- Page 2 SquareLED X-tra 40 Bar 12 TILT | ZOOM | SEAMLESS USER MANUAL...
-
Page 3: Table Of Contents
Content INTRODUCTION ....................3 DESCRIPTION ......................3 SAFETY INSTRUCTIONS .................. 3 DMX-512 control connection ................ 4 DMX-512 connection with DMX terminator ......... 4 Operation ......................... 4 Display Menu ....................4 Main functions ....................6 DMX functions and values..............8 CLEANING AND MAINTENANCE ..............11 INSTALLATION .................... -
Page 4: Introduction
INTRODUCTION Thank you for having chosen our LED lighting Unpack the device, inside the box you should find: The fixture device One power cable One XLR connection cable This manual Please check carefully that there is no damage caused by transportation. Should there be any problems, consult your dealer and don’t install this device. -
Page 5: Dmx-512 Control Connection
Make sure the power cord is never crimped or damaged by sharp edges. If this would be the case, replacement of the cable must be done by an authorized dealer. Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle the power cord by the plug. - Page 6 Main menu Sub-menu Level 2 menu Parameter DMX Address 001 - 512 Fixture Ch Mode STD/EXT Run Mode DMX/Host/Sound Tilt Inv Close/Open Manual Tilt 0 - 255 Tilt Fine 0 - 255 0 - 255 0 - 255 0 - 255 Information Time Current Time...
-
Page 7: Main Functions
Main functions 1. address:Current DMX address A.Setting DMX address by button press ENTER button when show the address menu, then adjust the DMX address by pressing [UP] or [DOWN] button Press [ENTER] to confirm or pressing [ESC] to return to main menu. B.Setting DMX address by controller 1.Set the DMX value of channel 5 to 10-15,channel 17 to 20-26, channel 7 to 30-36,channel 8 to 40-46,then the devices connected to the controller will enter to... - Page 8 Key mode press ENTER button when show the key mode menu, then select lock or unlock by pressing [UP] or [DOWN] button Show Temperature press ENTER button when show the Temp Uint CS menu, select the way of showing the fixture’s temperature in ℃ or ℉ by pressing [UP] or [DOWN] button DMX status press ENTER button when show the DMX Status menu, then select clear value or...
-
Page 9: Dmx Functions And Values
7. Auto test press ENTER button when show the auto test menu, select test mode by pressing [UP] or [DOWN] button 8. Factory setting press ENTER button when show the Factory setting menu, adjusting color cablir by pressing [UP] or [DOWN] button DMX functions and values Standard Chanel... - Page 10 252 - 255 turn on 0 - 255 Green 0 - 255 green Blue 0 - 255 blue White 0 - 255 white Inner Effect Built-in effect selection 0 - 10 no effect 11 - 13 Static effect 1 14 - 16 Static effect 2 …...
- Page 11 Extended Chanel Value Function mode(60CH) name Tilt 0 - 255 Vertical rotation TiltFine 0 - 255 Vertical fine-tuning Tilt-Speed 0 - 255 Vertical motor speed Zoom1 0 - 255 Zoom in 1 Zoom2 0 - 255 Zoom in 2 Dimmer 0 - 255 Dimming 8bit DimFine...
-
Page 12: Cleaning And Maintenance
LED2 Blue 0 - 255 LED2 blue LED2 White 0 - 255 LED2 white … … … … … … …… LED12 Red 0 - 255 LED12 red LED12 0 - 255 LED12 green Green LED12 Blue 0 - 255 LED12 blue LED12 0 - 255... - Page 13 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
