Notes: Please use this manual together with service manual
Model No.[SA-PM250EB/EC/EE/EF/EG-S, Order no. PSG1403006CE].
TABLE OF CONTENTS
1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.2. Caution for AC Cord (GS/GSX only)------------------ 4
1.3. Before Repair and Adjustment ------------------------- 4
1.4. Protection Circuitry ---------------------------------------- 4
1.5. Caution For Fuse Replacement------------------------ 4
1.6. Safety Part Information----------------------------------- 5
2 Warning -------------------------------------------------------------- 6
Model No.
Product Color: (S)...Silver Type
PAGE
to Electrostatically Sensitive (ES) Devices ----------6
2.2. Precaution of Laser Diode -------------------------------7
2.4. Handling Precaution for Traverse Unit----------------8
3 Service Navigation --------------------------------------------- 10
3.1. Service Information -------------------------------------- 10
3.2. Notes -------------------------------------------------------- 10
3.3. Different Points ------------------------------------------- 11
© Panasonic Corporation 2014. All rights reserved.
Unauthorized copying and distribution is a violation of
law.
CD Stereo System
SA-PM250GS
SA-PM250GSX
SA-PM250GT
PSG1405005AE
PAGE
Advertisement
Table of Contents
Related Manuals for Panasonic SA-PM250GS
Summary of Contents for Panasonic SA-PM250GS
-
Page 1: Table Of Contents
3 Service Navigation --------------------------------------------- 10 1.6. Safety Part Information----------------------------------- 5 3.1. Service Information -------------------------------------- 10 2 Warning -------------------------------------------------------------- 6 3.2. Notes -------------------------------------------------------- 10 3.3. Different Points ------------------------------------------- 11 © Panasonic Corporation 2014. All rights reserved. Unauthorized copying and distribution is a violation of law. - Page 2 4 Specifications ---------------------------------------------------- 12 5 Block Diagram --------------------------------------------------- 13 5.1. SYSTEM CONTROL & AUDIO BLOCK DIAGRAM -------------------------------------------------- 13 6 Schematic Diagram--------------------------------------------- 14 6.1. MAIN (MICON) CIRCUIT (1/2)------------------------ 14 6.2. MAIN (MICON) CIRCUIT (2/2)------------------------ 15 6.3. MAIN (SUPPLY) CIRCUIT ----------------------------- 16 6.4.
-
Page 3: Safety Precautions
1 Safety Precautions 1.1. General Guidelines 1. IMPORTANT SAFETY NOTICE There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Circuit Board Layout, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent X-RADIATION, shock, fire, or other hazards. -
Page 4: Caution For Ac Cord (Gs/Gsx Only)
1.2. Caution for AC Cord (GS/GSX only) 1.3. Before Repair and Adjustment Disconnect AC power, discharge AC Capacitors (C1702, C1710, C1725, C1727 and C1728) through a 10W, 1W resistor to ground. Caution : DO NOT SHORT-CIRCUIT DIRECTLY (with a screwdriver blade, for instance), as this may destroy solid state devices. After repairs are completed, restore power gradually using a variac, to avoid overcurrent. -
Page 5: Safety Part Information
1.6. Safety Part Information Safety Parts List: There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Exploded View & Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. -
Page 6: Warning
2 Warning 2.1. Prevention of Electro Static Discharge (ESD) to Electrostatically Sensi- tive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD). -
Page 7: Precaution Of Laser Diode
2.2. Precaution of Laser Diode CAUTION! THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. Caution: This product utilizes a laser diode with the unit turned "on", invisible laser radiation is emitted from the pickup lens. Wavelength: 790 nm (CD) Maximum output radiation power from pickup: 100 μW/VDE Laser radiation from the pickup unit is safety level, but be sure the followings:... -
Page 8: Handling Precaution For Traverse Unit
2.4. Handling Precaution for Traverse Unit The laser diode in the optical pickup unit may break down due to static electricity of clothes or human body. Special care must be taken avoid caution to electrostatic breakdown when servicing and handling the laser diode in the Traverse Unit. Cautions to Be Taken in Handling the Optical Pickup Unit 2.4.1. - Page 9 Grounding for electrostatic breakdown prevention 2.4.2. Some devices such as the CD player use the optical pickup (laser diode) and the optical pickup will be damaged by static electricity in the working environment. Proceed servicing works under the working environment where grounding works is completed. 2.4.2.1.
