KIARA
TECHNICAL MANUAL
ENG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KIARA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Saxun KIARA

Summary of Contents for Saxun KIARA

  • Page 1 KIARA TECHNICAL MANUAL...
  • Page 2 INDEX 1. GENERAL RECOMMENDATIONS REGARDING SAFETY, USE AND RESTRICTIONS 2. PARTS LIST AND SECTION 2.1 PARTS LIST KIARA 3. WIND RESISTANCE, CUTTING BOARDS AND SELECTION 3.1 WIND RESISTANCE (EN 13561) 3.2 MOTOR SELECTION 3.3 DEGREES OF INCLINATION 3.4 MINIMUM LINE ACCORDING TO ARM MEASUREMENT 3.5 MANUFACTURING DISCOUNTS...
  • Page 3 6. MAINTENANCE 6.1 CLEANING AND CARE 7. ANNEX I 7.1 WHAT TO DO IN CASE OF EMERGENCY 8. ANNEX II 8.1 MOTOR CONFIGURATION 9. ANNEX III 9.1 DISASSEMBLY AND DISPOSAL OF THE PACKAGING AND COMPONENTS OF THE PRODUCT AT THE END OF ITS USEFUL LIFE IMPORTANT It is important to read these instructions carefully...
  • Page 5 TECHNICAL MANUAL KIARA 1. GENERAL RECOMMENDATIONS REGARDING SAFETY, USE AND RESTRICTIONS In order to ensure the safe assembly, use and main- persons (especially children!) may interfere or cause tenance of this product, a number of precautionary hazards during installation. measures must be taken. Please observe the following...
  • Page 6 1 | 1 1 | 1 1 | 1 CODE COMPONENTS CODE COMPONENTS 024716 Kiara Awning Caps Wall Kit 024629 BC pro le Kiara 024754 Kiara Awning Caps Ceiling Kit 024739 Diffuser profile LED 17x5.3 mm 024702 Kiara Awning Wall Kit 022807 Axle Ø80...

  • Page 7: Motor Selection

    TECHNICAL MANUAL KIARA 3. WIND RESISTANCE, CUTTING BOARDS AND SELECTION 3.1 WIND RESISTANCE (EN 13561) WIND RESISTANCE EN 13561 WIDTH PROJECTION 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75 4.00 4.25 4.50 4.75 5.00 5.25 5.50 5.75 6.00 1.50 1.75 2.00...
  • Page 8 3.4 MINIMUM LINE ACCORDING TO ARM MEASUREMENT MINIMUM LINE ACCORDING TO ARM MEASUREMENT (m) MINIMUM LINE (m) PROJECTION (m) Motor 1.25 1.51 1.50 1.76 1.75 2.01 2.00 2.26 2.25 2.51 2.50 2.76 2.75 3.01 3.00 3.26 3.25 3.51 3.50 3.76 3.75 4.01 4.00...
  • Page 9 TECHNICAL MANUAL KIARA 4. VIEWS AND CROSS-SECTIONS 4.1 FIXTURE PLATE DIMENSIONAL CROSS-SECTION 18.50 20.75 Ø11 13.50 Ø11 Ø11 24.50 50.50 4.2 SUPPORT INSTALLATION VIEW Wall Ceiling Ceiling with square Wall to wall...

  • Page 10: Assembly And Installation

    5. ASSEMBLY AND INSTALLATION 5.1 IDENTIFICATION OF PARTS Mobile support Fixed support Left support Right support Motor/dot support Fixture plates Multi-motor support Canopy Load bar Box awing Power strip kit Screws...
  • Page 11 TECHNICAL MANUAL KIARA 5.2 ROLLING TUBE ASSEMBLY Attach the canvas to the rolling tube using plugs and screws. Insert the fixing screws into the rolling tube. 5.3 AWNING PROFILES ASSEMBLY Place the wedges equidistant Insert the brush profile into its upper register profile from each other.
  • Page 12 Place the protective profile over the canvas, and place the With the rolling tube already in the awning, place the rolling tube into the awning profile. canopy profile into its housing folding it down until it fits. 5.4 AWNING ASSEMBLY Attach the mobile supports to the awning profiles with the screws...
  • Page 13 TECHNICAL MANUAL KIARA 5.5 ANGLE OF THE AWNING Select the correct groove depending on the desired angle, within the following range: On a wall: grooves F1 (0º - 37.5º) and F2 (37.5º - 75º) On a ceiling: grooves T1 (17º - 37.5º) and T2 (37.5 - 75º) Install it according to the version (the steps are the same whatever groove is chosen), placing bolt A in the desired groove.

