Heinz Walz KF-24/6B Manual

Cold trap and temperature controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Heinz Walz GmbH • Eichenring 6 • 91090 Effeltrich • Germany
Phone +49-(0)9133/7765-0 • Fax +49-(0)9133/5395
E-Mail info@walz.com • Internet
COLD TRAP
TEMPERATURE CONTROLLER
KF-24/6B
KF-18/2B
MGK-1B
TR-KF-24
TR-KF-18
3rd Edition: August 2011
Coldtrap new-3.doc
© Heinz Walz GmbH, 2011
and
www.walz.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KF-24/6B and is the answer not in the manual?

Questions and answers

Related Manuals for Heinz Walz KF-24/6B

Summary of Contents for Heinz Walz KF-24/6B

  • Page 1 COLD TRAP TEMPERATURE CONTROLLER KF-24/6B KF-18/2B MGK-1B TR-KF-24 TR-KF-18 3rd Edition: August 2011 Coldtrap new-3.doc © Heinz Walz GmbH, 2011 Heinz Walz GmbH • Eichenring 6 • 91090 Effeltrich • Germany Phone +49-(0)9133/7765-0 • Fax +49-(0)9133/5395 E-Mail info@walz.com • Internet www.walz.com...

  • Page 3: Table Of Contents

    1 Safety Instructions ..............1 1.1 General Safety Instructions ................. 1 1.2 Special Safety Instructions ................1 2 General ..................2 2.1 Transport ....................... 2 3 Cold Trap KF-24/6B ..............3 3.1 Installation ..................... 3 3.2 System Description ..................5 3.2.1 Design......................5 3.2.2 Function...................... 7 4 Cold Trap KF-18/2B ..............9...
  • Page 4 8.9.6 PC OFF ....................38 9 Accessories ................39 9.1 WLAN-USB Adapter for Remote Control..........39 10 Maintenance................40 11 Pin Assignment and Fuses............41 11.1 Connectors of KF-24/6B ................41 11.2 Connectors of KF-18/2B ................41 11.3 Connectors of MGK-1B ................42...
  • Page 5 CONTENT 11.4 Fuses and Connectors of TR-KF-24............43 11.5 Fuses and Connectors of TR-KF-18............44 12 Technical Data ................45 12.1 Cold Trap KF-24/6B..................45 12.2 Cold Trap KF-18/2B..................46 12.3 Measuring Gas Cooler MGK-1B..............47 12.4 Temperature Controller TR-KF-24............. 48 12.5 Temperature Controller TR-KF-18.............

  • Page 7: Safety Instructions

    SAFETY INSTRUCTIONS CHAPTER 1 Safety Instructions General Safety Instructions Read the safety instructions and the operating instructions first. Pay attention to all the safety warnings. Keep the device away from water or high moisture areas. Keep the device away from dust, sand and dirt. Always ensure there is sufficient ventilation.

  • Page 8: General

    CHAPTER 2 GENERAL General The Cold Traps KF-24/6B, KF-18/2B, and the Measuring Gas Cooler MGK-1B are suitable for cooling gas to a predetermined dew-point, so that excess humidity condenses. In this capacity the devices can be used in the following applications:...

  • Page 9: Cold Trap Kf-24/6B

    4) Connector for Temperature Controller TR-KF-24 5) Pt 100 The Cold Trap KF-24/6B may be operated indoors as well as in the field. In the field, the user has to ensure that the device is sheltered from the effects of the weather.
  • Page 10 CHAPTER 3 COLD TRAP KF-24/6B The cold trap must stand upright to enable the condensate to drain off freely into the hose connected as condensate collector. Note: The hose must hang free or be arranged so that it can be filled with condensate, without forming air bubbles.

