I. Panel Description
8
7
1. LCD DISPLAY
2. THERMOCOUPLE SOCKET
3. ON/OFF BUTTON
4. SHIFT BUTTON
5. FUNCTION SELECT SWITCH
1
1
4-20mA
4
mV 1V
12V
6
7
．
_
%
PROCESS
CALIBRATOR
6. NUMERICAL & FUNCTION KEYPAD
7. STAND
8. AC ADAPTOR INPUT SOCKET
9. OUTPUT LEADS
