American Dynamics Intellex ADRSS030TB3 Datasheet

RAID storage system
The American Dynamics RAID Storage System is a highly reliable
storage device that offers high-density, high-performance storage
expansion for Intellex digital video management systems. This low
cost-per-terabyte storage solution features high drive density in a
rack-mountable 2U form factor complete with twelve (12) hot-
swappable drive bays. Powerful Direct Attached Storage (DAS)
and network configurations provide scalable, high-availability
extended storage Module
Retain more video over longer periods of time with an Extended
Storage Module (ESM). Ideal for Intellex DVMS and LT systems
each ESM seamlessly expands your database capacity by an
additional 640 GB or 1000 GB. You can triple the capacity by
cascading up to three ESM units per Intellex DVMS or LT. Both
ESM640 and ESM1000 are compatible with desktop and rack
mount installations.
Rack Mount Kits
Turn your standard desktop Intellex DVMS or LT into a rack-
mountable unit with our steel-constructed front rack mount kit.
Our Intellex BNC rack mount extension kit provides an
additional option, enabling you to
install the BNC video and alarm
board on the back of the rack and
connect it to Intellex using flexible
extension ribbon cables.
external speakers
Hear as well as see what's happening when you connect these
speakers to your Intellex Ultra, Intellex IP, Intellex DVMS or
Intellex LT system .
2
(1) The Extended Storage Modules are not compatible with Intellex Ultra or Intellex IP.
(2) Audio is enabled only on Premier Editions of Intellex DVMS and Intellex LT.
Intellex
everything you need to complete your
digital video surveillance system.
RAID Storage System
Extended Storage Module
Rack Mount Kits
External Speakers
USB to RS-232 Adapters
External DAT Drive
USB Control Module
Video BNC Looping Kit
400 and 500 GB Disk Upgrade for Intellex
external DAT Drive
Safeguard your previously recorded video by archiving DDS-4
tapes on your system with this external DAT drive.
UsB to Rs-232 Adapters
Capture more data or expand the control of your digital video
management system. Our USB to RS-232 adapters provide the
interface you need to record text from cash registers, ATMs and
video storage.
other devices as well as integrate Intellex with the complete line
of American Dynamics MegaPower
systems. The adapters are available in models with one, four, or
eight RS-232 ports to match your data collection
requirements.
UsB Control Module
Get the tools to control, program, monitor and upgrade
,
1
your American Dynamics SpeedDome
dome cameras. Our USB Control Module lets you operate
SpeedDome Ultra, Optima and Optima LT from Intellex, Network
Client or a PC using all the features of a Touch Tracker
including DirectSet™. You can update firmware via SensorNet
as well as program and ping-test your SpeedDomes without
physically accessing them. Utilities and associated files are
posted at www.americandynamics.net.
Video BNC Looping Kit for Intellex Ultra
Add a matrix switcher or other video accessory without a
distribution amplifier with this looping kit for Intellex Ultra.
Intellex Ultra 400 and 500 GB
Disk Upgrade
Expand the storage of your Intellex Ultra
without opening the chassis by sliding
in a 400 or 500 GB disk drive.
D A T A s h e e T
Accessories
®
Ultra
®
matrix switcher controller
®
programmable
®
®