  • Page 11: System Description

    COLD TRAP KF-24/6B CHAPTER 3 System Description 3.2.1 Design Fig. 2: Cross-section through the Cold Trap KF-24/6B 1) Perspex inserts 2) Platinum temperature sensor Pt 100 3) Peltier elements 4) Heat exchanger for liquid cooling 5) Air heat exchanger 6) Condensate drain...
  • Page 12 CHAPTER 3 COLD TRAP KF-24/6B The interior part (7) of the cold trap KF-24/6B is thermostated by the Peltier elements (3). It has two boreholes for the gas conduit. At the lowest point of this gas conduit there is a condensate drain (6). The condensate collects here and runs into the condensate hose.

  • Page 13: Function

    3.2.2 Function The Temperature Controller TR-KF-24 is used to set the desired dew-point temperature of the Cold Trap KF-24/6B. It supplies the power to the Peltier elements in such a way that the temperature of the interior part is adjusted to the set dew-point temperature.
  • Page 14 CHAPTER 3 COLD TRAP KF-24/6B The diagram below (Fig. 3) shows the cooling time at ambient tem- perature +40 °C down to -1 °C. Fig. 3: Cooling time from +40 °C to -1 °C for a gas flow of 20 l/min...

  • Page 15: Cold Trap Kf-18/2B

    COLD TRAP KF-18/2B CHAPTER 4 Cold Trap KF-18/2B Installation The Temperature Controller TR-KF-18 and the external AC Power Supply 3020-N are required for the operation of the Cold Trap KF- 18/2B. The Cold Trap KF-18/2B can be operated indoors as well as in the field.
  • Page 16 CHAPTER 4 COLD TRAP KF-18/2B At the front side of the cold trap is a condensate hose with drain cock connected. Also at the front side is the gas outlet (OUT). The gas inlet is located on the top of the cold trap (Fig. 4). A 9-pin jack for the connection of the temperature controller is lo- cated at the back of the housing beneath the fan.

  • Page 17: System Description

    COLD TRAP KF-18/2B CHAPTER 4 System Description 4.2.1 Design Fig. 5: Cross-section through Cold Trap KF-18/2B 1) Perspex gas connection 2) Gas outlet 3) PU-foam 4) Gas conduit 5) Condensate drain 6) Housing 7) Interior part 8) Peltier elements 9) Heat exchanger 10) Round jack 11) Fan 12) Temperature sensor Pt 100...
  • Page 18 CHAPTER 4 COLD TRAP KF-18/2B The interior part (7) of the cold trap KF-18/2 is thermostated by the Peltier elements (8). It has two boreholes for the gas conduit (4). At the lowest point of this gas conduit there is a condensate drain (5). The condensate collects here and runs into the condensate hose.

  • Page 19: Function

    COLD TRAP KF-18/2B CHAPTER 4 4.2.2 Function The Temperature Controller TR-KF-18 is used to set the desired dew-point temperature of the Cold Trap KF-18/2B. It controls the supplied power in such a way that the Peltier elements cool the inte- rior part to the set dew-point temperature.
  • Page 20 CHAPTER 4 COLD TRAP KF-18/2B If the measuring gas cooler operates continuously at dew-point tem- peratures below 0 °C, the conduits may freeze, depending on the quantity and humidity of the gas. To defrost the unit, switch off the controller. Alternatively, the dew-point may be set to 10°C above ambient temperature.

  • Page 21: Mesuring Gas Cooler Mgk-1B

    MEASURING GAS COOLER MGK-1B CHAPTER 5 Measuring Gas Cooler MGK-1B Installation The Temperature Controller TR-KF-18 and the external AC Power Supply 3020-N are required for the operation of the Measuring Gas Cooler MGK-1B. The Measuring Gas Cooler MGK-1B can be operated in indoors as well as in the field.
  • Page 22 CHAPTER 5 MEASURING GAS COOLER MGK-1B The measuring gas cooler must stand upright to enable the conden- sate to drain off freely into the silicon hoses connected as condensate collectors. For this purpose, the rear feet are slightly higher than the front ones, thus enabling the condensate to flow forwards into the direction of the condensate hose.

