- Page 2 ACD200 Useranual Preface Preface Preface Preface Preface This manual is helpful in type selecting, installation, parameter setting, site commissioning, trubleshooting, and daily maintenance of the inverter. To guarantee safe operation of the inverter, please read this manual thoroughly, and keep it handy for referance in the future.
-
Page 3: Table Of Contents
ACD200 Usermanual Catalogue CHAPTER 1 WIRING................... 1 1.1 W )....1 IRING AYOUT OF ONTROL ERMINALS FACTORY SETTING 1.2 D ESCRIPTION OF THE ONTROL ERMINAL NDOCATORS ......1 CHAPTER 2 FUNCTION PARAMETERS LIST ..........3 2.1 D ESCRIPTION OF THE ARAMETER IN THE TABLE ........ -
Page 4: Chapter 1 Wiring
ACD200 Usermanual Wiring Chapter 1 Wiring Chapter 1 Wiring Chapter 1 Wiring Chapter 1 Wiring 1.1 Wiring Layout of Control Terminals(factory setting) 1.1 Wiring Layout of Control Terminals(factory setting) 1.1 Wiring Layout of Control Terminals(factory setting) 1.1 Wiring Layout of Control Terminals(factory setting) Diameter of wire: 24 ～12AWG Diameter of wire: 22 ～16AWG Wire Type: 75 ℃，Copper Only... - Page 5 ACD200 Usermanual Wiring Inout voltage range: Accept the input of analog 0~10V voltage/current,voltage and (Input impedance: 70K Analog value input current are selected by Jump Line Ω);input current range: J6,factory setting 4~20mA(Input impedance: voltage.(reference:groud) 250Ω)resolving capability: 1/1000 Supply analog voltage/current output,it can represent 11 kinds Voltage output range: of unit,please refer to the...
-
Page 6: Chapter 2 Function Parameters List
ACD200 Usermanual Functioanl Parameter List Chapter 2 Function Parameters List Chapter 2 Function Parameters List Chapter 2 Function Parameters List Chapter 2 Function Parameters List 2.1 Description of the Parameter in the table 2.1 Description of the Parameter in the table 2.1 Description of the Parameter in the table 2.1 Description of the Parameter in the table ×... - Page 7 ACD200 Usermanual Functioanl Parameter List H0.05 ACCE Time 1 0.1－6000.0 20.0 ○ H0.06 DCCE Time 1 0.1－6000.0 20.0 ○ ACCE and DCCE Time 0: Second H0.07 × 1: Minute Unit Upper Limit H0.08 Lower Limit Frequncy －3200.0Hz 0.01Hz 50.0Hz × Frequency Lower Limit H0.09...
-
Page 8: H1- Specified Frequency Function Parametes
ACD200 Usermanual Functioanl Parameter List Selection Starting time of S 10.0（％）－50.0（％） （ACCE and DCCE time ） H0.24 0.1(％) 20.0(%) ○ H0.24+H0.25≤90（％） curve 10.0（％）－80.0（％） （ACCE and DCCE time） Risiing time of S H0.25 0.1(％) 60.0(%) ○ H0.24+H0.25≤90（％） curve 0: model G G/L model set H0.26 ×... -
Page 9: H3- Auxiliary Fuctional Parameters
ACD200 Usermanual Functioanl Parameter List 1: stop automatically 2: stop by DCCE+DC brake Starting frequency of H2.06 0.0－15.0Hz 0.1Hz 0.0Hz ○ DC brake when stop H2.07 DC brake time when stop 0.0－20.0s 0.1s 0.0s ○ DC brake voltage when H2.08 0－15（％）... - Page 10 ACD200 Usermanual Functioanl Parameter List 0－247，0 is radio address, when the inverter is set as 0, it only receive and H3.09 Machine address × do not send, 247 is the host address Communication timeout H3.10 0.0－999.0s 0.1s 0.0s × detection time Response delay time of H3.11 0－1000ms...
