Intellex® RMS Installation Note
READ THIS BEFORE INSTALLING THE RMS!
Connect the Mouse
Connect the VGA Monitor
®
Intellex
Installation Note
NOTE: This note adds or corrects information in the Intellex
RMS Installation and Operating Instructions. In case
of conflict, this note replaces information in those
manuals.
NOTE: Default recording mode changed to circular. Note
that the default Intellex 3.1 recording mode has been
changed from linear to circular. To change the
recording mode, click the Setup button, then the
Record Mode button. In the Record Mode dialog box,
select either Linear or Circular.
You must connect the mouse cable to the upper PS/2-style con-
nector (#4 in Figure 1 below) on the rear of the unit. The lower
PS/2-style connector (#5 in Figure 1) is for a keyboard
(optional).
The monitor must be connected to the VGA connector (#11 in
Figure 1).
RMS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Intellex RMS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for American Dynamics Intellex RMS

  • Page 1 Intellex® RMS Installation Note Intellex Installation Note READ THIS BEFORE INSTALLING THE RMS! NOTE: This note adds or corrects information in the Intellex NOTE: Default recording mode changed to circular. Note Connect the Mouse You must connect the mouse cable to the upper PS/2-style con- nector (#4 in Figure 1 below) on the rear of the unit.
  • Page 2: Installing The Hard Drives

    Intellex® RMS Installation Note INSTALLING THE HARD DRIVES The six hard drives packaged with the Intellex RMS must be installed in the unit. The hard drives are each contained in caddies so they may be easily installed. 1. Remove the drives from the packaging.
  • Page 3 1. Master Power Switch — This switch turns the unit on and off. 2. Power Setting — Use this switch to select the correct input voltage setting: 115 or 230 volts. Intellex RMS Digital Video Management System Figure 1 —Rear Panel Connectors...
  • Page 4 Pink Mic In (Microphone) 9. Com2 — This DB9-P connector provides the interface between the unit and a dome controller (Sensormatic VM16 or American Dynamics ADTT16). 10. Printer — This DB25-S connector provides the interface between the unit and the printer.
  • Page 5 Select the language desired and follow the instruc- tions on the screen. If the installation wizard does not start automatically, click on Start, Run, then browse to the drive letter of the CD drive and run Setup.exe. Intellex RMS Digital Video Management System...
  • Page 6 Intellex® RMS Installation Note Audio Recording and Monitoring Connecting the Audio Source Connect the audio source to the Intellex unit through the color coded 3.5mm audio con- nectors on the rear of the unit. The pink connector is used for a microphone input and the blue connector is used for a line level signal input.
  • Page 7 Intellex unit. • Canceling an export while writing to the CD will make the entire CD unreadable. Do not cancel writing if you are adding a new clip to a previously recorded CD. Intellex RMS Digital Video Management System...
  • Page 8 Our dealers are empowered to provide the very best in customer service and support. Dealers should contact American Dynamics at (800) 507-6268 or (561) 912-6259 or on the Web at www.americandynamics.net. Part Number 8200-0243-00 B0 ®...
