BZB Gear BG-CHA User Manual

CONNECTION DIAGRAM
Camcoder DSLR Camera
HDMI CABLE
USB 3.0
LIVE
Laptop
USB PIN DEFINITION
P1
VBUS 1
D- 2
D+ 3
GND 4
SSRX- 5
SSRX+ 6
GND 7
SSTX- 8
SSRX+ 9
Shield SHELL
WARRANTY
BZBGEAR wants to assure you peace of mind.
We're so confident in the quality of our products
that along with the manufacturer's one-year
limited warranty, we are offering free second-year
warranty coverage upon registration*.
PS4
Taking advantage of this program is simple,
just follow the steps below:
1. Register your product within 90 days of
purchase by visiting BZBGEAR.com/warranty.
2. Complete the registration form. Provide all
necessary proof of purchase details, including
serial number and a copy of your sales receipt.
For questions, please call 1.888.499.9906 or
email support@bzbgear.com.
For complete warranty information, please
visit BZBGEAR.com/warranty or scan the QR code
below.
P2
1
2
*Terms and conditions apply. Registration is
3
required.
4
5
6
7
8
9
SHELL
BG-CHA
USB 3.1 Gen 1 Full HD Video Capture Device
with Scaler and Audio
User Manual
INTRODUCTION
The BG-CHA USB 3.1 Gen 1 Full HD Video
Capture Device with Scaler and Audio provides a
professional way to capture HDMI video signals. It
adopts USB 3.1 Gen 1 (USB 3.0) interface, which can
realize high-speed transmission. Users can capture
Full HD (1080p60) video by this capture device.
Besides, BG-CHA can capture and display original
uncompressed HDMI video with more realistic color
rendition. BG-CHA also uses large volume image
buffer technology which effectively avoids the video
tearing. The high sampling rate and high sampling
accuracy assure images with high sharpness, rich
details, and less color edges.
