APOE5912v set
Adjustable triple output 5/9/12v POE SET
Power over Ethernet (POE) adapter is designed to supply operational power to surveillance
Cameras and VoIP device and wireless LAN devices such as access points, bridges and router.
It enables power current to travel on the Ethernet network cable to device.
It supports 5VDC or 9VDC or 12VDC power requirements.
Specification
PoE Injector
Input Voltage
Output Voltage
Input Current
Load Regulation
Operating Temperature
PoE Splitter
Input Voltage
Output Voltage
RJ45 cable Power Usage
Date Rate
Operation Temperature
Storage Temperature
Operation Humidity
Storage Humidity
AC 110 ~ 220V
DC 48V / 0.4A
0.5A Maximum
+ / - 5%
0 ~ 40
℃
DC 48V
DC 5V or DC 9V or DC 12V
( Adjustable)
Date: Pins 1,2,3,6
Power: Pins 4,5,7,8
10/100Mbps
0 ~ 40
℃
-40 ~ 70
℃
10% ~ 80% RH
5% ~ 90% RH
