AmbiCom WL54-PCIe Specifications

Features
• PCI Express Mini Card form factor. (USB 2.0 Mini Card)
• IEEE 802.11b/g compliance.
• Backward compatible with IEEE 802.11b standard.
• Wire-free access to networked resources from anywhere beyond the desktop.
• Delivers data rate up to 54Mbps.
• 802.11g: Dynamically shifts between 54, 48, 36, 24, 18, 12, 9 and 6Mbps network speed, based on
signal strength, for maximum availability and reliability of connection.
• 802.11b: Dynamically shifts between 11, 5.5, 2, and 1Mbps network speed, based on signal strength,
for maximum availability and reliability of connection.
• Allows users move between Access Points without resetting their connection reconfiguration.
• Support antenna diversity.
• Uses 2.4GHz frequency band, which complies with worldwide requirement.
• Fallback rate algorithm that sets the optimum transmission rate based on actual signal-to-noise ratio
and packet loss information
• Support Peer-to-Peer communication among any wireless users, no Access Point required.
• Ensures great security by providing the 64/128-bit Wired Equivalent Privacy (WEP), WIFI Protected
Access (WPA), and AES advances WLAN security defined in the IEEE standard.
AmbiCom 54g PCI Express Mini Card
T
he WL54-PCIe gives you the freedom to work your way, from wherever you
want. The industry standard IEEE 802.11g featuring advanced silicon chip design
and is capable of delivering data transfer rates up to 54Mbps.
802.11g shares the same 2.4GHz frequency band which 802.11b uses. The radio
circuitry and the chip are designed to work with existing 11Mbps 802.11b
equipment installed earlier. Whichever standard is used, WL54-PCIe is ready to
connect.
WL54-PCIe
Model:
