Quick Installation Guide
IEEE 802.11n
Wireless-N USB Dongle
(Read Me First)
Please install the driver before inserting the USB dongle
WiFi Protected Setup (WPS)
Pin-Code (Software WPS) or Push-Button Configuration
Your other existing wireless peripherals must support WPS
feature. After the driver has been installed, simply activate
WPS feature on both devices to automatically configure the
USB adapter wireless network security. See Page 6.
Advertisement
Table of Contents
Related Manuals for AmbiCom P5T-WL150NUSBX
Summary of Contents for AmbiCom P5T-WL150NUSBX
-
Page 1: Quick Installation Guide
Quick Installation Guide IEEE 802.11n Wireless-N USB Dongle (Read Me First) Please install the driver before inserting the USB dongle WiFi Protected Setup (WPS) Pin-Code (Software WPS) or Push-Button Configuration Your other existing wireless peripherals must support WPS feature. After the driver has been installed, simply activate WPS feature on both devices to automatically configure the USB adapter wireless network security. -
Page 2: System Requirements
If you want to use all the features provided by the wireless USB dongle or you are using Windows 2000, please install the “Install driver and AmbiCom Wireless Utility” or “Ralink Configuration Tool” during setup. You will be able to switch to “Microsoft Wireless Zero Configuration Tool”... -
Page 3: Driver Installation
3. Accept the License agreement. Follow the recommended steps below for your specific model. Note: Select “AmbiCom Wireless Utility” or “Ralink Configuration Tool” only if you require certain special features, such as Pin-Code WPS (software WPS) or changing... - Page 4 For all models: Windows 2000 operating system user should select “AmbiCom Wireless Utility” or “Ralink Configuration Tool”. Otherwise, see below: WL250N-USB Select “Install driver and Ralink WLAN Utility” for advance wireless features or “Microsoft Zero Configuration Tool” for simple wireless features.
- Page 5 8. If you have selected “Install driver only” option, double- click the wireless icon appear at the bottom right corner. If your wireless network has been setup with a wireless security code, you will need to type the code to gain access.
- Page 6 If your USB does not comes with a button on the USB dongle, the WPS feature is configure using the “AmbiCom Wireless Utility” or “Ralink Configuration Tool”. Otherwise, simply press the WPS button on both the USB dongle and a WPS capable wireless router devices for 2 seconds (refer to your router manual) to automatically configure the wireless security.
-
Page 7: Technical Support
Disclaimer This product is design for indoor use only. AmbiCom Inc., is not liable for the personal injury and property damage cause by misuse of this product. By using this product, users agree to obey their local regulations, public safety laws, and maintaining safety environment to other user. - Page 8 USA/Canada During the warranty period, AmbiCom, Inc. will, at its option, either repair or replace defective products with similar parts and products. Should the product be identified as defective, the end user is responsible for returning the product to the place of purchase...
- Page 9 However, any implied warranty or merchantability of fitness for a particular purpose is for a period of 1 year on this written warranty. AmbiCom, Inc. reserves the right to change its warranty policy without prior notice. Information provided in this manual is subject to change without prior notice.
- Page 10 Federal Communication Commission - Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 11 Federal Communication Commission (FCC) Radiation Exposure Statement This equipment complies with SAR for general population/uncontrolled exposure limits in ANSI/IEEE C95.1-1999 and had been tested in accordance with the measurement methods and procedures specified in OET Bulletin 65 Supplement C. The equipment version marketed in US is restricted to usage of the channels 1-11 only.
- Page 12 R&TTE Compliance Statement This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE) The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000.
