SWEEX BC200010 Manual

English version
BC200010 Sweex Rackmount 19" UPS 1000VA
Introduction
Thank you for buying this Sweex Rackmount 19" UPS. This Sweex Rack-mount 19" UPS works quickly and simply and includes the following
features:
Backup for servers/systems that must not go down without warning.
•
A scheduler to switch the UPS on and off.
•
A scheduler to test the rechargeable batteries.
•
Multilingual software: English, German, Spanish, Italian, French and Portuguese.
•
An e-mail or SMS can be sent in the event of a fault in the mains.
•
Send broadcast messages to a group of users in the event of a fault.
•
We advise you to read this manual carefully first to guarantee correct operation of the Sweex Rack-mount 19" UPS.
Before starting installation, make sure that the operating system is up-to-date. This is simple to check in Internet Explorer by selecting Windows
Update in the Tools menu.
Contents of the packaging
Before installation, check that all the necessary parts are present. The box should contain the following parts:
Sweex Rack-mount 19" UPS
•
This manual
•
Installation CD-ROM with any drivers, software and a comprehensive manual
•
Contact the supplier if any of the above parts is missing.
2 W W W . S W E E X . C O M
Specifications
Model
Capacity W
Input Voltage
Voltage Range Acceptable Voltage Range 0-160VAC / 0-300VAC
Line Low Transfer
Line Low Comeback
Line High Transfer
Line High Comeback
Output Voltage
Voltage Regulation (Batt. Mode)
Frequency
Frequency Regulation (Batt. Mode)
Waveform
Transfer Time Typical
Battery Rack Case Battery Type
Battery Number
Backup Time (at full load)
Recharge Time
Indicators AC Mode
Backup Mode
Boost/Buck
Load/Battery Level
Load/Battery Level
UPS Fault
Overload
Low Battery
Audible Alarm Backup Mode
Low Battery
UPS Fault
Overload
Battery Replacement
Physical Rack Case Dimension (DxWxH) mm 475x482x85
Net weight (kg)
Environment Operating Environment
Noise Level
Interface RS-232 / USB depends of model
English version
1000VA 2000VA 3000VA
600W 2000W 2000W
120VAC or 220/230/240VAC
88VAC ± 4% or 160/168/175VAC ± 4%
95VAC ± 4% or 170/178/198VAC ± 4%
148VAC ± 4% or 260/272/275VAC ± 4%
141VAC ± 4% or 248/260/265VAC ± 4%
120VAC or 220/230/240VAC
±7% RMS for entire battery voltage range
50Hz or 60Hz
±0.5Hz
Pure Sinewave
4-6ms
12V/9Ah 12V/9Ah 12V/7Ah
2 4 8
5 minutes (Typical)
4 hours to 95% after discharged
Green LED lighting
Green LED flashing
Yellow LED lighting
It represents Load Level in AC Mode and Battery Level in Backup Mode
4-segment LED bar- 0-25% : 4th LED lighting
26%-50% : 3rd and 4th LEDs lighting
76%-100% : 4 LEDs in a row all lighting
The 2nd LED in a row of Load/Battery LEDs flashing once every second
and one or more addition load/battery level LEDs lighting
The 1st LED in a row of Load/Battery LEDs flashing once every 0.5 second
and all other load/battery level LEDs lighting
The bottom LED in a row of Load/Battery LEDs flashing every 2 seconds
Sounding every 10 seconds
Sounding every 5 seconds
Sounding continuously
Sounding every 0.5 second
Sounding 2 seconds every 60 seconds
475x482x130 475x482x172**
18 27.2 45.6
0- 40°C, 0-90 % relative humidity (non-condensing)
Less than 45dB
Support Windows 98SE / 2000/ XP
