Kemot URZ3148 Owner's Manual

With red-ray-through infrared sensor and Lenses, can fast detect the weak infrared ray from body
and automatically start lighting rapidly when some people enter the detection range; the lamp will be
automatically turned off in some certain time after people leave. Very save power and be economic
to the users. It has features of very low consumption, stability and convenient installation.

Application places:

For indoor use only.

Operation instructions:

• Works only when the light intensity is not strong enough, won't be working in the daylight.
• With 30 seconds delaying time.
• Detection distance: 6 m (at parallel 120 degree).
• During installation, make the detection side towards the people moving area, the installation
height and slope can be adjusted , normal installation height: 2-3 m.
• lt enters normal work state after about 40 s. infrared warm-up time for first installation and
switch on power supply. (The lighting lamp may be lightened several times during the 40 s, this
is common phenomena).

Technical Data:

• Working voltage: 230 V-/50 Hz
• Max. power: for incandescent lamp 60 W
for energy-saving lamp 20 W

Installation

Safety issues

1. In relation to device's voltage, make sure to follow safety precautions during mounting,
maintenance and product use.
2. To install:
• make sure the power supply is switched off,
• insert the device with a rotary movement into the lamp frame (chandelier, wall light...),
• insert the lamp with a rotary movement into the device,
• switch on the power supply.
3. To remove the device follow the above steps in reverse order.
4. This item is for indoor use only. It should be installed in the places of aeration and far from high-
temperature source. Make sure to avoid strong sunlight, raining and moisture places
5. The sensor and detection distance will become shorter when the environment temperature
above 38 degrees.
6. „lnfrared sensor and Lenses", Don't cover anything in front of the detection Len(sensor head).
lf the sensor distance becomes short obviously or sensor sensitivity falling condition, clean the
lenses with soft, slightly damp cloth.
English

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems) This marking shown on the
product or Its literature, indicates that It should not be disposed with other household wastes at the end of its working life. To prevent
possible harm lo the environment or human health from uncontrolled waste disposal, please separate this from other types of
wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either
the retailer where they purchased this product, or their local government office, for details of where and how they can take this item
for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase
contract This product should not be mixed with other commercial wastes for disposal.
Made in China for LECHPOL Zbigniew Leszek, Miętne, 1 Garwolińska Street, 08-400 Garwolin.
Lightbulb socket with motion sensor 120° and dusk sensor
EN
Owner's manual
URZ3148
