Summary of Contents for antoniolupi NEULUCE
- Page 1 Neuluce NEULUCE design AL Studio...
- Page 2 Neuluce ASSEMBLY DIAGRAMS FOR MIRRORS Installation manual P.S. Remove protection from the corners only when you have completed installation. We advise to foresee electrical wiring in the center of the mirror. 1_ To hang the mirror at the desired H height. Trace the position of the holes in the brackets so that the folding side reaches height C.
- Page 3 Neuluce ASSEMBLY DIAGRAMS FOR MIRRORS Installation manual DC 12V DC 12V 110-230v 110-230v 110-230v 110-230v 2_ Connect the lamps according to the above schemes. 115V 230V AC AC/DC CONNECTING BOX / SCATOLINO DI CONNESSIONE Lampada 1 / Lamp 1...
