AIDA
TECHNICAL MANUAL
ENG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIDA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Saxun AIDA

Summary of Contents for Saxun AIDA

  • Page 1 AIDA TECHNICAL MANUAL...
  • Page 2 INDEX 1. GENERAL RECOMMENDATIONS REGARDING SAFETY, USE AND RESTRICTIONS 2. PARTS LIST AND SECTION 2.1 PARTS LIST AIDA 3. WIND RESISTANCE, CUTTING BOARDS AND SELECTION 3.1 WIND RESISTANCE (EN 13561) 3.2 MOTOR SELECTION 3.3 DEGREES OF INCLINATION 4. VIEWS AND CROSS-SECTIONS 4.1 FIXTURE PLATE DIMENSIONAL CROSS-SECTION...
  • Page 3 6. MAINTENANCE 6.1 CLEANING AND CARE 7. ANNEX I 7.1 WHAT TO DO IN CASE OF EMERGENCY 8. ANNEX II 8.1 MOTOR CONFIGURATION 9. ANNEX III 9.1 DISASSEMBLY AND DISPOSAL OF THE PACKAGING AND COMPONENTS OF THE PRODUCT AT THE END OF ITS USEFUL LIFE IMPORTANT It is important to read these instructions carefully before installation, operation, repair or first use, in...
  • Page 5 TECHNICAL MANUAL AIDA 1. GENERAL RECOMMENDATIONS REGARDING SAFETY, USE AND RESTRICTIONS In order to ensure the safe assembly, use and main- persons (especially children!) may interfere or cause tenance of this product, a number of precautionary hazards during installation. measures must be taken. Please observe the following...
  • Page 6 024151 Front side cover Aida 024534 Bracket for box Aida 024148 Box and front bars end covers Aida 022990 Set of arms 024149 Covers for box and front bar end covers Aida 024553 Ceiling bracket Aida 024154 Middle support Aida...

  • Page 7: Motor Selection

    TECHNICAL MANUAL AIDA 3. WIND RESISTANCE, CUTTING BOARDS AND SELECTION 3.1 WIND RESISTANCE (EN 13561) WIND RESISTANCE EN 13561 WIDTH MINIMUM 2.50 2.75 3.00 3.25 3.50 3.75 4.00 4.25 4.50 4.75 5.00 5.25 5.50 5.75 6.00 PROJECTION LINE 1.85 2.45 2.10...
  • Page 8 4. VIEWS AND CROSS-SECTIONS 4.1 SUPPORT CROSS-SECTION 156.50 Ø14 Ø12.50 4.2 SUPPORT INSTALLATION VIEW CEILING FRONTAL INSTALLATION INSTALLATION...
  • Page 9 TECHNICAL MANUAL AIDA 4.3 POSSIBLE INSTALLATION EXAMPLES CENTRAL REINFORCEMENT ARM SUPPORT WALL / CONVEYOR CEILING FIXATION 2 ARMS 3 ARMS 4 ARMS 5 ARMS 6 ARMS...

  • Page 10: Assembly And Installation

    5. ASSEMBLY AND INSTALLATION 5.1 WINDING TUBE ASSEMBLY...
  • Page 11 TECHNICAL MANUAL AIDA 5.2 WALL FASTENING ASSEMBLY 5.3 CEILING FASTENING ASSEMBLY 1° 2°...
  • Page 12 M8 (2x) M8x16 (2x) 5.4 SUPPORT AND CONVEYOR ASSEMBLY M8x20 1° 2° 2° 1° M8x16 (2x) M8 (2x) M8x20 M8 (2x) 1° 2° M80 (2x) M80 (2X) M8x20 (2x) ~1500mm...

  • Page 13: Arm Assembly

    TECHNICAL MANUAL AIDA <5mm <5mm 5.5 ARM ASSEMBLY 2° 1°...
  • Page 14 <2 cm <2 cm 2° 1° 3° 3° 2° 1° CLICK!
  • Page 15 TECHNICAL MANUAL AIDA 5.6 CASSETTE COVER ASSEMBLY M6x10 (3X) M6x10 (2X) M4.2x32...

  • Page 16: Terminal Assembly

    5.7 TERMINAL ASSEMBLY 1° DO NOT CUT DO NOT CUT 2° M4.2x19 1° <2 mm 2°...
  • Page 17 TECHNICAL MANUAL AIDA 5.8 CANVAS ASSEMBLY...

