- Page 1 INSTALLATION GUIDE TeamWorx Version: October 15, 2012...
- Page 2 INSTALL STABILIZER BARS ON WORKSURFACES A. Turn worksurfaces upside down. B. Install stabilizer bars. In some cases, they should be installed at an angle. C. Note: only worksurfaces 60” and greater have stabilizer bars included. DeskMakers TeamWorx Installation Guide...
- Page 3 Modesty panel placement varies. Refer to project drawings and Purchase Order. NOTE: on some configurations such as a double-pedestal desks, the modesty panel should be attached to the cargo hub by screwing through the back of the open cargo hub and into the modesty panel. DeskMakers TeamWorx Installation Guide...
- Page 4 B. Center spine wall panels will have dowel holes on both sides, while end spine wall panels will have dowel holes on one side only. C. Wall sections should be tightly abutting each other before you proceed to the next step. DeskMakers TeamWorx Installation Guide...
- Page 5 B. Align the privacy panel so that it is seated snugly in the clip. C. Tighten the clip using a Phillips screwdriver (for 2”x 2” two-piece clips) or an Allen wrench (for 1- 5/8” x 3/4” clips. DeskMakers TeamWorx Installation Guide...
