- Page 1 Sauter GmbH Ziegelei 1 Phone : +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 e-mail: info@kern-sohn.com Internet: www.sauter.eu Instruction manual motorized test bench with stepper motor SAUTER TVO-S/THM-S Version 2.0 01/2020 PROFESSIONAL MEASURING TVO-S-THM-S-BA-e-1920...
-
Page 2: Table Of Contents
Instruction manual motorized test bench with stepper motor Congratulations on purchasing the SAUTER TVO or the THM test bench with stepper motor. We hope you enjoy your quality measuring system with its wide range of functions and high reproducibility. If operated correctly, this high-quality product will give you many years of use. -
Page 3: Introduction
Stopping is also carried out very precisely and without overtravel. All Sauter force gauges up to 2 KN, depending on the test bench, can be adapted to the TVO-S and THM-S series. -
Page 4: Check Before Use
It can be used for material testing in the metal, plastics and textile industries. It can also be operated with SAUTER software (AFH), from where it can be conveniently controlled by PC. This software is also able to document force, time and distance. - Page 5 TVO500N TVO1000N TVO2000N5 THM500N Test bench 500S 500S 500S Maximum force 500 N 1000 N 2000 N 500 N 1-500 1-500 1-500 1-500 Speed range mm/min mm/min mm/min mm/min Speed accuracy 1% of max. Maximum travel 270mm 500mm 700mm 245mm distance Maximum number 1000...
-
Page 6: Control Panel
6 Control panel Function Declaration Main switch: Switching the test bench on / off Lower slide moves upwards (as long as is Direction switch OPEN: pressed) Lower slide moves downwards (as long as is Direction button AB: pressed) Stop button: In Auto Mode the movement is stopped Speed control knob: Regulation of the lifting speed... -
Page 7: Application
The test stand has two 9-pin connectors to connect a force gauge and one connector for communication with the PC. The test stand can be operated with SAUTER AFH software. This allows the motion control and number of cycles to be set directly on the PC. -
Page 8: Warnings
8 Warnings Incorrectly performed force measurements can lead to serious injury to persons and damage to objects. Force measurements should therefore only be carried out by trained and experienced personnel. In particular, it should be avoided that forces are applied to the measuring instrument by the test bench which exceed the maximum load (Max) of the test bench or measuring instrument or which do not act axially on the instrument via the test bench Note:... -
Page 9: Technical Drawings
9 Technical drawings 9.1 TVO-S Position AxBxC [mm] D [mm] 380x665x280 500N500S 405x930x265 1000N500S 465x1135x300 2000N500S TVO-S-THM-S-BA-e-2020... -
Page 10: Thm-S
9.2 THM-S Position AxBxC [mm] 233x236x688 500N500S TVO-S-THM-S-BA-e-2020...
