AmbiCom Air2Net BT2000D-CF Product Specifications

Product Specifications:
Model Number
Descriptions
General
Hardware Type
Bluetooth Spec. Compliance
Throughput
Operating Voltage
Power Consumption
Operating Distance
Antenna
Regulatory Approval
Dimensions
Weight
Temperature
Radio
Spread Spectrum
Frequency Range
RF Channels
Polarization
Modulation
Output Power
Receiver Sensitivity
Max Input Level
Power Control
Base Band
Physical Links
Network Capabilities
Link Manager
RSSI
Power Control
Authentication
Encryption
Test Mode
Role Switch (Master/Slave)
BT2000D-CF
Air2Net Bluetooth CompactFlash Card (with PC Card Adapter)
CompactFlash Card Type I Interface
Type II Interface With PC Card Adapter
Ver. 1.1
460 Kbps (Data channels)
3.3V/5V from PC card interface
Standby: 18 mA
Active: 43 mA
>10M for open space
Embedded antenna with 0dBi max. directivity
BQB (Bluetooth v.1.1 Qualified), FCC, ETSI, TELEC, CE
CF Card: 2.03 x 1.65 x 0.31 in (51.6 x 42.8 x 7.87mm)
PC Card Adapter: 3.38 x 2.13 x 0.19 in (85.73 x 54 x 4.76 mm)
CF Card: 23 g (0.8 oz)
PC Card Adapter: 0.1 oz (2.8 g)
Storage temperature: -30°C ~ +85°C
Operating temperature: 0°C ~ +70°C
Frequency Hopping Spread Spectrum (FHSS)
Compliant with FCC part 15
2.4 – 2.4835 GHz (2.4 GHz ISM Band)
79-channel system for USA, Japan, and Europe (except France)
23-channel system for France to be supported later
Linear
GFSK, BT =0.5
4 dBm (Max.)
-70 dBm with BER < 0.1%
-20 dBm
No
Support of ACL link
SCO link will be supported soon
Support of piconet point-to-point and point-to-multipoint
connections
Scatternet to be supported soon
Yes
No
Yes
Yes
Yes
Yes
Page 1 of 2
Rev. 4
