technology Co. LTD Producer:Tianjin Fuji-ta Technology Co. LTD Manufacturer add:Taian road and AIMA road, south distr development zone, tianjin Service number:400-182-9808...
