- Page 1 4 ZONE 3-Channel, 4 x 200W Professional Powered Mixer USER'S MANUAL دفترچه راهنما NEUTRIK NEUTRIK NEUTRIK NEUTRIK 4 ZONE...
- Page 2 دستورالعملهای مهم حفاظتی IMPORTANT SAFETY INSTRUCTIONS 1. Read t hese instructions before operating t his بمنظور استفاده بهتر و رعایت نکات ایمنی ، قبل از بکار گیری apparatus. دستگاه ،دستورا لعملهای کتابچه راهنما را به دقت مطا لعه فرموده و 2.
-
Page 3: Table Of Contents
PA2040 P O W E R E D M I X E R TABLE OF CONTENTS INTRODUCTION................4 FEATURES..................5 GETTING STARTED.................5 FRONT PANEL..................6 BACK PANEL................. 15 APPLICATION................18 SPECIFICATIONS................19... -
Page 4: Introduction
سنپر ینی تولید و به بازار عرضهSENPRINI مهندس پرویز یوسفی پور در سال 1431 اولین اکو آمپلی فایر نواری 002 وات المپی را با نام . اکوچنگ به کاربران ا رایه گردیدECHO CHANG نمود . در سال 8531 محصوالت تولیدی سنپرینی با نام و عال مت... -
Page 5: Features
PA2040 Getting Started Features 1. Before turning the power on, the master volume • Four zone speaker outputs offering 200 Watts control should be set to -∞. • Two Combo input jacks for microphones • A single ¼” phone jack for line inputs 2. -
Page 6: Front Panel
PA2040 User's Manual توضیحات پانل جلوی دستگاه Front Panel NEUTRIK NEUTRIK NEUTRIK NEUTRIK 1. Combo Inputs 3. Mic In Volume Controls Channels 1 and 2 feature combo input connectors that accept mi- These rotary controls allow users to adjust the incoming micro- crophone input signals through either XLR and ¼"... - Page 7 PA2040 5 6 7 8 9 10 8. Treble Control 5. Echo Control Turn to the right to boost high frequencies, adding crispness to The control on the left will adjust the final output level of the digital percussion from drum machines, cymbals, and synthesizers. Turn echo effect.
- Page 8 PA2040 User's Manual 13 15 13. Play/Pause Button 11. Speaker Zone Buttons This button will allow you to play and pause audio playing through These buttons will allow users to assign the main signal to their re- the USB recording. In addition to this, it will allow you to select spective zones.
- Page 9 PA2040 18. Line Out 15. Stop/Menu Button These RCA and ¼” sockets provide signal output (pre-master fad- In general, pushing this button will return you to the previous er) for cassette decks, MP3 recorders and consumer-grade audio menu. This includes when navigating menus and sub-menus with- equipment.
- Page 10 PA2040 User's Manual 24. Antenna This BNC port is for the inclusion of the PA2040's antenna. This allows the built-in USB module's radio to receive radio signals. The radio function can be found within the USB module's main menu. FM Antenna ترمینال نصب سیم آنتن هوایی FM جهت...
- Page 11 PA2040 More on the USB Recorder AC Power Cable مرور مجدد بر سیستم ضبط و پخش The PA2040 includes a pre-installed AC power cable. This can be connected to a suitable AC power outlet to provide power to the mixer. Be sure to check local voltage levels before attempting to use this device.
- Page 12 PA2040 User's Manual Deleting a File Repeat Mode When in the Music (MSC) menu, select the file you wish to delete. To activate repeat, push and hold the Play/Pause button when Push and hold the ; button to enter options. Use and : to in the Music (MSC) menu.
- Page 13 PA2040 Using the FM Radio FM مراحل استفاده از رادیو Radio Radio STEP 4 STEP 1 4 مرحله 1 مرحله 91.7MHz When complete, the radio will automatically start. You Use the and : buttons to navigate to the FM can push the ...
- Page 14 PA2040 User's Manual Recording an MP3 to Internal Memory )USB مراحل ضبط بروی حافظه داخلی (بدون فلش Record Radio STEP 4 STEP 1 91.7MHz 4 مرحله 1 مرحله Use the and : buttons to locate the "REC" menu to pause recording at any time.
- Page 15 PA2040 Recording an MP3 to USB Drive USB مراحل ضبط بروی فلش Radio STEP 4 STEP 1 91.7MHz 4 مرحله 1 مرحله Insert a FAT-32 formatted USB flash drive. This will automatically allow you to record directly to the USB ...
-
Page 16: Application
PA2040 User's Manual کاربرد APPLICATION نحوه ارتباط ادوات صوتی ما نند رادیو ضبط ، سی دی ، ا رگ ،گیتاربرقی ، ریتم با کس ،آمپلی فایر کمکی ، باند اکتیو (باندهای مجهز به آ مپلی فایر) وباند مونیتور Page 16... - Page 17 PA2040 Page 17...
-
Page 18: Specifications
PA2040 User's Manual SPECIFICATIONS Zone Outputs: 200W (100V) POWER AMP, Output Power in Watts (@THD<0.5%, 1KHz) Low Impedance Output: 200W @ 4 ohms Built-in Delay Effect Variable Digital Echo with Speed and Repeat Combo Mic Inputs Line Input Channel Master Graphic EQ Bass and Treble Control Noise (20Hz to 20KHz bandwidth, IHF-A weighted, line inputs to main output) Master Output, all channel level at min. - Page 19 PA2040 MEMO Page 19...
- Page 20 W W W.ECHO CH AN G .C OM W W W.ECHO CH A N G. IR Head Office: No. 224, Echo Chang Building Keshavarz Blvd, 14177 Tehran, Iran Tel: +98 21 88959010, 88961413 Fax: +98 21 88959252...
