- Page 1 LED strip manual liniLED® Side RGB 160/240 30 mm V DC ADAM IK08 RoHS IP20 | IP68 CLEANING AGENTS FROST SEA WATER SWIMMING POOL UV RESISTANT SWIMMING POOL System GLOW WIRE BEND RADIUS S D C M RESISTANT RESISTANT RESISTANT...
-
Page 3: Table Of Contents
Side RGB 160/240 Technical notes Side RGB 160/240 - Product drawings Product information Product specifications Cable selection Area advice Product care and handling Cutting instructions Solder Connect IP40 Uninstalling the connector Power supply Symbols Disclaimer... -
Page 4: Technical Notes
- Products are transported in proper packaging. Products should remain packed until installation. - Take ESD (Electrostatic Discharge) protection measures when handling liniLED® products. - The products and their components may not be exposed to mechanical, static loads and other tension/compression other than from the product itself. -
Page 5: Side Rgb 160/240 - Product Drawings
Product information The liniLED® Top RGB 160/240 LED strip (IP20/IP40/IP64/IP67/IP68) is a high quality, flexible LED strip with a unique co-extrusion technology. The combination of high quality and exceptional flexibility, allows for an endless range of indoor and outdoor applications. -
Page 6: Cable Selection
100.1 m 2.50 mm2 - 0.007 Ω/m 447.8 m 867.7 m 219.6 m 429.6 m 82.7 m 166.7 m Note: Calculations are based on a standard connector with 1 metre cable (0.5 mm2). LED strip manual | liniLED® Side RGB 160/240... -
Page 7: Area Advice
Area advice Depending on the installation area of the liniLED® LED strip we off er a range of IP20, IP40, IP64 and IP68 solutions to cope with external factors. Below the diff erent connectors are displayed for use in diff erent environments. See corresponding pages or individual product manual for further instructions. -
Page 8: Product Care And Handling
Do not twist the LED strip. The LED strip has to be unreeled on a horizontal surface at the time of installation. Do not unreel the spool of LED strip before installation. LED strip manual | liniLED® Side RGB 160/240... -
Page 9: Cutting Instructions
Top view | Make sure the cut is vertical as illustrated in the image above. above. Top view | Only cut on the dotted lines to prevent damaging the Dispose of the unnecessary material through waste recycling of LED strip. electrical and electronic equipment. LED strip manual | liniLED® Side RGB 160/240... - Page 10 Cutting instructions Place the liniLED® LED strip on the base of the cutting tool. Not doing so may result in a deformed LED strip. LED strip manual | liniLED® Side RGB 160/240...
-
Page 11: Solder
PCB. Carefully cut away this part of the extrusion. Side view | Do not cut the PCB! The end result after cutting the LED strip extrusion should look similar to the image above. LED strip manual | liniLED® Side RGB 160/240... - Page 12 Pre-solder the wires. Pre-solder the connector pads. 300°C Max. 4 sec. Solder the wires to the connector pads. Connect the liniLED® LED strip to the power supply (24 V DC) con- stant voltage. LED strip manual | liniLED® Side RGB 160/240...
-
Page 13: Connect Ip40
Take into account the direction of the arrow on the bottom of the Connector (3), Clamp (4). liniLED® LED strip and allign it with the arrow on the clamp (4). Place the shell (2) over the LED strip. Make sure the side with the Side view | Slide the clamp (4) over the cable to reveal the smallest opening is put on first. - Page 14 Slide the shell (2) partly over the clamp (4). arrow is on the upper side. ‘ Click ’ Test the liniLED® LED strip before you slide it fully over the clamp (4). Slide the shell (2) entirely over the clamp (4) and push firmly until it ‘clicks‘ .
-
Page 15: Uninstalling The Connector
Uninstalling the connector Gently wiggle the connector and pull in opposite direction. Firmly grab the outer shell and gently grab the liniLED® LED strip. The connector should look like this when it is removed. Firmly press the sides of the shell and pull gently while holding the cable to remove it. -
Page 16: Power Supply
Measure output (23-25 V DC) before installing liniLED® system Connect the LED strip as indicated in the figure above. The wires should be connected as follows: Red (+) and Black (-). Insert the power plug. LED strip manual | liniLED® Side RGB 160/240... -
Page 17: Symbols
This product is available on request and can be applied submerged in swimming pools and their environment. Disinfectants will have no harmful e ect on the product. For chemical speci cations of these elements see the liniLED® material sheet. Verify IP rating for proper use. -
Page 18: Disclaimer
Disclaimer The published information is checked to be as accurate as possible, however Triolight B.V. or any reseller of liniLED® cannot be held liable for any damages resulting from misprints, errors, modifi cations or outdated information. No legal rights can be derived from this document. Triolight B.V. reserves the right to modify the information without informing the customers.