-
Page 10: Service Navigation
3 Service Navigation 3.1. Service Information This service manual contains technical information which will allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, this information will be followed by supplement service manual to be filed with original service manual. -
Page 11: Different Points
3.3. Different Points Ref. No. Parts No. Parts name & Description Remarks SA-PM250EB-S SA-PM250GS/GSX/GT-S RYP1985-S1 RYP1985A-S1 FRONT PANEL ASS’Y RKQX1015C-K2 RKQX1015A-K2 REAR CABINET RKQX1015C-K2 REAR CABINET GS/GSX RGN3453-K RGN3453B-K NAME PLATE GS/GSX RGN3453D-K NAME PLATE RPG0L46 RPG0L51 PACKING CASE GS/GSX... -
Page 12: Specifications
2. Total harmonic distortion is measured by the digital spectrum ana- Amplifier Section lyzer. RMS Output Power Stereo Mode System : SC-PM250GS-S Music center: SA-PM250GS-S Front Ch (both ch driven) Speaker: SB-PM02EG1-K 10 W per channel (6 Ω), 1 kHz, 10% THD System : SC-PM250GSX-S... -
Page 13: Block Diagram
SMPS CUT 10 SMPS CUT FROM/TO POWER SUPPLY STBY CTRL STBY CONTROL 93 M VDET M VDET 38 DC DET PWR 77 DC DET PWR NOTE: “ * ” REF IS FOR INDICATION ONLY SA-PM250GS/GSX/GT SYSTEM CONTROL & AUDIO BLOCK DIAGRAM... -
Page 14: Schematic Diagram
DIMMER DIMMER RX8009 FL_CS D1H81014A042 FL_CS CLK_FL FL_DO FL_DO TU_INT TU_INT TU_RST TU_RST CLK_TU_SCL TU_SCL TU_SDA TU_SDA C8064 INNER_SW INNER_SW PW_STBY3R3V R8208 TO MAIN (MICON) CIRCUIT (2/2) SA-PM250GS/GSX/GT MAIN (MICON) CIRCUIT NOTE: “ * ” REF IS FOR INDICATION ONLY... -
Page 15: Main (Micon) Circuit (2/2)
DA: MAIN (DAMP): SCHEMATIC DIAGRAM - 4 R8114 330K CD: MAIN (CD MOTOR DRIVER): SCHEMATIC DIAGRAM - 5 US: MAIN (USB): SCHEMATIC DIAGRAM - 6 TO MAIN (MICON) CIRCUIT (1/2) SA-PM250GS/GSX/GT MAIN (MICON) CIRCUIT NOTE: “ * ” REF IS FOR INDICATION ONLY... -
Page 16: Main (Supply) Circuit
+9V VOLTAGE REGULATOR LB1100 J0JYC0000656 PW_LCD9V MI: MAIN (MICON): SCHEMATIC DIAGRAM - 1 ~ 2 DA: MAIN (DAMP): SCHEMATIC DIAGRAM - 4 CD: MAIN (CD MOTOR DRIVER): SCHEMATIC DIAGRAM - 5 US: MAIN (USB): SCHEMATIC DIAGRAM - 6 SA-PM250GS/GSX/GT MAIN (SUPPLY) CIRCUIT... -
Page 17: Main (Damp) Circuit
C8152 DGND IN SCHEMATIC R8217 TUN_BCK DIAGRAM - 6 R8216 TUN_DATA R8215 DSP_SDA TUN_LRCK DSP_SCL DSP_MUTE DSP_RESET MI: MAIN (MICON): SCHEMATIC DIAGRAM - 1 ~ 2 CD_SDO SU: MAIN (SUPPLY): SCHEMATIC DIAGRAM - 3 CD_BCK CD_LRCK SA-PM250GS/GSX/GT MAIN (DAMP) CIRCUIT... -
Page 18: Main (Cd Motor Driver) Circuit
2.2M R5022 CD-LD B1ADCF000001 LASER DRIVE MD/LPD C5020 R5007 C5018 R5036 0.01 DVD-LD C5028 GND-LD LB5002 C5027 J0JYC0000656 MI: MAIN (MICON): SCHEMATIC DIAGRAM - 1 ~ 2 SU: MAIN (SUPPLY): SCHEMATIC DIAGRAM - 3 SA-PM250GS/GSX/GT MAIN (CD MOTOR DRIVER) CIRCUIT... -
