Larson Electronics XLE-PA-IP20-CS.50-50A-3PH-250V-3P4W-B Instruction Manual

WARNING:

TO AVOID FIRE, SHOCK, OR DEATH; TURN OFF POWER AT CIRCUIT BREAKER OR FUSE AND
TEST THAT POWER IS OFF BEFORE WIRING

CAUTIONS:

- TO BE INSTALLED AND/OR USED IN ACCORDANCE WITH APPROPRIATE ELECTRICAL
CODES AND REGULATIONS.
- IF YOU ARE UNSURE ABOUT ANY PART OF THESE INSTRUCTIONS, CONSULT AN
ELECTRICIAN.
- USE THIS DEVICE ONLY WITH COPPER WIRE.
- ENSURE THAT LOCKING FLANGED INLET HAS THE PROPER ELECTRICAL RATING FOR THE
SYSTEM ON WHICH IT IS BEING INSTALLED.
- THESE DEVICES ARE FOR GROUNDING CIRCUITS, OR EQUIPMENT GROUNDING ONLY. DO
NOT USE IN NON-GROUNDING APPLICATIONS.
- THE ENCLOSURE USED TO INSTALL THE LOCKING FLANGED INLET MUST BE
APPROPRIATE FOR THE LOCATION BEING SERVED (DRY, WET, DAMP).
NOTE:
WIRE SIZE AND TYPE MUST COMPLY WITH APPROPRIATE LOCAL ELECTRICAL CODES. IN USA
REFER TO NEC TABLES ARTICLE 400.
NOTE:
THE LOCKING FLANGED INLETS ARE DESIGNED TO ACCEPT WIRES FROM #10 AWG TO #4 AWG.

TO INSTALL:

1. WARNING: TO AVOID FIRE, SHOCK, OR DEATH TURN OFF POWER AT CIRCUIT
BREAKER OR FUSE AND TEST THAT POWER IS OFF BEFORE WIRING!
2. Strip insulation of each conductor 3/4" (19.1 mm) per STRIP GAGE molded on the back cover
of the Flanged Inlet.
3. Make sure that stripped wire is clean, and of a bright copper color. If necessary, twist strands of
each stripped conductor tightly. DO NOT TIN CONDUCTORS.
4. NOTE: DO NOT LOOSEN TERMINAL SCREWS.
5. Insert each stripped conductor into proper wiring well per Table 1, and per markings on device.
Check for stray wire strands.
6. Tighten each terminal to 35 in-lb of torque, using a 5/32" Allen wrench. CAUTION: TERMINAL
MUST TIGHTEN ONTO CONDUCTORS, NOT INSULATION.
7. Mount Locking Flanged Inlet on panel cut-out per Figure 1.
Larson Electronics, LLC
California Standard CS8375, Twist-Lock 50-Amp
Male Inlet, 250V Delta 3PH 3P4W, IP20 Instruction
Phone: (800) 369-6671
XLE-PA-IP20-CS.50-50A-3PH-250V-3P4W-B
Manual
Fax: (903) 498-3364 www.larsonelectronics.com
1 of 2
