RUD Ice 120 User Instructions

Balancer

Advertisement

Quick Links

Complies with the machinery directives 2006/42/EC
NB: Please ensure that the safety instructions have been fully read and understood before initial use of the ICE-Balancer.
Failure to do so may result in serious injuries and/or material damage and eliminates manufacturers warranty.
User Instructions - Part 1

Safety instructions

This safety instruction/declaration of the manufacturer must be
kept on file for the lifetime of the product.
ATTENTION: Please inspect all components prior to use.
Damaged, incorrect assembly or improper use may result
in serious injuries and/or material damage.
EC-Declaration of the manufacturer
According to the Machinery Directive 2006/42/EC, annex II B
and amendments.
We hereby declare that the design and construction of the
equipment detailed within this document, adheres to the
appropriate level of health and safety of the corresponding EC
regulation.
Any un-authorised modification and/or any incorrect use of
the equipment not adhered to within these user instructions
waivers this declaration invalid.
The equipment must be regularly tested and inspected as per
BGR 500. Failure to carry out the recommended maintenance
and testing waivers this declaration invalid.
Designation of the equipment:
Type: ICE-Balancer
Manufacturer's mark:
Drawings (iges, dxf and step), product information and other
support material can be downloaded from www.rud.com.au.
For further information on our complete range of products and services please visit our website at
www.rud.com.au