Page 19: Main (Usb) & Tuner Circuit
CIRCUIT (CN8002) TU_SCLK IN SCHEMATIC L54...GT TU_SDIO DIAGRAM - 4 G1C4R7MA0495 FOR SA-PM250GT TU_RESET TU_INT G2A380Y00002 0.47 JK52 AM ANT AM ANT AM ANT FOR SA-PM250GS/GSX NOTE: “ * ” REF IS FOR INDICATION ONLY SA-PM250GS/GSX/GT MAIN (USB) / TUNER CIRCUIT... -
Page 20: Printed Circuit Board
R8085 LB8110 R8084 R436 C8026 C8001 IC5001 C8002 C5001 R435 R8067 C8029 LB5001 R434 R8066 C8022 C8032 C8031 C1125 LB1109 C8064 C1188 R1149 QR1102 3734AA 3734AA (SIDE A) NOTE: " * " REF IS FOR INDICATION ONLY SA-PM250GS/GT/GSX MAIN P.C.B. -
Page 21: Main P.c.b. (Side B)
C1100 IC1108 C1141 C433 C6011 LB1108 R1100 CN8000 1 2 3 LB8007 R1101 IC8003 C434 CN1100 LB401 C1146 LB1106 C1148 R1105 QR1101 R1147 C461 3734AA 3734AA (SIDE B) NOTE: " * " REF IS FOR INDICATION ONLY SA-PM250GS/GT/GSX MAIN P.C.B. -
Page 22: Tuner P.c.b
7.3. TUNER P.C.B. TUNER P.C.B. (REP5069BB...GS/GSX) (REP5069DB...GT) FM ANT VA51 JK52 JK51 IC52 CN51 3734AB 3734AB 3734AB 3734AB (SIDE A) (SIDE B) NOTE: " * " REF IS FOR INDICATION ONLY SA-PM250GS/GT/GSX TUNER P.C.B. -
Page 23: Exploded View And Replacement Parts List
S7200 (VOLUME P.C.B.) S7201 P1700 S901 ZJ1702 (BUTTON P.C.B.) S902 *ZJ904 S903 (SMPS P.C.B.) JK52 (FOR GT) (TUNER P.C.B.) JK51 SA-PM250GS-S CN51 SA-PM250GSXS SA-PM250GT-S NOTE: " * " PART IS NOT SUPPLIED / REF IS FOR INDICATION ONLY. CABINET DRAWING... -
Page 24: Packaging
REMOTE CONTROL **SPACER PAD A1-1 R/C BATTERY COVER AC CORD (FOR GT ONLY) (FOR GS/GSX ONLY) AC CORD (FOR GS/GSX ONLY) SA-PM250GS/GSX/GT AC CORD (FOR GS/GSX ONLY) SB-PM02EG1 O/I BOOK FM INDOOR ANTENNA AM LOOP ANTENNA FERRITE CORE (FOR GT ONLY) -
Page 25: Mechanical Repacement Parts List
8.3. Mechanical Repacement Parts List Safety Ref. No. Part No. Part Name & Qty Remarks Description Safety Ref. No. Part No. Part Name & Qty Remarks RWJ1A03113XX 3P WIRE (BASS Description BUTTON-FUNCTION BUTTON) CABINET AND RWJ1A04075XX 4P WIRE (PANEL- CHASSIS FUNCTION BUTTON) REX1726-1 10P WIRE (SMPS -... - Page 26 Safety Ref. No. Part No. Part Name & Qty Remarks Description ACCESSORIES N2QAYB000984 REMOTE CONTROL A1-1 RKK-AKX18PHK R/C BATTERY COVER K2CA2YY00257 AC CORD K2CP2YY00061 AC CORD GS/GSX K2CQ2YY00119 AC CORD GS/GSX K2CT2YY00097 AC CORD GS/GSX RQT9926-B O/I BOOK (En) GS/GSX RQT9931-G O/I BOOK (Cn/Ar) 1 GS/GSX...
-
Page 27: Electrical Replacement Parts List
8.4. Electrical Replacement Parts List Safety Ref. No. Part No. Part Name & Qty Remarks Description Safety Ref. No. Part No. Part Name & Qty Remarks LB8018 J0JDC0000102 INDUCTOR Description LB8019 J0JDC0000102 INDUCTOR PRINTED CIR- JACKS CUITS BOARDS JK52 K4AC02B00042 JK AM ANTENNA PCB1 REP5071A...
