- Page 1 TRADE PRO DASH CAM SAF EG UA RD YOU R JOU RN EY USER GUIDE: RVEP1 RVEP2...
- Page 2 WA R N I NG The Dash Cam must not be fitted in a position which obscures the driver’s view of the road ahead. Depending on the country of use, recordings made with this device may be subject to Data Protection Laws. Ensure these are complied with. If the dash cam is to be used in a commercial environment e.g.
-
Page 3: Table Of Contents
TAB L E O F CON T ENTS Package Contents Product Specification Getting Started Installation Settings 9-10 Reformatting SD Card Passwords Reviewing Recordings 13-15... -
Page 4: Package Contents
PAC KAG E CON TE NTS Dash Camera Interior Camera (only with RVEP2) Quick Start Guide Window sticker Trim removal tool Hard wired power supply (fuse box) Tool to remove lockable SD card hex screw 3M adhesive mount (+1 replacement 3M pad) CON F I G U RATI ON Lockable Micro SD slot ON/OFF button... -
Page 5: Product Specification
Record vital evidence in the event of an incident. Protect yourself from insurance fraud, and in some cases even lower your insurance costs. Exceptional low light performance means Trade Pro dash cameras can provide vital evidence even when driving at night. -
Page 6: Getting Started
GE T T IN G STA R T ED To capture video and photos, requires the MicroSD card (pre-installed) MicroSD Card We recommend the use of the included MicroSD card for optimum performance. Minimum Class 10 U1 16GB/32GB (Class 10 U3 for Optimum Performance) SD CARD ERROR –... -
Page 7: Installation
INSTA L L I N G I NTO VEH I CLE 1. Ensure windscreen is clean of any moisture, dust and oils. 2. Position dash camera in a central location out of the line of sight of driver position 3. Connect hardwire kit to dash camera 4. - Page 8 HAR DW I RI NG I NTO VEH IC LE 1. Remove a fuse from an auxiliary power point in the fuse box 2. Insert the fuse into the end of the hardwire kit 3. Insert hardwire kit into fuse box in the slot vacated by the fuse removed in step 1 4.
-
Page 9: Settings
SE T T I NG S Resolution Set the resolution for the dash cam to record footage at. The higher resolution provides clearer image (recommended) the lower resolution creates smaller recording file sizes. Loop Recording The dash cam has the option to save recordings on a loop of 3 or 5 minutes. The dash cam will overwrite the oldest files saved to the MicroSD card to remove the requirement to manually clear the memory space. - Page 10 SE T T I NG S GPS (RVEP2) The GPS tracks the coordinates and speed of the dash cam during recording that is stamped on the bottom of the video recording. This can be set for metric, imperial or OFF. Date/Time Set the date &...
-
Page 11: Reformatting Sd Card
(TRAD E PRO 2) When installing a new Micro SD card larger than 32GB capacity into Trade Pro 2 dash cam, the card will need to be reformatted using the dash camera. This function is located in the setup menu. -
Page 12: Passwords
CH A NG E PASSWOR D (TRAD E PRO 2) 1. Remove security cover with removal tool 2. Remove Micro SD card 3. Insert Micro SD card into computer 4. Open ‘SDHC’ folder on the ‘This PC’ location 5. Open the file named ‘Password’ 6. -
Page 13: Reviewing Recordings
V I E WI NG RECOR D I NG S ON COM P UTER 1. Remove security cover with removal tool 2. Remove Micro SD card 3. Insert Micro SD card into computer 4. Open ‘SDHC’ folder on the ‘This PC’ location 5. - Page 14 V I E WI NG RECOR D I NG S ON TRAD E P RO 1 Press the ‘Rec’ button Press the ‘Mode’ button Press ‘Rec’ to play video twice recordings To Delete or Lock a Video File This menu allows you to Press the menu button save or delete the recorded files...
- Page 15 V I E WI NG RECOR D I NG S ON TRAD E P RO 2 A password is required to Press the ‘Rec’ button Default Password is: access the menu using the ‘1 1 1 1 1 1’. arrows to enter numbers and the Press ‘Rec’...
- Page 16 OTH E R I N FOR MATI ON Information on Waste Disposal for Consumers of Electrical & Electronic Equipment This mark on a product and/or accompanying documents indicates that when it is to be disposed of, it must be treated as Waste Electrical & Electronic Equipment (WEEE).
- Page 17 In line with our policy of continuous product development, Ring Automotive Limited reserve the right to alter specification without notice. Whilst every care has been taken in compiling the information in this catalogue, Ring Automotive Limited cannot accept legal liability for any errors or omissions.