  • Page 14: Motor Assembly

    5.7 MOTOR ASSEMBLY Screw the motor to the motor/tip support with the screws and insert the support/motor assembly into the shaft. Use the screws to screw on all three supports. 5.8 BRACKET ASSEMBLY To assemble the arms, insert the solid shafts A and attach Install the power strips on the front terminals using the...

  • Page 15: Terminal Assembly

    TECHNICAL MANUAL KIARA 5.9 TERMINAL ASSEMBLY Insert the canvas into the load bar profile and screw To attach the terminal cap to the terminal, insert the the power strips to it using the screws B. Insert the screw into the inside of the terminal and attach it to the terminal cap.
  • Page 16 To ensure that the arms are level, open the awning just enough to be able to work (it is not necessary to open the awning all the way). Adjust the height of the elbows using the front support stud bolt on both sides until the elbows of the arms are parallel.

  • Page 17: Installation Instructions

    TECHNICAL MANUAL KIARA 5.12 INSTALLATION INSTRUCTIONS Take the measurements, place the fixture plates on the wall and mark the slots to be drilled. Attach the supports to the surface using a level, in order to make sure that they are level. Use the correct fastenings, depending on the surface that you want to fix the awning to.
  • Page 19 TECHNICAL MANUAL KIARA 60 mm If the plates are installed directly onto the ceiling and are If clearance cannot be provided for adjusting the angle, flush with the wall, adequate clearance must be provided use roof brackets as an alternative.

  • Page 20: Maintenance

    6. MAINTENANCE 6.1. CLEANING AND CARE For best use and extended durability of the screen, it is recom- To clean the canvas, we recommend removing the dust that mended to carry out regular maintenance and checks at least has accumulated without using water, to enable you to re- once a year, or even more often depending on the wear and move all the surface particles by vacuuming, air blowing, tear caused by wind at the installation site.

  • Page 21: Motor Configuration

    TECHNICAL MANUAL KIARA 8.ANNEX II 8.1. MOTOR CONFIGURATION 1. SAFETY 1. Safety and responsibility 2. Specific safety regulations Before installing and using the product, read this guide In addition to the safety standards described in this guide, carefully. the instructions detailed in the attached document, titled “Safety standards that must be respected and conserved”...
  • Page 22 3. Motor - tube installation 3.1 Insert the motor into the rolling tube. 3.2 For safety reasons, attach the rolling tube to the wheel with 4 Ø5 For rolling tubes. mm Parker screws or 4 Ø4.8 mm Pop steel rivets situated: For smooth rolling tubes, align the notch you have made with - At a minimum of 5 mm from the exterior end of the the crown.
  • Page 23 TECHNICAL MANUAL KIARA 3. CABLES 2. Connect the motor as per the information in the IMPORTANT following table: Always make a loop in the power cable to avoid water penetrating the motor. During installa- tion, comply with the standards and legislation in force.
  • Page 24 B) The awning does not move Press the raising or lowering button and carry out process "c" or "d" according to the reaction of the awning: C) The awning still isn’t moving The limit switches are not adjusted and there is no Somfy io control point registered.
  • Page 25 TECHNICAL MANUAL KIARA 5. Setting the limit switches The limit switch settings depend on the type of awning. Settings for cassette-type awnings For cassette-type awnings, the upper limit switch is auto- matically adjusted, but you need to adjust the lower limit switch.
  • Page 26 8. Prior registration of first Somfy io local control point 1. Using a previously registered Somfy io local control point Briefly press the PROG button of this control point (G): the awning moves briefly and the control point will have been registered.
  • Page 27 TECHNICAL MANUAL KIARA 6. USE Standard use 1. Favourite position ("My") Definition The motor can register an intermediate position named “fa- vourite position (My)" that is different to the upper and lower limit positions. To register, modify or delete the favourite position (“My"), consult the "Additional settings"...

