MAKS Water Quick User Manual

WIRELESS WATER LEAKAGE SENSOR
• secure two-way radio communication with MAKS PRO
• 868,0 ... 868.6MHz, several channels for
redundancy, range up to 2000 m
• power - two lithium batteries AAA, up to 5 years of operation
• no installation required, just put the sensor
on the bathroom floor, under the washing machine
or dishwasher
• 4 contacts to detect water leakage
• accelerometer for flipping detection
Wireless sensor is designed to detect water leakage. The
device sends an alarm notification to the alarm center
MAKS PRO.
No installation required, for indoor use.
Radio communication
The detector transceiver operates in several channels of
868.0 ... 868.6 MHz band for redundancy.
Secure two-way radio communication.
Distance - up to 2000 m in the open space.
Three grades of power, maximum - up to 20 mW.
Setting up
The detector operates only with the
MAKS PRO wireless security system
center, connection to other systems is not provided.
The sensor is connected to the security center and
is configured using the MAKS Setup mobile
application.
Features
Four аdjustable gold-plated contact. Operation of two
or more sensors at the same time is an alarm.
Built-in accelerometer to detect flipping or incorrect
installation.
Sealed case and a temperature sensor.
Batteries
The device uses two AAA batteries
Lithium batteries (FR03)
Alkaline batteries (LR03)
Salt batteries (R03)
Usage allowed
Included
Do not use!
Characteristics
Number of contacts
ISM wireless interface,
up to 2000 m
Power
(battery included)
standby consumption
transmission consumption
service life of battery
Operating temperature range
Dimensions
Case color
Weight
Protection class
For more information on setting up and operating the
device, please visit www.maks.systems
4
868,0... 868,6 MHz
two batteries
AAA (LR03) 3V
no more than 5 µA
up to 50 mA
up to 5 years
-10°С to +55°С
67,5 х 67 х 18 mm
white, black
55 grams
IP65