  • Page 23: System Description

    MEASURING GAS COOLER MGK-1B CHAPTER 5 System description 5.2.1 Design Fig. 8: Cross-section through the measuring gas cooler MGK-lB 1) Gas connector 2 2) PU-foam 3) Gas conduit 2 4) Condensate drain 2 5) Housing 6) Interior part 7) Peltier elements 8) Heat exchanger 9) Fan 10) Gas connector 1...

  • Page 24: Function

    CHAPTER 5 MEASURING GAS COOLER MGK-1B The temperature of the interior part (6) is controlled by Peltier ele- ments (7). It has four boreholes (3 and 11) for the two gas conduits. Each gas conduit has a condensate drain (4 and 12) at its lowest point, from where the condensate runs into the condensate hoses.
  • Page 25 MEASURING GAS COOLER MGK-1B CHAPTER 5 For further information, see function of Cold Trap KF-24/2B (chap- ter 2.2.2). The following figure (Fig. 9) shows the cooling time for +30°C down to -7°C. Fig. 9: Cooling time for +30 °C down to -7 °C for a gas flow of 1 l/min per If the measuring gas cooler operates continuously at dew-point tem-peratures below 0 °C, the conduits may freeze depending on the...
  • Page 26 CHAPTER 5 MEASURING GAS COOLER MGK-1B flow rate and humidity of the gas. To defrost the unit, switch off the controller or set a dew-point to 10°C above ambient temperature. Switch off the gas flow during defrosting. If the measuring gas cooler is used at the inlet of gas analyzers for pre-drying of measuring and reference gas, the temperature should be set to +2 °C.

  • Page 27: Temperature Controller Tr-Kf-24

    Fig. 11: Back side of Temperature Controller TR-KF-24 The Temperature Controller TR-KF-24 is designed to control the Cold Trap KF-24/6B. It provides power to the cold trap as required to reach the desired dew-point temperature. It comprises two slide-in modules: The control unit with panel-PC and the power supply unit (Fig.
  • Page 28 CHAPTER 6 TEMPERATURE CONTROLLER TR-KF-24 Fig. 12: Panel-PC of Temperature Controller TR-KF-24 with USB connectors and power button Fig. 13: TR-KF-24: Connectors and power switch at the back-side. The power button underneath the display on the front of the panel turns on the panel-PC only.
  • Page 29 TEMPERATURE CONTROLLER TR-KF-24 CHAPTER 6 The connector for the Cold Trap KF-24/6B and the main switch are located at the back side of the housing. After the cold trap and the temperature controller are set-up and connected, the main switch can be engaged.

  • Page 30: Temperature Controller Tr-Kf-18

    CHAPTER 7 TEMPERATURE CONTROLLER TR-KF-18 Temperature Controller TR-KF-18 System description Fig. 14: Temperature Controller TR-KF-18: Front side Fig. 15: TR-KF-18: Connectors at the back side...
  • Page 31 TEMPERATURE CONTROLLER TR-KF-18 CHAPTER 7 The Temperature Controller TR-KF-18 may be used to operate the Cold Trap KF-18/2B or the Measuring Gas Cooler MGK-1B. It con- trols the power supplied to the cold trap as required to reach the de- sired dew-point temperature.

  • Page 32: Operation

    CHAPTER 8 OPERATION Operation General The Temperature Controller TR-KF-18 and TR-KF-24 comprise an integrated panel-PC for operation. The panel-PCs of both versions operate in the same way with the TR-KF-Control Program and are therefore described together. The panel-PC has a graphical display and a convenient touch panel. Self explanatory buttons allow fast operation.

  • Page 33: Virtual Keyboard

    OPERATION CHAPTER 8 Virtual Keyboard The virtual keyboard serves for the input of number or letters. Fig. 16: Virtual keyboard from accessed keyboard icon that automatically appears if the cursor is close to an input field (Fig. 17). Fig. 17: Keyboard icon To change the position of the keyboard, place the touch pen at its upper border.

