- Page 1 Sling Guide Joerns Healthcare Redefining patient handling...
-
Page 2: Table Of Contents
Oxford Sling Models FIM Scoring Oxford Slings Feature Sling Accessories Cradle Options Range of Sizes Weight Capacity Identification Label User Guide Sling Safety Information Size & Weight Range Guide Other Considerations for Slings Special Slings Sling Prescription Sheets Sling Support Levels and Commode Apertures Selecting the Best Type of Sling Information About Other Equipment Sling & Lift Selection Chart Clinical Support/Advice Moving and Handling Training About Joerns Healthcare... -
Page 3: Introduction
Oxford Slings Introduction A sling is an item of moving and handling equipment that is used with a mechanical lift in order to facilitate the transfer of a patient. A sling comprises a specially designed and constructed piece of fabric that is placed under and around a patient before being attached to the cradle/spreader bar of a lift to raise, transfer and lower the patient. -
Page 4: Oxford Sling Models
Sling Models The Oxford range of slings has been designed with a number of features aimed at meeting varied lifting requirements and applications. Each sling is described briefly below. Note FIM scores have been provided as an assessment tool to classify a person’s function from independence to total assistance in 7 levels. - Page 5 Oxford Slings Full Back Sling (Spreader Bar: 6 Point) This is a more specialised sling. It incorporates integral boned head support and padded leg pieces and is available in sizes XS to XL. The correct size will fit snuggly and give full protection for patients who go into extension or have involuntary movements or behavioural problems.
- Page 6 Standing Sling (Standaid) The standing sling is suitable for those patients who have a greater degree of weight bearing ability. It allows excellent access for toileting and is easy to fit, providing quick and effective transfers. The adjustable waist strap and the non-slip back pad ensures the sling does not ride up during the transfer.
-
Page 7: Fim Scoring
Oxford Slings FIM Score A widely used assessment tool to classify a person’s function from independence to total assistance in 7 levels. What are the 7 levels? 7. Complete Independence Another person is not required for the activity which is performed safely without modification or outside assistance within a reasonable time. -
Page 8: Oxford Slings Feature
OXFORD Sling Features OXFORD slings have many common attributes that make them easier to use, and easier to train with. Coloured binding provides clear recognised size Coloured loop straps that provide adjustment and information. the correct angle positioning for the 6-point spreader bar system. - Page 9 Oxford Slings The angles of the straps are carefully calculated to Handles on the sides of our slings are optimised ensure the correct posture and comfort of the patient. to ensure correct handling. Made from polyester OXFORD slings are durable, Net slings are ideal in wet environments, providing soft and comfortable. rapid draining and drying. Padding provides additional comfort and support to The grey colour of our slings means that contamination delicate areas and our webbing straps have covered is easy to spot - but the polyester fabric isn’t prone...
-
Page 10: Sling Accessories
Sling Accessories Head supports ensure correct positioning during Head/Neck Roll transfer. Extension straps allow adjustment to the length of the existing sling straps that connect to a patient lift. (Available as an optional accessory). Cradle Options The OXFORD professional lift range has the option of two cradles that provide the carer greater choice in selecting the most appropriate sling and cradle for the task. - Page 11 Oxford Slings 6-point Spreader Bar The 6-point spreader bar uses slings with webbing loops that allow positioning adjustments to be made by selecting the different coloured loops. The attachment straps at shoulder level determine the position of the back, ranging from upright through to semi-reclined and reclined.
-
Page 12: Range Of Sizes
Range of Sizes Most slings are available in a range of sizes to accommodate variety in height, shape and weight of patients. All these factors must be taken into consideration when selecting the appropriate sling for the patient. Sizes are available from XS to XL and full details on our slings can be found in our order form. -
Page 13: Identification Label
Oxford Slings Identification Label The identification label provides essential information about the sling such as: n Model reference number n Care instructions n Type of sling n Safe working Load (SWL) n Size n Bar code (not shown) n Testing mark (CE or similar) n Identification picture n Date of manufacture Note:... -
Page 14: Size & Weight Range Guide
Size & Weight Range Guide (approx.) Please note the following sling guides are recommendations only. A full risk assessment must be conducted before any sling is selected. This will ensure safety for the patient and the carer. Sling Range Weight Recommendation Chart (GUIDE ONLY) Sling Minimum Weight Maximum Weight... -
Page 15: Special Slings
Oxford Slings Special Slings Special slings are ‘one-off’ designs to meet specific requirements of individual patients and can be made to order. The following specials can be ordered (extended lead times apply - please consult your OXFORD representative for details). n Extend loop strap length to suit (leg or shoulders) n Taper leg section n Add loop to suit... -
Page 16: Sling Support Levels And Commode Apertures
Sling Support Levels and Commode Apertures Different types of slings provide different levels of support for the patient being lifted. The support level is determined by the shape and structure of the fabric, with the main body of the sling providing support to the back and head (photo 1) and the leg straps providing support to the thighs, hips and buttocks (photos 3/4). -
Page 17: Selecting The Best Type Of Sling
Oxford Slings Selecting the Best Type of Sling Selecting a sling for an individual patient involves more than simply measuring their size and deciding what the sling will be used for. Basic factors to take into consideration are the level of support required from the sling and whether a commode aperture is necessary. -
Page 18: Information About Other Equipment
Information About Other Equipment It is necessary to establish the sling’s compatibility with other equipment, especially the lift and the lifting system. It is also important to identify any associated equipment that is involved in transfers, such as seating, beds, trolleys, toilets and play or therapy equipment to ascertain that the lift and sling will work effectively with these items. -
Page 19: Clinical Support/Advice
Joerns Healthcare training programmes are CPD certified. About Joerns Healthcare Joerns Healthcare provides the complete solution to moving and handling with a range of compatible lifts, slings and accessories designed to meet the needs of both patient and carer. Besides slings, the OXFORD patient... - Page 20 Joerns Healthcare Limited High Street, Wollaston, Stourbridge, West Midlands DY8 4PS England (T) +44 (0)1384 446622 (F) +44 (0)1384 446601 www.joerns.co.uk • email: info@joerns.co.uk 2007 Joerns Healthcare 0705/000690271.UK/SD Rev. B...