-
Page 11: H4- Simple Plc Function Parameters
ACD200 Usermanual Functioanl Parameter List 2: output current selection when 3: output voltage operating 4: DC bus voltage 5: motor speed 6: radiator tempreture 7: reserved 8: analog input ACI 9: MI、FWD and REV input terminal status 10: PID given pressure 11: PID feedback pressure LED initial screen monitoring parameter... -
Page 12: H5- Closed Loop Functional Parameters
ACD200 Usermanual Functioanl Parameter List 000－321 ○ H4.09 Pahse 5 setting Phase 5 operating time 0－6000.0 10.0 ○ H4.10 H4.11 000－321 ○ Phase 6 setting H4.12 Phase 6 oeprating time 0－6000.0 10.0 ○ H4.13 000－321 ○ Phase 7 setting H4.14 Phase 7 oeprating time 0－6000.0 10.0 ○... -
Page 13: H6- Termianl Function Parameters
ACD200 Usermanual Functioanl Parameter List H6 H6 H6 H6- - - - Termianl FUnction Parameters Termianl FUnction Parameters Termianl FUnction Parameters Termianl FUnction Parameters 0: free control end 1: multi-speed control terminal 1 2: multi-speed control terminal 2 3: multi-speed control terminal 3 4: multi-speed control terminal 4 5: external forward jog control 6: external reverse jog control... - Page 14 ACD200 Usermanual Functioanl Parameter List 0: Inverter is in operating （RUN） 1: frequency arriving signals （FAR） frequency level detection signals （FDT1） 4: overload pre-warning signal(OL) 5: output frequency up to upper limit （FHL） 6: output frequency up to upper limit （FLL） 7: inverter locked and stop due to under voltage (LU) 8: external fault stop...
-
Page 15: H7- Specific Traverse Function Parameters
ACD200 Usermanual Functioanl Parameter List H6.14 0.00－upper limit frequency 0.1Hz 10.0Hz ○ FDT1(frequency level)level 0.0－50.0Hz H6.15 FDT1 lag 0.1Hz 1.0Hz ○ 0: output frequency (0－upper limit frequency) 1: rated frequency (0－upper limit frequency) Analog output (AO1) 2:output current (0－2×rated current) H6.16 ○... -
Page 16: H8- Motor And Vector Control Parameters
ACD200 Usermanual Functioanl Parameter List Traverse preset H7.07 frequency waiting 0.0－6000s 0.1s 0.0s ○ time H8 H8 H8 H8- - - - Motor and Vector Control Parameters Motor and Vector Control Parameters Motor and Vector Control Parameters Motor and Vector Control Parameters Control method 0: V/F control H8.00... -
Page 17: Ha Parameters
ACD200 Usermanual Functioanl Parameter List detection level Overload pre-load 0.0－20.0s H9.06 0.1s 5.0s ○ delay time Overvoltage stall 0: avoid H9.07 × 1: allow selection Coervoltage stall 120-150（%） H9.08 1(%) 140(%) ○ point Auto frequency limit 110－200（%） H9.09 1(%) 150(%) ×... -
Page 18: He- Secret Code And Manufacturer Functional Parameters
ACD200 Usermanual Functioanl Parameter List Fault record before Hd.05 Fault record before Hd.04 Hd.04 The rated frequency The rated frequency when the latest fault when the latest Hd.06 0.1Hz happened fault happened The rated output The rated output frequency when the latest frequency when the Hd.07 0.1Hz... -
Page 19: Chapter 3 Fault Diagnosis And Countermeasures
ACD200usermanual Fault Diagnosis and Countermeasures Chapter 3 Fault Diagnosis and Countermeasures 3.1 Faults and Counter Measures 3.1 Faults and Counter Measures 3.1 Faults and Counter Measures 3.1 Faults and Counter Measures The possible fault that will happen in ACD200 is listed in table 7-1,the fault code range is U-01~U-23. - Page 20 ACD200usermanual Fault Diagnosis and Countermeasures Deceleration time is too short Extend the decceleration time Inverter deccelerate Add the brake power of external There is potential load or high U-03 the operating energy consumption braking inertia load speed and compenents overcurrent Inverter power is a little Use inverter with bigger power small...
- Page 21 ACD200usermanual Fault Diagnosis and Countermeasures Adjust the V/F curve setting,adjust Improper V/F curve the torque lifting range Set it as speed-checking and Restart the rotating motor restarting function Low voltage of grid Check input power Use inverter with smaller power Inverter power is too big level Adjust the V/F curve setting,adjust...
-
Page 22: Fault Recording And Checking
ACD200usermanual Fault Diagnosis and Countermeasures U-17 Reserved Reserved Reserved Loose connection control Check and reconnecting panel wiring and plug-in Current Ask manufacturer or sales agent for Auxilliay power damaged assist U-18 sensing Ask manufacturer or sales agent for Hall components damaged circuit assist Ask manufacturer or sales agent for... -
Page 23: Fault Reset
ACD200usermanual Fault Diagnosis and Countermeasures C C C C ode C C C C ontents ontents C C C C ode C C C C ontents ontents ontents ontents ontents ontents Rated frequency when the fault Hd.00 Fault record for last time Hd.06 happened last time Rated frequency when the fault...