  • Page 34: Main Window

    CHAPTER 8 OPERATION Main Window The main window appears after the instrument has been started. Fig. 18: Main window 1) Yellow field: Internal temperature, and set temperature. 2) Blue field: Values for external control 3) Picture buttons: Set-value, control start/stop, chart settings, settings and menu 4) Status button 5) Chart 1: Overview-chart showing up to 1860 data points with...

  • Page 35: Protocol & Status

    OPERATION CHAPTER 8 Protocol & Status All important events are displayed in the status button and listed in a protocol. The protocol can be accessed by pressing the status button. Fig. 19: Protocol Window The system constantly performs function checks. If an error occurs, the green status button turns yellow and displays a message;...

  • Page 36: Control Start / Stop

    CHAPTER 8 OPERATION Control Start / Stop The green start-button and the red stop-button serve to start or stop the temperature control, respectively. Chart Settings The chart button leads to the chart settings. Fig. 20: Chart Settings Chart 1, 2 and 3 show the set-value with a blue line (labeled: Set) and the actual internal temperature with a red line (labeled: Int.).

  • Page 37: Touch Pen Options: Chart 2 And Chart 3

    OPERATION CHAPTER 8 8.7.1 Touch Pen Options: Chart 2 and Chart 3 The scales of chart 2 and chart 3 can be changed by moving the touch pen over the chart area. The chosen option determines the function of the move- ment: Panning: Movement up/down or left/right will shift the re- spective scale.

  • Page 38: Scale: Chart 1

    CHAPTER 8 OPERATION 8.7.3 Scale: Chart 1 The temperature scale of chart 1 can be changed individually for the set-value (Set) and the measured temperature value (Int.). By choosing "Auto" the temperature will be scaled automatically, so that all measured data are shown in chart 1.

  • Page 39: Screen Brightness

    OPERATION CHAPTER 8 8.8.1 Screen Brightness With the sun button the brightness of the display can be adjusted. 8.8.2 Temperature Regulation Usually the option "Intern" is chosen, mean- ing that the temperature shall be regulated to the internal set-value, entered by the user via the software.

  • Page 40: Dew-Point Calibration

    Entering an offset, per- forming a calibration or overwriting the calibration values with fac- tory settings. A calibration reference for humidity determination (e.g. a dew-point mirror) is required. You may send the device to the Heinz Walz GmbH for recalibration. 8.8.5.1 Offset The offset button can be used for a simple adjustment of the indicated temperature.

  • Page 41: Factory Value

    OPERATION CHAPTER 8 When the calibration temperature has been entered, the temperature regulation starts automatically, whereby the entered calibration tem- perature is used as set-value. When the set-value is reached and stable and also the reference in- strument indicates a stable value, the calibration is continued by pressing the yellow status button.

  • Page 42: Start-Up Sequence

    CHAPTER 8 OPERATION 8.8.6 Start-up Sequence The start-up sequence determines how the temperature controller resumes opera- tion after an interruption of power supply. With the option off, the temperature con- trol will remain in standby mode. If the option "Momentary Value" is chosen, the last set-value will be used for the resumption of temperature control.

  • Page 43: Protocol

    OPERATION CHAPTER 8 8.9.2 Protocol The protocol window can also be accessed with the status button and has been explained above. 8.9.3 Settings The settings window can also be accessed with a picture button and has been explained above. 8.9.4 Service The service window is for factory use only.

  • Page 44: St-Control Update

    CHAPTER 8 OPERATION After pressing the button "Factory value" an additional window will open. Choose the filename with the extension ".fac" and then press "open" to load the file. 8.9.5.3 ST-Control Update The button "ST-Control" allows an update of the firmware via an external USB stick.

  • Page 45: Accessories

    ACCESSORIES CHAPTER 9 Accessories WLAN-USB Adapter for Remote Control The temperature controllers can be controlled remotely with an ade- quate WLAN-USB-Adapter (type: EDIMAX EW7711Uxx) via the "Remote Desktop Connection" function of the external PC (Start / Programs / Accessories / Communications). Fig.

