Wesco RAIS-N-ROL Operating Instructions And Parts Manual

Description
The Wesco RAIS-N-ROL machinery movers are designed for
safe, easy lifting and transportation of large, bulky loads.
This product is distributed by:
Wesco Industrial Products, LLC
1250 Welsh Road
North Wales, PA 19454
Tel: 215-699-7031 Fax: 215-699-3836
Contact the factory for parts information and
ordering. Visit us on the web at www.wescomfg.com
Specifications
Part # Model #
260086 RNR-2
260091 RNR-2P
260087 RNR-4
260092 RNR-4P
260088 RNR-6
260093 RNR-6P
260097 RNR-6P-RF
260138 RNR-64
260139 RNR-64P
260089 RNR-8
260094 RNR-8P
260090 RNR-10
260095 RNR-10P
Unpacking
When unpacking the Wesco Product, check carefully for
shipping damage and missing parts. If damage has occurred
or any parts are missing, file a claim with the delivering carrier
within 24 hours and notify the dealer from whom the unit was
purchased.
Warranty Repairs
If the unit does not work properly, contact your dealer or the
factory (215-699-7031) for units less than 90 days old.
Non-Warranty Service
If units are older than 90 days, repairs can be made easily on
site with factory supplied parts.
NOTE: Do not send units to the factory for service without
first obtaining a "Return Merchandise Authorization" (RMA)
number from the customer service department. We will not
be responsible for merchandise returned without proper
authorization.
General Safety Information
The Wesco RAIS-N-ROLS are designed for specific
functions. To insure proper use, the following instructions
must be adhered to:
(1) Load Rating: The capacity for a pair of units is shown on
a metal plate attached to the top of the frame. Do not
exceed load rating printed on the metal plate. Always
use caution when using units at or near maximum
capacity.
2,000 Lb/4,000 Lb/6,000 Lb/8,000 Lb/10,000 Lb Capacity
Operating Instructions and Parts Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO RAIS-N-ROL,
Capacity Lift
2,000 lbs./pr. 5" 160 lbs./pr.
2,000 lbs./pr. 5" 167 lbs./pr.
4,000 lbs./pr. 12" 315 lbs./pr.
4,000 lbs./pr. 12" 313 lbs./pr.
6,000 lbs./pr. 12" 359 lbs./pr.
6,000 lbs./pr. 12" 359 lbs./pr.
6,000 lbs./pr. 12" 359 lbs./pr.
6,000 lbs./pr. 12" 359 lbs./pr.
6,000 lbs./pr. 12" 359 lbs./pr.
8,000 lbs./pr. 6" 480 lbs./pr.
8,000 lbs./pr. 6" 475 lbs./pr.
10,000 lbs./pr. 6" 480 lbs./pr.
10,000 lbs./pr. 6" 475 lbs/pr.
RAIS-N-ROL
READ THESE INSTRUCTIONS BEFORE USING.
The Wesco RAIS-N-ROLS are designed for specific
functions. To insure proper use, the following instructions
must be adhered to:
(1) Load Rating: The capacity for a pair of units is shown
on a metal plate attached to the top of the frame. Do
not exceed load rating printed on the metal plate.
Always use caution when using units at or near
maximum capacity.
(2) Units must be connected with load binders before load
is lifted.
(3) Only intended for use in pairs.
(4) Make sure load is centered on forks.
(5) Never move the unit unless the forks are in the lower
position.
Weight
(6) Wesco RAIS-N-ROLS are intended for movement of
loads and are not intended for positioning loads in a
raised position for extended periods of time. Do not
leave units unattended with load in raised position.
(7) If alterations to the RAIS-N-ROL are made Wesco will
void all warranties without exceptions. User made
alterations may result in unsafe conditions during use
of unit.
(8) Do not use units on inclines.
(9) Inspect unit thoroughly, daily, before operating. Make
sure that all attachments and fasteners are completely
tightened.
(10) When units are not in use, they should be completely
lowered and release valve tightened.
(11) Do not operate a damaged unit until it is completely
repaired.
(12) Always remove load before repairing.
(13) WARNING: Units are unstable if handled improperly.
Use caution when moving over uneven floors.
The RAIS-N-ROL is ready to use as shipped. If hydraulic
jack does not operate properly, contact the dealer you
purchased unit from immediately.
Warning: DO NOT ATTEMPT REPAIRS ON ANY NEW
UNIT SHOULD FAILURE OCCUR. DOING SO WILL VOID
THE WARRANTY.
TO POSITION:
(1) With one foot placed securely on padded bar and both
hands firmly gripping handle, position forks of first unit
under load. Make sure load is centered on forks.
(2) Faceplate (rubber) must be in contact with load. Note:
A filler block may be needed as a spacer between the
faceplate and load.
(3) Position second unit in same manner as above on
other end of load.
(4) Connect the two RAIS-N-ROL units with load binders
(available from Wesco).
(5) Two people are required for moving large loads.
General Safety Information
Operation
