Alfa Network AOA-501 Technical Specifications

5.8 GHz Outdoor Omni-Directional Antennas

5.8GHz Omni-Directional antenna are designed
for use with unlicensed-band wireless equipmemt in
outdoor environmemt for long distance data
transmisson in compliance with IEEE802.11a.Ideal
for working with AP for 360 degree coverage.
Technical Specifications
Model
Frequency
VSWR
Gain
Vertical Beamwith
Horizontal Beamwith 360°
Impedance
Connector
Length
Diameter
Weight
AOA-501 AOA-502
5.4~5.9GHz 5.4~5.9GHz
≦ 1.5 ≦ 1.5
8 dBi 10 dBi
12° 8°
360°
50Ω 50Ω
Fixed N female Fixed N female
450 mm 500mm
25 mm 25 mm
430 g 480 g
AOA-503 AOA-504
5.4~5.9GHz 5.4~5.9GHz
≦ 1.5 ≦ 1.5
12 dBi 15 dBi
6° 3°~5°
360° 360°
50Ω 50Ω
Fixed N female Fixed N female
560 mm 810 mm
25 mm 25 mm
510 g 540 g
