APA-L01
Panel Directional Antenna / 18 dBi, N-Type Female connector
Specification
Frequency
Type
Polarization
Gain
VSWR
Impedance
Connector Type
Temperature
Lightning Protection
Material
Dimensions
Weight
2400 ~ 2483.5MHZ
Panel Directional
Linear, Horizontal / Vertical
18dBi
< 1.5
50Ω
N Type (Female) / N-type Female Reverse
-30 to 60 ℃
DC Ground
Cover base :Injection ABS
330 x 295 x 35mm
1.6Kg (include Swivel base)
