Alfa Network AWDS-R03 Specifications

AWDS-R03
802.11g Wireless LAN
ADSL2+Router
Congratulations on purchasing this 802.11g Wireless LAN ADSL2+ Router. This
router is a cost-effective ADSL2+ router, with the combination of an ADSL2+ modem, router, Ethernet network
switch and wireless access point, you can surf the Internet through your ADSL2/2+ broadband connection without
investing other devices.
This router can support downstream transmission rates of up to 24Mbps and upstream transmission rates of up to
1Mbps. It supports PPPoA (RFC 2364 - PPP over ATM Adaptation Layer 5), RFC 1483/2684 encapsulation over
ATM (bridged or routed) and PPP over Ethernet (RFC 2516) to establish a connection with ISP. The product also
supports VC-based and LLC-based multiplexing.
With the web management interface, users can easily configure the various functions of the router including DHCP
server, NAT, virtual server, DMZ, access control, IP/MAC/Application/URL filter, Firewall, PPTP/IPSec/L2TP
pass-through, DDNS, UPnP, Wireless and etc.
This router is a high performance and high-speed device that provides a full rate of ADSL2+ standard with the
superb reliability and a complete solution for home and office application.
Features
ADSL2/2+ Compliance
• Support downstream rates of up to 24Mbps and upstream rates of up to 1Mbps.
• Compliant to ITU-T G.992.1 (G.dmt), G.992.2 (G.lite), G.992.3 (ADSL2), G.992.4 (splitterless ADSL2), G.992.5
(ADSL2+) for Annex A, B. (Annex A and B are supported in different H/W platform)
• Supports Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (G.992.1); G.994.1 and G.996.1 (for ISDN only);
G.991.1;G.lite (G992.2)).
• Multiple Protocols over AAL5 (RFC 1483/2684).
• PPP over AAL5 (RFC 2364).
• PPP over Ethernet (RFC 2516).