  • Page 28: Additional Settings

    7. ADDITIONAL SETTINGS FAVOURITE POSITION ("MY") 7.1 Registering or modifying the preferred position ("My") The processes of registering and modifying the preferred position ("My") are the same. 1. Place the awning in the desired position "My". 2. Press the "My" button until the awning moves: the pre- ferred position ("My") will be registered.
  • Page 29 TECHNICAL MANUAL KIARA 7.7 Modification for non cassette-type awnings For non cassette-type awnings, the upper and lower limit switches can be modified. 7.8 Resetting the upper limit switch 1. Place the awning in the upper limit switch position. 2. Press the raising and lowering buttons simultaneously un- til the awning moves: the motor is now in adjustment mode.
  • Page 30 7.10 "Back release" function for cassette-type awnings only This function allows the canvas tension of the cassette-type awning to be loosened after it has been closed. IMPORTANT The procedure for activating "Back release" is the same. For safety reasons, this function can only be activated or deactivated from the Somfy io control point in 3 cases: - After the settings are confirmed and before recording the first Somfy io control point.
  • Page 31 TECHNICAL MANUAL KIARA To install this function: 1. Place the awning in the middle position. 2. Press the "My" and raising buttons simultaneously fol- lowed by a simultaneous sustained pressing of the "My" and raising buttons until the awning moves.

  • Page 32: Tips And Tricks

    8. TIPS AND TRICKS 8.1.Do you have any questions about the Sunea screen io? PROBLEM POSSIBLE CAUSES SOLUTIONS The cabling is incorrect. Check the cabling and modify it if necessary The motor is too hot Wait for the motor to cool down. The cable used is incorrect Check the cable used and make sure it has 3 wires The Somfy io control point battery needs...

  • Page 33: Technical Data

    TECHNICAL MANUAL KIARA 9. TECHNICAL DATA Radio frequency 868-870 MHz io-homecontrol® bidirectional triband Power source 230 V ~ 50 Hz Use temperature -20 °C a +70 °C Protection index IP 44 Maximum number of control points and associated sensors Security level...
  • Page 34 9.ANNEX III 9.1. DISASSEMBLY AND DISPOSAL OF THE PACKAGING AND COMPONENTS OF THE PRODUCT AT THE END OF ITS USEFUL LIFE IMPORTANT he packaging must be recycled by the authorised professional who installed the product. We advise you to recycle the product packaging respon- The disposal of paper and cardboard can be do sibly: through various channels such as collection by pri-...
  • Page 35 TECHNICAL MANUAL KIARA DISASSEMBLY AND REMOVAL OF THE PRODUCT IMPORTANT The disassembly of the product at the end of its useful life must be carried out by qualified personnel, and in order to carry it out, the reverse steps that were carried out for its assembly must be performed.
  • Page 36 IMPORTANT Always act with care. Please only use suit- able tools that are in perfect condition. • Step 1 • Step 10 Remove the caps from the awning, either by pulling Loosen and remove the screws that attach the motor/ on the cap until it comes off, or by removing the nylon tip supports to the fixed supports.
  • Page 37 TECHNICAL MANUAL KIARA STEEL STAINLESS COMPONENTS GALVANISED / ALUMINIUM WEEE PLASTIC TEXTILES STEEL ZINCED • Profiles • Screws • Axle • End caps • • Motor • Motor supports • Supports • • Set of arms • Terminal plate •...

  • Page 38: Stainless Steel

    THE MATERIALS THAT OUR PRODUCTS ARE MADE OF OFFER A GREAT VARIETY OF ENVIRONMENTAL ADVANTAGES GALVANISED STEEL Galvanised steel is a type of steel which undergoes a certain treatment, at the end of which it is coated with several layers of zinc which protect it, avoiding oxidation. The recycling of zinc helps reduce demand for new materials and as a result generates considerable energy savings, being a metal that constitutes a very valuable and sustainable resource.
  • Page 39 PLASTIC Plastic recycling provides a sustainable source of raw material for the industry. Its reuse also significantly reduc- es environmental problems, as it is a non-biodegradable material. Recycling reduces energy consumption and CO2 emis- sions, thus mitigating pollution and climate change. There are several types of plastic, so to achieve optimal recycling it is essential to deposit them in clean points where the separation of the different types and their...
