SPEEDY basic
Operating instructions
WM-020-379-10-en BA Speedy basic S M L X Y
Manufacturer:
STARK Spannsysteme GmbH
Roemergrund 14
6830 Rankweil
Austria
Tel.: +43 55 22 37 400-0
Fax: +43 55 22 37 400-700
E-mail: info@stark-inc.com
www.stark-inc.com
SPEEDY basic S / M / L / X / Y
Art. No.: 8000 001 - 8000 ...
Advertisement
Table of Contents
Related Manuals for Roemheld SPEEDY basic S
Summary of Contents for Roemheld SPEEDY basic S
- Page 1 SPEEDY basic Operating instructions WM-020-379-10-en BA Speedy basic S M L X Y SPEEDY basic S / M / L / X / Y Art. No.: 8000 001 - 8000 … Manufacturer: STARK Spannsysteme GmbH Roemergrund 14 6830 Rankweil Austria Tel.: +43 55 22 37 400-0...
-
Page 2: Table Of Contents
Description of fast closing clamping device ....................7 General ................................7 Mounting and installation ..........................7 5.2.1 SPEEDY basic S / M / L / X ........................7 5.2.2 SPEEDY basic L ............................9 Removal of fast closing clamp .......................... 9 Start-up, operating and operation ........................ -
Page 3: Identification Of The Partly Completed Machinery
Optional: With blow-out and mount control Function: Clamping and centring workpiece pallets Product group: Speedy basic S / M / L / X / Y Article number: 8000 001 to 8000 … Trade name: As per product group, see above 3 User information 3.1 Purpose of the document... -
Page 4: Essential Safety Instructions
_BA Speedy basic S M L X Y WM-020-379-10-en .DOCX 4.3 On the use of rotating machine 4 Essential safety tools instructions On usage in a rotating application the fast closing clamp is only allowed to be 4.1 Proper use... -
Page 5: Spare Parts, Wear Parts And Auxiliary Materials
_BA Speedy basic S M L X Y WM-020-379-10-en .DOCX 4.5 Spare parts, wear parts and 4.7.1 Spring assembly auxiliary materials If the fast closing clamp is dismantled incorrectly, the internal pre-tensioned Only retractable nipples manufactured by spring assembly may cause damage or Stark Spannsysteme GmbH may be used even injuries. -
Page 6: Hazard Due To Overpressure
_BA Speedy basic S M L X Y WM-020-379-10-en .DOCX 4.7.3 Hazard due to overpressure 4.7.6 Aspects that may affect service Pipes or hoses bursting due to overpressure can place personnel and life the environment at risk. The service life may be affected by:... -
Page 7: Description Of Fast Closing Clamping Device
There are corresponding retractable nipples on the means of clamping; these are used for quick set-up. While machining is in progress on one pallet, the others can be set-up. 5.2 Mounting and installation 5.2.1 SPEEDY basic S / M / L / X Screws DIN 7984 or for X DIN 912 included... - Page 8 _BA Speedy basic S M L X Y WM-020-379-10-en .DOCX 1. Check the installation contour for Speedy basic for dimensional accuracy and surface finish. Important: The transition from the chamfer to the centre bore must be free of burrs; otherwise the O- ring may be damaged (leaks and failure of the fast closing clamp).
-
Page 9: Speedy Basic L
_BA Speedy basic S M L X Y WM-020-379-10-en .DOCX 5.2.2 SPEEDY basic L The same instructions as described in 5.2.1 apply, however the SPEEDY basic Y is screwed into the plate using a central external thread. It is recommended to use the spanner for installation for this purpose;... -
Page 10: Start-Up, Operating And Operation
_BA Speedy basic S M L X Y WM-020-379-10-en .DOCX 6 Start-up, operating and operation 6.1 Putting in operation for the first time Visually inspect the entire machine and the fast closing clamps Instruct unauthorised personnel to leave the machine... -
Page 11: Servicing And Maintenance
_BA Speedy basic S M L X Y WM-020-379-10-en .DOCX 7 Servicing and maintenance 7.1 Function check Check the SPEEDY for correct function. With the SPEEDY released, check the recess of all balls. If the retractable nipple cannot be inserted and removed from the locating bore without the use of force then immediate servicing is required from Stark Spannsysteme GmbH. -
Page 12: Cleaning
_BA Speedy basic S M L X Y WM-020-379-10-en .DOCX 7.3 Cleaning In principle, soiling inside the fast closing clamp is not allowed. Clean depending on the application and change interval. Well-established practice! The fast closing clamp may be blown out and off using compressed air. -
Page 13: Storage
_BA Speedy basic S M L X Y WM-020-379-10-en .DOCX 7.5 Storage: Before first-time use: If you do not use the fast closing clamp immediately, please store it in the original packaging dry and dust-free. Extended storage after usage: Before storing, clean the fast closing clamp (see chapter "Generalreinigung 8.4") and carry out corrosion protection measures. -
Page 14: Specifications
_BA Speedy basic S M L X Y WM-020-379-10-en .DOCX 8 Specifications basic SH basic SP basic MH basic MP basic LH basic LP Maintenance interval of spring 80,000 80,000 80,000 80,000 80,000 80,000 assembly Retention force 1) [ N ]... -
Page 15: Manufacturer's Declaration
Verantwortung, dass das Produkt Type: SPEEDY basic S / M / L / X / Y 8000 001 - 8000 … to which this declaration relates corresponds to the following standards auf das sich diese Erklärung bezieht, mit den folgenden Normen übereinstimmt...
