INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE APPLIANCE
INSTALLATION MANUAL
Electric 30-inch Wide
PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE
THE MANUAL IS INTENDED TO ASSIST IN THE INITIAL INSTALLATION AND ADJUSTMENTS OF THE RANGE.
SPECIAL WARNING
Only qualified personnel should
install or service this range.
Read "Safety Instructions" in Use &
Care book before using range.
Improper installation, adjustment,
alteration, service, maintenance or
use of range can result in serious
injury or property damage.
CAUTION:
This range has been designed in
accordance with the requirements of various safety
agencies and complies with the maximum allowable
wood cabinet temperatures of 194°F. If this range is
installed with cabinets that have a lower working
temperature than 194°F, discoloration, delamination
or melting may occur.
ENGLISH
ESPAÑOL
FRANÇAIS ' ' ' ' p. 13-18
Your range may not be equipped with some of the features referred to in this
manual.
Free-standing Range
' ' ' ' PP. 1-6
' ' ' ' pág. 7-12
CLEARANCE DIMENSIONS
For complete information in regard to installation of
freestanding range, see figures 1 and 2 on page 2. For
SAFETY CONSIDERATIONS do not install a range in
any combustible cabinetry which is not in accord with the
installation clearances shown in figure 1.
MOBILE HOMES
The installation of a range designed for mobile home
installation must conform with the Manufactured Home
Construction and Safety Standard, Title 24 CFR, Part
3280 (formerly the Federal Standard for Mobile Home
Construction and Safety, Title 24 HUD, Part 280) or,
when such standard is not applicable, the Standard for
Manufactured Home Installations 1982 (Manufactured
Home Sites, Communities and Set-Ups), ANSI
A225.1-latest edition, or with local codes.
LOCATING THE RANGE
Place range in a well lit area. Do not set range over
holes in the floor or other locations where it may be
subject to strong drafts. Any opening in the wall behind
the range and in the floor under the range should be
sealed. Make sure the flow of cooling/ventilation air is
not obstructed below the range.
8101P556-60
(06-03-00)
