- Page 1 NICHARGE UNIFIX 300 Le support universel (sol, mur, mât, …) 16/04/2018 www.uniteck.fr CO00117...
- Page 2 Unifix brackets have been specially designed to fix your Unisun photovoltaic panels or equivalent (see part compatible panels): • Unifix 300 for your Unisun panels Unisun 80.12M (x3) / 100.12M (x3) / 100.24M (x3) / 110.12BC (x3) / 150.12M (x2) / 150.12BC (x2) / 200.24M UNIFIX 300 Simple to install, they attach either: •...
-
Page 3: Safety Instructions
UNIFIX 300 PANEL COMPATABILITY With the design based on the use of Oblong drilling, Unifix allows the fixing of different panels of the market. Unifix accepts 1, 2 or 3 panels according to the references, with the spacings and dimensions of panels indicated below. - Page 4 Mount Unifix brackets only on surfaces with sufficient lift. Consider the additional load with panel: Support Panel Unifix 300 = 15 kg Unisun 80.12M (x3) / 100.12M (x3) / 100.24M (x3) / =19kg / 23kg / 23kg/ 110.12BC (x3) / 150.12M (x2) / 150.12BC (x2) / 200.24M...
- Page 5 UNIFIX 300 - PREPARATION LIST OF PIECES M8x100 M8X20 n°15 n°16 n°18 n°34 n°17 n°13 N°9 N°10 FOR USAGE WITH ONE PANEL: M8x45 8X18x10 Recommended tightening torque Couple 5,10 Nm 8,80 Nm 21,50 Nm M 10 44,00 Nm Nb. Average friction coefficient μ = 0.20 / Tightening at 50% of the elastic limit www.uniteck.fr...
- Page 6 UNIFIX 300 - PREPARATION BEFORE MOUNTING • Fix the pieces n°8 by 2. M8x20 n°18 • Fix the parts n°17 on the parts previously assembled M8x20 n°17 www.uniteck.fr 17/34...
- Page 7 UNIFIX 300 - - WALL MOUNTING / FLOOR / ROOF • Attach parts n°15 and n°16 to part n°34. Pre-tighten the nuts. The final tightening will be done at the end of the assembly. M8x20 n°15 n°16 n°34 • Pre-attach parts n°9 to part n°34. Do not tighten completely M8x20 n°34...
- Page 8 UNIFIX 300 - - WALL MOUNTING / FLOOR / ROOF • Secure the top bracket with 8 screws to fit your surface (screws and dowels not included). www.uniteck.fr 19/34...
- Page 9 UNIFIX 300 - - WALL MOUNTING / FLOOR / ROOF • Unifix has a multi-position tilt system. (10 positions). Set the desired tilt to the desired orientation. Electrical performance depending on tilt and panel 0° orientation Adjustable 30° 60° 90°...
- Page 10 Fix the bar n°34 on the wall or flat surface. M8x20 • Attach your Unisun solar panels panneau panneaux panneaux M8x20 M8x20 M8x45 8,2 x 18 x • Tighten all screws and check that all other screws have been tightened. www.uniteck.fr 21/34...
- Page 11 UNIFIX 300 - FIXING ON ROUND MAT (40 TO 60 MM DIAMETER) • Attach the bracket to the mast with 2 flanges and associated M8 screws (for fixing to the signal mast, use the flanges corresponding to the mast used, flanges not included...
- Page 12 UNIFIX 300 - FIXING ON ROUND MAT (40 TO 60 MM DIAMETER) • Add reinforcements n°10 and bar n°34 previously assembled. The position of your fixing screws on the rail of the bar n°9 determines the position of the lower bar on your mast.
