- Page 1 Sauter GmbH Ziegelei 1 Tel.: +49-[0]7433-9933-199 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-mail: info@sauter.eu Internet: www.sauter.eu Instruction manual Motorized vertical test stand with stepper engine SAUTER TVO-S Version 1.0 03/2017 PROFESSIONAL MEASURING TVO-S-BA-e-1710...
- Page 2 Congratulations on your purchase of a motorized vertical test stand with step motor from SAUTER. We hope that you are satisfied with the quality of workmanship of the test stand, and its multiple functionalities. If you have any suggestions, questions or doubts, we are ready to assist you.
- Page 3 TVO-S test stands also feature a precise stop function without run-on. TVO-S test stands can be adapted for mounting all SAUTER force measuring de- vices. SAUTER offers optional software and accessories which ensure maximum configura- tion flexibility of your measuring instrument.
- Page 4 4 adjustable legs Operation manual 5 Weight and packaging Standard dimensions (TVO 500N500S): L × W × H: 570 × 430 × 235 mm Specific weight: 25 kg Packaging: stable wooden box 6 Functions 6.1 Operator panel Main switch: Switching on/off the test stand Direction switch UP: Movement up (when the switch is pressed, the force measuring device moves up)
- Page 5 TVO-S test stands have been designed to ensure trouble-free mounting of the major- ity of SAUTER force measuring devices. The test stands have a very broad range of applications and are suited to manual operation. In addition, they make it possible to automate a range of functions such as stepless speed adjustment, and automatic lifting and lowering with a set number of repetitions (up to 1,000).
- Page 6 The test stand is compatible with AFH soft- ware from SAUTER which supports a number of functions including speed adjust- ment and setting the number of cycles directly from the computer as well as evalua- tion of data in relation to force, time or distance covered.
- Page 7 that time, movement is resumed in the opposite direction. To ensure smooth testing, the limiting rings must be set very accurately, so that the test object/testing apparatus is not damaged when the set travel path setting is too long/too short. 10 Maintenance Keep the surroundings of the test stand clean.
