11. Parts & Accessories:
Flange Kits: (for 1 1/2" & 2" meters)
Two flanges (NPT threaded for connection to
pipe) and two gaskets
WMNLD-F-150 = Flange kit for 1 1/2" meters
WMNLD-F-200 = Flange kit for 2" meters
Check Valves:
C112CVLFN = 1/2"
D112CVLFN = 3/4"
E112CVLFN = 1"
G112CVLFN = 1 1/2"
H112CVLFN = 2"
Lead free brass check valves are available to
prevent reverse flow through meter. Reverse
flow will deduct from the meter's total. The
use of a check valve will also prevent the me-
ter and upstream water from being contami-
nated by debris or additives like fertilizer that
get added downstream from the meter.
12. Warranty:
WM-NLD water meters are warranted to perform to AWWA new meter accuracy standards,
and for twelve months from the shipment date will be free from defects in materials and
workmanship. If a meter fails to perform as warranted, Assured Automation will repair it
free of charge subject to the terms of this warranty. Assured Automation's liability under
this performance warranty is expressly limited to the repair or replacement of the meter
upon the customer's returning the complete meter prepaid to:
This performance guarantee is not applicable to meters which have been damaged by
aggressive water conditions, foreign matter in media, misapplication, willful misconduct,
negligence, vandalism, act of God, improper installation, frost/freeze damage or using the
meter outside of its specific operating parameters (especially temperature and flow ranges).
In no event shall Assured Automation be liable for incidental or consequencial damages
of any kind, including but not limited to loss of profits or revenue, loss of use, cost of capi-
tal, cost of substitute equipment, facilities or services, downtime costs, delays and claims
of customers of the customer or other third parties.
WM-NLD Series Positive Displacement Water Meters - Installation, Operation, & Maintenance
Garden Hose Adapters: (set)
One NPT Female x Male Garden Hose Thread
One NPT Female x Female Garden Hose Thread
WMGHA050 = Adapter set for 1/2" meters
WMGHA075 = Adapter set for 3/4" meters
Digital Display with Reset:
Add a remote digital display that can be reset
to simplify reading. Simply attach the 2 wires
from the meters pulse output to terminals #2
and #6 on the display.
KAL-D06 = digital display only (for panel mount)
KAL-D06-DIN32-ENC = display in weatherproof
enclosure
Assured Automation
263 Cox Street
Roselle, NJ 07203