  • Page 18: Machine Assembly

    5.9 MACHINE ASSEMBLY M6x40 (2X) M4.2X32 (3X)
  • Page 19 TECHNICAL MANUAL AIDA 5.10 ATTACHMENT OF THE ARMS TO THE TERMINAL fascetta di Security sicurezza band...

  • Page 20: Wall Mounting

    1° 2° 0 mm 5.11 WALL MOUNTING <145 mm...

  • Page 21: Ceiling Mounting

    TECHNICAL MANUAL AIDA 5.12 CEILING MOUNTING UNI 6954 M4.2X31 5.13 ARM ALIGNMENT...
  • Page 22 Cap.3.2 3 mm...
  • Page 23 TECHNICAL MANUAL AIDA 5.14 COMPLETION OF ASSEMBLY 1° 2° M4.2x32 (2X)
  • Page 24 5.15 WINDING TUBE MOTOR ASSEMBLY Motor Axle cup Adaptador Grapa Motor 2° 1° 3,9x16 (x2)
  • Page 25 TECHNICAL MANUAL AIDA 2° 1° M6x10 (2X) Motor cable LED kit cable...

  • Page 26: Maintenance

    6. MAINTENANCE 6.1. CLEANING AND CARE For best use and extended durability of the screen, it is recom- To clean the canvas, we recommend removing the dust that mended to carry out regular maintenance and checks at least has accumulated without using water, to enable you to re- once a year, or even more often depending on the wear and move all the surface particles by vacuuming, air blowing, tear caused by wind at the installation site.

  • Page 27: Motor Configuration

    TECHNICAL MANUAL AIDA 8. ANNEX II 8.1 MOTOR CONFIGURATION 1. INTRODUCTION 6. USE 6.1. Standard use. 2. SAFETY 6.2. Use with a Somfy io sensor. 2.1. Safety and responsibility. 6.3. Feedback 2.2. Specific safety regulations. 7). ADDITIONAL SETTINGS 3. INSTALLATION 7.1.

  • Page 28: Installation

    2. SAFETY 2.2 Safety and responsibility 2.2 Specific safety regulations Before installing and using the product, read this guide In addition to the safety standards described in this guide, carefully. the instructions detailed in the attached document, titled “Safety standards that must be respected and conserved” A property motorisation and automatisation professional must be followed.
  • Page 29 TECHNICAL MANUAL AIDA 3.2.3 Remove burrs and chips from the rolling tube. For smooth tubes, make a notch according to the dimensions indicated: - e = 4 mm - h = 28 mm. 3.3 Motor - tube installation 3.3.1 Insert the motor into the rolling tube.
  • Page 30 4. CABLES 4.2 Connect the motor as per the information in the following table: IMPORTANT Always make a loop in the power cable to avoid 3 x 0,75 mm 230 V water penetrating the motor. During installa- tion, comply with the standards and legislation 50 Hz in force.
  • Page 31 TECHNICAL MANUAL AIDA B) The awning does not move Press the raising or lowering button and carry out process “c” or “d” according to the reaction of the awning: C) The awning still isn’t moving The limit switches are not adjusted and there is no Somfy io control point registered.
  • Page 32 5.5 Setting the limit switches The limit switch settings depend on the type of awning. 5.5.1 Settings for cassette-type awnings For cassette-type awnings, the upper limit switch is auto- matically adjusted, but you need to adjust the lower limit switch. Lower limit switch setting IMPORTANT Do not use the “My”...
  • Page 33 TECHNICAL MANUAL AIDA 5.5.2 Modification of non cassette-type awnings For non cassette-type awnings, the upper and lower limit switches must be modified. Upper limit switch setting 1. Place the awning in the upper limit switch position. IMPORTANT If the raising button is pressed for more than 2 seconds, the awning will continuously raise itself.
  • Page 34 5.5.3 Modification of non cassette-type awnings For non cassette-type awnings, the upper and lower limit switches must be modified. Upper limit switch setting 1. Place the awning in the upper limit switch position. IMPORTANT If the raising button is pressed for more than 2 seconds, the awning will continuously raise itself.
  • Page 35 TECHNICAL MANUAL AIDA 5.6 Prior registration of first Somfy io local control point 5.6.1 Using a previously registered Somfy io local control point Briefly press the PROG button of this control point (G): the awning moves briefly and the control point will have been registered.
  • Page 36 6. USE 6.1 Standard user 6.1.1 Favourite position (“My”) Definition The motor can register an intermediate position named “fa- vourite position (My)” that is different to the upper and lower limit positions. IMPORTANT To register, modify or delete the favourite po- sition (“My”), consult the “Additional settings”...

