- Page 1 BG-C2HA USB 3.0 Full HD Video Capture Device with HDMI 2.0a Loop Out & Audio User Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ......................... 1 FEATURES ..........................1 PACKAGE CONTENTS ......................1 SPECIFICATIONS ........................2 PANEL DESCRIPTIONS ......................3 CONNECTION DIAGRAM ......................3 VIDEO STREAMING ........................4 TROUBLESHOOTING ......................13 USB PIN DEFINITION ......................14 WARRANTY ..........................15 MISSION STATEMENT ......................16... -
Page 3: Introduction
INTRODUCTION The BG-C2HA USB 3.0 Full HD Video Capture Device with HDMI 2.0a Loop Out & Audio provides a professional way to capture HDMI video signals. It utilizes the USB 3.0 interface to achieve high-speed transmission. Additionally, the HDMI input and Loop Out can support up to 4K2K@60. With this device, users can connect to a 4K2K@60 source and capture Full HD (1080p60) video. -
Page 4: Specifications
SPECIFICATIONS Model Name BG-C2HA Technical Role of usage Video Capture Device Input Video bandwidth Single-link 600MHz [18Gbps] Output Video bandwidth Up to 350MBps (USB) Video support(USB) Up to 1080p60 Video support(Loopout) Up to 4K2K60 HDMI Embedded Audio & Stereo audio Input... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS 1. HDMI IN: Connect to a HDMI source 2. LED INDICATOR: Input signal indicator LED 3. STEREO AUDIO IN: Connect to analog stereo audio source 4. Micro-USB Port: Connect to the +5V DC power supply unit 5. STEREO AUDIO OUT: Audio extracts from HDMI input 6. -
Page 6: Video Streaming
VIDEO STREAMING Create a Video Stream Users can create video streams on the streaming service platform of choice. The below steps show how to complete the video streaming settings from Twitch and YouTube. Twitch 1. Browse the Twitch website (https://www.twitch.tv/) and log in, then select "Creator Dashboard" from your account drop-down menu at the top right of the screen. - Page 7 3. Go back to Twitch and select "Channel" from your account drop-down menu. 4. At this point, you will see the player start live streaming.
- Page 8 YouTube 1. Browse the YouTube website (https://www.youtube.com/) and log in, then lick "Go live" from the "Create" icon menu at the top right of the screen. * If your account is using YouTube for the first time to create a video stream, you need to wait 24 hours to enable the function.
- Page 9 3. You will see "Stream key" from the “STREAM SETTINGS” below. Copy the "Stream key" and paste it into the "Stream Key" field in the OBS, then click "Start Streaming" in the software. * Please refer to steps 4-6 of the OBS software control program. 4.
- Page 10 5. The player on YouTube will start live streaming.
- Page 11 Stream and record videos with OBS OBS is a popular USB capture freeware and has excellent compatibility. Please start with OBS if users are not familiar with USB capture devices. Download the software Browse the download page of the OBS official website (https://obsproject.com/download), then select the suitable computer operating system and start downloading.
- Page 12 1. First, find the "Scenes" window, click "+" in the lower left corner, and then enter the name of the scene to create a new scene. 2. Find the "Source" window, click "+" in the lower left corner, and then select "Display Capture" or "Video Capture Device"...
- Page 13 4. Click "Settings" and then select "Stream" to perform streaming settings. Users can choose service providers, including Twitch, YouTube, etc. 5. Paste the stream key provided by the service provider into the "Stream Key" field, then click "Apply" and "OK" after setting.
- Page 14 7. On the other hand, users can also click "Start Recording" to record videos with OBS. Besides, you can click "Settings" and then select "Output" to set “Recording Path” and “Recording Format”. ○ The procedures the manual demonstrates are based on the interface that each website provides at the time when the manual is written.
-
Page 15: Troubleshooting
TROUBLESHOOTING Our USB device has been subjected to rigorous tests before shipping. Most of the incompatibilities we have experienced are not from the USB capture device itself, but from the sophisticated software and hardware combinations of PCs or laptops. Please try the following suggestions- OBS is a popular USB capture freeware and has excellent compatibility with most devices. -
Page 16: Usb Pin Definition
USB PIN DEFINITION VBUS SSRX- SSRX+ SSTX- SSRX+ Shield SHELL SHELL -14-... -
Page 17: Warranty
WARRANTY BZBGEAR wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*. Taking advantage of this program is simple, just follow the steps below: 1. -
Page 18: Mission Statement
MISSION STATEMENT BZBGEAR manifests from the competitive nature of the audiovisual industry to innovate while keeping the customer in mind. AV solutions can cost a pretty penny, and new technology only adds to it. We believe everyone deserves to see, hear, and feel the advancements made in today’s AV world without having to break the bank.
