Redkite Baby Go Round Ladybug Instruction Leaflet page 2

Parts list
Anti slip blocks x 6 Front wheels x 2
Assembly instructions
1. Open the walker to it's middle
position by raising the tray.
Fig 1.
2. To attach the front of the
seat, insert the pins on the front
of the seat into the holes and
then push downwards until they
click into position.
Fig 2.
3. To attach the rear of the seat,
thread the straps with the
buckles through the
corresponding slots on the tray
recess. Now from the underside,
pull the straps completely
through and pivot the buckle to
lie flat against the underside of
the tray.
Fig 3 & 3a.
Rear wheels x 2
Fig. 1
Fig. 2
Fig. 3
Fig. 3a
4. Place the walker on a solid flat
surface with the bottom facing
upwards. Insert the pins of the
front wheels into their housings
until they click into position.
Fig 4.
5. With the walker still upside down,
insert the friction blocks into the
receiving holes on the base. Ensure
they are secured properly before
first use.
Fig 5.
Height adjustment.
6. Remove the baby from the
walker. Turn the safety button
lengthwise and press the button
until the mechanism is released.
With the button still pressed in,
select new height. Three different
height positions are available.
Fig 6.
7. When the new position has been
selected, release the button and
check it has turned 90 degrees
back to it's original position.
Fig 7.
NOTE This product (including toy
tray attachment) must be
assembled by an adult.
Rear
Front
Fig. 4
Fig. 5
Fig. 6
Fig. 7