  • Page 37: Additional Settings

    TECHNICAL MANUAL AIDA 7. ADDITIONAL SETTINGS 7.1 Favourite position (“MY”) 7.1.1 Registering or modifying the preferred position (“My”) The processes of registering and modifying the preferred position (“My”) are the same. 1. Place the awning in the desired position “My”.
  • Page 38 7.3.2 Modification for non cassette-type awnings For non cassette-type awnings, the upper and lower limit switches can be modified. Resetting the upper limit switch 1. Place the awning in the upper limit switch position. 2. Press the raising and lowering buttons simultaneously un- til the awning moves: the motor is now in adjustment mode.
  • Page 39 TECHNICAL MANUAL AIDA 7.4 Advanced functions IMPORTANT Contact the awning manufacturer before using these functions to check the compatibility of its installation. 7.4.1 Back Impulse” function This function allows the canvas to be tightened during every lowering movement of the awning. It can be adjusted up to ½...
  • Page 40 7.4.3 "Closing force" function for cassette-type awnings only This function allows the user to increase or reduce the awn- ing cassette closing force on 3 levels (high-medium-low). By default, the motor is supplied from the factory set to a medium level. For safety reasons, this function can only be accessed from the Somfy io control point in 3 cases: - After the settings are confirmed and before the first Som-...

  • Page 41: Tips And Tricks

    TECHNICAL MANUAL AIDA 8. TIPS AND TRICKS 8.1. Do you have any questions about the Sunea screen io? PROBLEM POSSIBLE CAUSES SOLUTIONS The cabling is incorrect. Check the cabling and modify it if necessary The motor is too hot Wait for the motor to cool down.

  • Page 42: Technical Data

    9. TECHNICAL DATA Radio frequency 868-870 MHz io-homecontrol® bidirectional triband Power source 230 V ~ 50 Hz Use temperature -20 °C a +70 °C Protection index IP 44 Maximum number of control points and associated sensors Security level Class I...
  • Page 43 TECHNICAL MANUAL AIDA 9.ANNEX III 9.1. DISASSEMBLY AND DISPOSAL OF THE PACKAGING AND COMPONENTS OF THE PRODUCT AT THE END OF ITS USEFUL LIFE IMPORTANT he packaging must be recycled by the authorised professional who installed the product. We advise you to recycle the product packaging respon-...
  • Page 44 DISASSEMBLY AND REMOVAL OF THE PRODUCT When disassembling this product, a number of precau- tionary measures must be taken. Observe the following IMPORTANT warnings and instructions. Please contact your supplier The disassembly of the product at the end with any queries. of its useful life must be carried out by qualified personnel, and in order to carry it Disassembly may only be carried out by experienced...
  • Page 45 TECHNICAL MANUAL AIDA • Step 13 Loosen and remove the screws that secure the termi- IMPORTANT nal cover to the cover, and the terminal cover to the Ensure than you dispose of all pieces of the terminal profile, and remove the covers.
  • Page 46 STEEL STAINLESS COMPONENTS ALUMINIUM WEEE PLASTIC TEXTILES GALVANISED STEEL • Profiles • Screws • Axle • • Motor • Motor supports • Supports • • Set of arms • Terminal plate • Canvas IMPORTANT - Always act with care. Please only use Our products are mainly made of recyclable materials.

  • Page 47: Galvanised Steel

    TECHNICAL MANUAL AIDA THE MATERIALS THAT OUR PRODUCTS ARE MADE OF OFFER A GREAT VARIETY OF ENVIRONMENTAL ADVANTAGES GALVANISED STEEL Galvanised steel is a type of steel which undergoes a certain treatment, at the end of which it is coated with several layers of zinc which protect it, avoiding oxidation.
  • Page 48 PLASTIC Plastic recycling provides a sustainable source of raw material for the industry. Its reuse also significantly reduc- es environmental problems, as it is a non-biodegradable material. Recycling reduces energy consumption and CO2 emis- sions, thus mitigating pollution and climate change. There are several types of plastic, so to achieve optimal recycling it is essential to deposit them in clean points where the separation of the different types and their...
  • Page 49 NOTES...
