American Dynamics ADC722WP Specifications

ADC720Series_VS281 3/1/04
FEATURES
•
1/3-inch interline color
imager, NTSC format
•
330-line color imager
•
Sharp picture
•
2.0 lux light sensitivity
•
Sensitive to IR
illumination
•
Discreet housings
3:19 PM Page 1
•
Automatic electronic
shutter
•
Automatic gain control
•
Auto tracing white
balance
•
12 VDC input via
included power supply
•
ADC722WP includes IR
illumination and is
weather resistant
ADC720 Series
COLOR SPECIALTY CAMERAS
The ADC720 Series cameras feature a color
imager that delivers a sharp picture at a very
economical cost.
The ADC720 Series offers cameras in housings
different than your typical standard camera.
The ADC720D features a 3.5-inch discreet
dome housing that is an attractive alternative
to a standard camera.
The ADC721B features a low silhouette tube
design that will fit in with most decors.
The ADC722WP is a weather resistant tube
design that meets IP57 for weather resistance.
The built in IR illumination LEDs allow this
camera to produce a picture with 0 lux ambient
light. The 12 IR LEDs provide coverage up to
10 meters (30 ft) to deliver a sharp picture while
producing no visible light. In low light when
the IR illuminators are operating the camera
electronically switches to black and white.
The ADC723PIR is a camera mounted in a
standard motion detector shell. The camera
blends in to the background appearing as a
security system device. People are unaware that
there is video surveillance in the area.
www.americandynamics.net
