- Page 1 Quick Start Guide Speakerphone SP-2000 Use at Home, Office or Traveling CA P/N: SP-2000 Rev. A00 www.CyberAcoustics.com 2021-03...
- Page 2 In the Package Quick Start Guide Speakerphone SP-2000 Use at Home, Office or Traveling CA P/N: SP-2000 Rev. A00 www.CyberAcoustics.com 2021-03 Quick Start Guide USB Type C to A Cable Note: The USB Type C to A Cable is packed under the inner tray inside the box.
-
Page 3: Table Of Contents
Table of Contents Pages Using the Speakerphone Getting Started - USB Connection Getting Started - Bluetooth Connection Lights Controls Technical Specifications Frequently Asked Questions 9,10,11 Customer Support Safety and Precautions Compliance Information 14,15... -
Page 4: Using The Speakerphone
Using the Speakerphone Best for Use In Home - Office - Traveling / USB Page 1... -
Page 5: Getting Started - Usb Connection
Getting Started - USB Connection The CA Essential Speakerphone can be used with a Bluetooth connection to your device or USB connection to your Windows 10 PC or Mac. USB connection - Using with a PC or Mac - Insert the USB Type A end of the Cable into the USB Type A port on your computer. -
Page 6: Getting Started - Bluetooth Connection
Getting Started - Bluetooth Connection - Step 1 Before you start, please fully charge the CA Essential Speakerphone. (See Page 2 - USB Connection) - Turn on the CA Essential Speakerphone by pressing the Power button. - Toggle Source Button to Bluetooth source - Source Light will be lit Blue. Soure Light Flashing Blue - The CA Essential Speakerphone is ready to pair and connect. - Page 7 Getting Started - Bluetooth Connection - Step 2 With your iPhone, iPad/Tablet, Smartphone - Go to Settings > Bluetooth, check Bluetooth is on - Select 'CA Essential SP' when it appears under DEVICES - Your device will connect in a few seconds - The Source Light will turn solid blue and there will be a quiet chime - The CA Essential Speakerphone is ready to use Note: Your Smartphone or Tablet instructions may vary...
-
Page 8: Lights
Lights Volume LED Indicator - Volume level Indicator Light - Lights are lit solid White (1 to 4 Lights) - Mic (Voice) Indicator Light when call is active - Lights will flash White (1 to 4 Lights) - Mic Muted - Lights are lit solid Red (All 4 Lights) Zoom Meeting/Phone Functionality - Meeting Invite or Incoming Call - Lights will flash Red - Meeting or Call in Progress - Lights will be lit solid Red... -
Page 9: Controls
Controls Call Button Bluetooth Connection to iPhone or Smartphone - Press to accept an incoming call or Press and Hold for 2 seconds to reject call. - During the call, Press to hang up call. USB Connection to PC or Mac for Zoom Meeting/Phone (Not supported for other Applications) - Press to accept a meeting invite or call. - Page 10 Controls Auto Power - The CA Essential Speakerphone will not auto power off when connected to a power source or connected to a PC or Mac - The CA Essential Speakerphone will auto power off within 15 minutes when the Bluetooth is disconnected and using Battery power.
-
Page 11: Technical Specifications
Technical Specifications Specifica�ons Power: • 5V / 1A - Power Source • 5W when playing music • Speaker: 20 - 20,000Hz Frequency response • Microphone: 100 - 16,000Hz • Speaker: 4 ohms Impedance • Microphone: 2.2k ohms Recommended system requirements Supported opera�ng system Windows 10, Mac OS X 10.4.11 or higher Opera�ng temperature... -
Page 12: Frequently Asked Questions
Frequently Asked Questions Frequently Asked Ques�ons Possible Solu�ons Bluetooth connec�on • Turn off the speaker. Can’t connect for the first �me • Check your Bluetooth source device and be sure you have found the sec�on that allows you to discover new Bluetooth products. If you see the speaker on the list, but cannot connect, you may need to try and synch again. - Page 13 Frequently Asked Questions Frequently Asked Ques�ons Possible Solu�ons • In the search box on the taskbar, type control panel, then select it from the results. USB connec�on • Select Hardware and Sound from the Control Panel, and then select Sound. Windows 10: •...
- Page 14 Frequently Asked Questions Frequently Asked Ques�ons Possible Solu�ons - Check the computer’s volume level. USB connec�on Speakerphone does not have sound / - Check proper sea�ng of cable connec�on. Microphone is not working - Verify the applica�on se�ngs you are using. Some applica�ons have separate volume level control.
-
Page 15: Customer Support
Customer Support If you have a question about your CA Essential Speakerphone, our Customer Service Team wants to assist you. Contact us at: www.cyberacoustics.com/support/contact Page 12... -
Page 16: Safety And Precautions
- Do not expose to excessive heat (e.g. from storage in direct sunlight, fire or the like). 2021 Cyber Acoustics or its subsidiaries. All rights reserved. Cyber Acoustics and other trademarks are trademarks of Cyber Acoustics or its subsidiaries. Other trademarks may be trademarks of their respective owners. -
Page 17: Compliance Information
Unique Identifier: (SP-2000) Responsible Party - Cyber Acoustics LLC 3109 NE 109th Ave., Vancouver, WA 98682 cyberacoustics.com Compliance Informa�on Statement: FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. - Page 18 RF exposure statement This equipment meets the exemption from the routine evaluation limits in section 2.5 of RSS-102. It should be installed and operated with a minimum distance of 20cm between the radiator and any part of your body. Cet équipement est conforme à l'exemption des limites d'évaluation habituelle de la section 2.5 de la norme RSS-102.
