- Page 1 Art. Modulo 6 MODULO6 design AL Studio...
- Page 2 Art. Modulo 6 ASSEMBLY DIAGRAMS FOR MIRRORS Installation manual 110/220 V ~ 110/220 V ~ P.S.: Remove the corner protection only when isntallation is completed. We advise to make sure the lighting wires are prepared so they are in correspondence to the center of the mirror. 1_ To attach the mirror to the desired height H.
- Page 3 Art. Modulo 6 ASSEMBLY DIAGRAMS FOR MIRRORS Installation manual 115V 230V AC AC/DC CONNECTING BOX / SCATOLINO DI CONNESSIONE Lampada 1 / Lamp 1 | 2 - Lampada 2 / Lamp 2 | 4 - 2_ Fix the bracket S at the determined height, put the second bracket in 3_ Make the electrical connection between the network and the AC level with the first and fasten it to the wall.