  • Page 46: Maintenance

    CHAPTER 10 MAINTENANCE 10 Maintenance Additional maintenance work is normally not necessary. For maintaining and cleaning of the housings a mild cleaning agent can be used. A suitable non-aggressive cleaning agent (e.g. 50% ethanol) can be pumped through the gas conduits for cleaning. The gas conduit must be dried afterwards.

  • Page 47: Pin Assignment And Fuses

    PIN ASSIGNMENT CHAPTER 11 11 Pin Assignment and Fuses 11.1 Connectors of KF-24/6B "TR-KF-24" 1: Shielding 2: Peltier + 3: Peltier – 6: Fan + 7: Fan – 12: Temp Int. 0- 4095 mV 13: + 5V 14: GND 15: Peltier + 16: Peltier –...

  • Page 48: Connectors Of Mgk-1B

    CHAPTER 11 PIN ASSIGNMENT 11.3 Connectors of MGK-1B "TR-KF-18" 14 / 1: Shielding 15 / 2: Peltier + 16 / 3: Peltier – Fan +12V 17 / 5: Fan – 19 / 7: Pt 100 20 / 8: Pt 100 Temp Int.
  • Page 49 PIN ASSIGNMENT CHAPTER 11 11.4 Fuses and Connectors of TR-KF-24 The housing of the TR-KF-24 bears one fuse: "10AM": Medium blow 10 A. "KF-24/6B" a1: PE b1 a1 a2: Peltier + b2 a2 a3: Peltier – b3 a3 a6: Fan + b4 a4 a7: Fan –...
  • Page 50 CHAPTER 11 PIN ASSIGNMENT 11.5 Fuses and Connectors of TR-KF-18 The housing of the TR-KF-18 bears three fuses: "F1:8AT": Slow blow 8 A "F2:8AT": Slow blow 8 A "F3:4AM": Medium blow 4 A "DC Power 14-17V" 1: +14..17 V 1 or 2 2: GND 3: +14..17 V 4: GND...
  • Page 51 TECHNICAL DATA CHAPTER 12 12 Technical Data 12.1 Cold Trap KF-24/6B One gas path Maximal gas flow rate: 25 l/min Material of gas conduit: aluminium anodized, Perspex, PVC and nickel-plated brass Air volume of gas cooler: 256 ml (w/o condensate drain) Temperature range: -50 to 70°C...
  • Page 52 CHAPTER 12 TECHNICAL DATA 12.2 Cold Trap KF-18/2B One gas path Maximal flow rate: 6 l/min Material of gas conduit: aluminium anodized, Perspex, PVC and nickel-plated brass Air volume of gas cooler: 55 ml (w/o condensate drain) Temperature range: -50 to +70 °C Accuracy: ±0.1 °C Cooling:...
  • Page 53 TECHNICAL DATA CHAPTER 12 Measuring Gas Cooler 12.3 MGK-1B Gas paths two, pneumatically separated Maximal flow rate: 1.5 l/min per path Material of gas conduit: aluminium anodized, PA6, silicone and nickel-plated brass Air volume of gas cooler: 20 ml (w/o condensate drain) Temperature range: -30 to +70 °C Accuracy:...
  • Page 54 CHAPTER 12 TECHNICAL DATA Temperature Controller TR-KF-24 12.4 Controller: Panel-PC Display: SVGA graphics display (640 x 480) with touch panel Ext. analog input: 0V to 10V => -50°C to 70°C Ext. analog output: 0V to 10V => -50°C to 70°C Panel-PC connectors: 2 x USB, RS485 Operating temperature: -20°C to 50°C...
  • Page 55 The warranty is subject to the following conditions: 1. This warranty applies if the defects are called to the attention of Heinz Walz GmbH, Germany, in writing within one year (1) of the shipping date of the product. 2. This warranty shall not apply to any defects or damage directly...
  • Page 56 3. All products being returned for warranty service must be care- fully packed and sent freight prepaid. 4. Heinz Walz GmbH, Germany is not responsible or liable, for missing components or damage to the unit caused by handling during shipping. All claims or damage should be directed to the...
